US Patent:

20120282555, Nov 8, 2012

Filed:

Oct 28, 2011

Appl. No.:

13/284393

Inventors:

Trace Cody - Austin TX, US
Case Gornstein - Plano TX, US
Alejandro Lago - Austin TX, US
Matthew Phelps - Indianapolis IN, US
Mark Thatcher - Austin TX, US

Assignee:

Flare Industries, Inc. - Austin TX

International Classification:

F23N 5/10
F23G 7/08
F23Q 7/10

US Classification:

431 5, 431258, 431 74, 431202, 431 6

Abstract:

An ignition assembly for use in pilots for flaring, incineration, and process burner applications, includes a hot surface igniter assembly specifically located in the pilot head or combustion chamber of a flame front ignition system for providing a pilot ignition source. The pilot head is positioned proximally to the exhaust exit of a flare gas stack. The hot surface ignition assembly is positioned proximally to the pilot head. The hot surface ignition assembly passes electric current through a ceramic-insulated element in order to produce heat by induction sufficient to ignite said pilot gas. A thermocouple, or other form of flame sensor, is provided for detecting and a sensing the existence of pilot flame and for controlling the ignition sequence.
