Alfred H Wells

US Patent:

44382901, Mar 20, 1984

Filed:

Jun 15, 1981

Appl. No.:

6/388695

Inventors:

Alfred E. Wells - Rochelle Park NJ
James H. Casillo - Towaco NJ

Assignee:

Thermo Electric Co., Inc. - Saddle Brook NJ

International Classification:

H01L 3528

US Classification:

136221

Abstract:

A fast response thermocouple probe is formed from two strips of different resilient thermocouple metals. The strips each have a bowed portion with the bowed portions overlapping and crossing each other at a spot welded junction point. The ends of each strip are connected together and engage a body member so that the bowed portions are spaced from the body. The strips are bent to form leaf springs thereby allowing for a resilient junction.

US Patent:

56225725, Apr 22, 1997

Filed:

Aug 28, 1995

Appl. No.:

8/520463

Inventors:

Alfred H. Wells - Williamsburg VA
Gerald M. Cobb - Hampton VA

Assignee:

Newport News Shipbuilding and Dry Dock Company - Newport News VA

International Classification:

C22C 3804
C22C 3806
C21D 600

US Classification:

148320

Abstract:

A steel plate has a minimum yield strength of 65 ksi, a tensile strength minimum of 78 ksi, a minimum elongation in 8 inches and 2 inches for a plate up to 24 inches in width of 18% and 22% respectively and a minimum elongation of 16% and 20% for a plate wider than 24 inches and a minimum Charpy V-notch energy of 30 ft-lb longitudinal and 20 ft-lb transverse at -40. degree. F. and a composition of the following weight percentages: a) carbon 0. 03-0. 10, b) manganese 1. 10-1. 65, c) phosphorous 0. 025 max, d) sulfur 0. 010 max, e) silicon 0. 10-0. 50, f) nickel 0. 40 max, g) chromium 0. 20 max, h) molybdenum 0. 03-0. 08, i) copper 0. 35 max, j) vanadium 0. 04-0. 10, k) columbium 0. 02-0. 06, l) aluminum 0. 03-0. 08 and treated by heat treating and/or rolling.
