Anna D Hayes

US Patent:

20110313522, Dec 22, 2011

Filed:

May 23, 2011

Appl. No.:

13/113815

Inventors:

Anna S. Hayes - Newton Centre MA, US

Assignee:

Anew Optics, Inc. - Newton Centre MA

International Classification:

A61F 2/16

US Classification:

623 643

Abstract:

The invention is directed to an assembly comprising a haptic for fixation to, and manufacture in conjunction with, an intraocular lens to be implanted in the natural lens capsule of an eye. The haptic of the invention comprises a continuous ribbon forming an essentially oblong shape having anterior and posterior portions relative to the elliptical center of the haptic, wherein the ribbon loop includes two or more essentially congruent ribbon arches in each portion, and each ribbon arch has a natural index of curvature with an inner and outer edges. designed to expand the eye capsule and put tension on the zonules of the eye. The ribbon affixes to the lens on each side of the optic edge at a point or a series of points that provides suitable centration and stability of the optic, and to suspend the optic in the open capsular space. The material of the haptic is preferably somewhat flexible, and elastic, so as to provide a constant, positive force on the capsule throughout all phases of accommodation, thereby preserving tension of the zonules and allowing the capsule to change shape naturally. The haptic ribbons may be solid or of an open work structure to increase the amount of hydration available to the lens capsule. A secondary haptic ribbon, affixed to a plano optical plate, may be located on the posterior capsular surface and oriented so that the haptic arms extend through the capsular prime meridian to the anterior capsular surface at a 90 angle from the anterior haptic ribbons, thus providing for a capsular configuration as natural as possible, yet associated with an intraocular lens that may be inserted through an incision of less than 3 millimeters.

US Patent:

20110313523, Dec 22, 2011

Filed:

May 23, 2011

Appl. No.:

13/113975

Inventors:

Anna S. Hayes - Newton Centre MA, US

Assignee:

Anew Optics, Inc. - Newton Centre MA

International Classification:

A61F 2/16

US Classification:

623 643

Abstract:

The invention is directed to an assembly comprising a haptic for fixation to, and manufacture in conjunction with, an intraocular lens to be implanted in the natural lens capsule of an eye. The haptic of the invention comprises a continuous ribbon forming an essentially oblong shape having anterior and posterior portions relative to the elliptical center of the haptic, wherein the ribbon loop includes two or more essentially congruent ribbon arches in each portion, and each ribbon arch has a natural index of curvature with an inner and outer edges. designed to expand the eye capsule and put tension on the zonules of the eye. The ribbon affixes to the lens on each side of the optic edge at a point or a series of points that provides suitable centration and stability of the optic, and to suspend the optic in the open capsular space. The material of the haptic is preferably somewhat flexible, and elastic, so as to provide a constant, positive force on the capsule throughout all phases of accommodation, thereby preserving tension of the zonules and allowing the capsule to change shape naturally. The haptic ribbons may be solid or of an open work structure to increase the amount of hydration available to the lens capsule. A secondary haptic ribbon, affixed to a plano optical plate, may be located on the posterior capsular surface and oriented so that the haptic arms extend through the capsular prime meridian to the anterior capsular surface at a 90 angle from the anterior haptic ribbons, thus providing for a capsular configuration as natural as possible, yet associated with an intraocular lens that may be inserted through an incision of less than 3 millimeters.

US Patent:

20180311033, Nov 1, 2018

Filed:

Jun 28, 2018

Appl. No.:

16/021170

Inventors:

- Bristol TN, US
Anna S. Hayes - Newton Centre MA, US

International Classification:

A61F 2/16

Abstract:

A haptic for fixation to, and manufacture in conjunction with, an intraocular lens to be implanted in the natural lens capsule of the human eye is disclosed. The haptic secures the lens in an appropriate position within the natural capsule so as to provide optimal visual acuity through the aphakic lens. The haptic is designed to position the lens neutrally, anteriorly or posteriorly within the lens envelope. The haptic has an anterior retention ring and a posterior retention ring.

US Patent:

20150327991, Nov 19, 2015

Filed:

Jul 24, 2015

Appl. No.:

14/808412

Inventors:

- Bristo TN, US
Anna S. Hayes - Newton Centre MA, US

International Classification:

A61F 2/16

Abstract:

A haptic for fixation to, and manufacture in conjunction with, an intraocular lens to be implanted in the natural lens capsule of the human eye is disclosed. The haptic secures the lens in an appropriate position within the natural capsule so as to provide optimal visual acuity through the aphakic lens. The haptic is designed to position the lens neutrally, anteriorly or posteriorly within the lens envelope. The haptic has an anterior retention ring and a posterior retention ring.
