Angel D Carvajal

US Patent:

20210328462, Oct 21, 2021

Filed:

Jun 30, 2021

Appl. No.:

17/363123

Inventors:

- Cambridge MA, US
Angel J. Carvajal - New York NY, US

Assignee:

Massachusetts Institute of Technology - Cambridge MA

International Classification:

H02J 50/12
H01F 38/14
H01F 27/28

Abstract:

A transformer system is provided that includes an ensemble of four magnetically coupled coils having fixed spacing geometry. The ensemble of four magnetically coupled coils includes a load coil, a primary resonant coil, a drive coil and a secondary resonant coil. All coils are coupled in the transformer system, but the first resonant coil is highly coupled with the drive coil so that the resonant coil can receive energy from the drive coil and the second resonant coil is highly coupled to the load coil so that the load coil can extract energy efficiently from the second resonant coil. Additionally, the primary resonant coil may be at least partially nested coaxially inside the drive coil and/or the secondary resonant coil may be at least partially nested coaxially inside the load coil.

US Patent:

20210159734, May 27, 2021

Filed:

Feb 2, 2021

Appl. No.:

17/165008

Inventors:

- Cambridge MA, US
Angel J. Carvajal - New York NY, US

Assignee:

MASSACHUSETTS INSTITUTE OF TECHNOLOGY - Cambridge MA

International Classification:

H02J 50/12
H01F 38/14
H01F 27/28

Abstract:

A transformer system is provided that includes four magnetically coupled coils having fixed spacing geometry. The four magnetically coupled coils include a drive coil that produces magnetic fields and a load coil. All coils are coupled in the transformer system, but the first resonant coil is highly coupled with the drive coil so that the resonant coil can receive energy from the drive coil and the second resonant coil is highly coupled to the load coil so that the load coil can extract energy efficiently from the second resonant coil.

US Patent:

20190267843, Aug 29, 2019

Filed:

Feb 25, 2019

Appl. No.:

16/283911

Inventors:

- Cambridge MA, US
Angel J. Carvajal - New York NY, US

Assignee:

MASSACHUSETTS INSTITUTE OF TECHNOLOGY - Cambridge MA

International Classification:

H02J 50/12
H01F 27/28
H01F 38/14

Abstract:

A transformer system is provided that includes four magnetically coupled coils having fixed spacing geometry. The four magnetically coupled coils include a drive coil that produces magnetic fields and a load coil. A first resonant coil is magnetically coupled to the drive coil producing energy that is stored by the first resonant coil. A second resonant coil is magnetically coupled to the first resonant coil to propagate the energy stored in the first resonant coil to the second resonant coil without using a magnetic core. The second resonant coil is then magnetically coupled to the load coil where the energy is transferred to the load coil.
