Alexander S Leanos

US Patent:

20140026833, Jan 30, 2014

Filed:

Jul 30, 2012

Appl. No.:

13/561227

Inventors:

Jeff A. Jensen - Dunlap IL, US
Alexander Speros Leanos - Metamora IL, US
Donald Lemont Stamets - Bloomington IL, US
Gerald Alan Nuese - Peoria IL, US
John Curtis Simkins - Tremont IL, US
Casey Bradford Behringer - Metamora IL, US

Assignee:

CATERPILLAR, INC. - Peoria IL

International Classification:

F01P 7/02
B21D 53/78

US Classification:

123 4149, 29889

Abstract:

A cooling fan shroud comprises multiple, functionally identical sections that form a ring-like structure that completely surrounds the fan when the shroud is installed onto an aperture plate or other structure. The shroud makes the cooling system more efficient by improving air flow at a given fan speed by reducing fan tip clearance, and increasing air flow due through the fan. An alternative, single piece shroud is also provided which can be retrofitted to an existing cooling system.
