Annette J Meredith

US Patent:

20110121030, May 26, 2011

Filed:

May 18, 2010

Appl. No.:

12/782680

Inventors:

WILLIAM R. MEREDITH - RALEIGH NC, US
ANNETTE JOHNSON MEREDITH - RALEIGH NC, US
ALBERT J. PARVIN - SAN ANTONIO TX, US
ERIKA C. LAICHE - SAN ANTONIO TX, US

International Classification:

B05C 9/06

US Classification:

222129

Abstract:

A structure and system are described which include the use of a combination container for sequentially dispensing multiple fluids onto a removable applicator device. A preferred application of the invention is with the sequential dispensing of a quantity of disinfecting solution over a toothbrush, followed by the dispensing of a measured quantity of toothpaste onto the toothbrush. The device is constructed in a double walled cylindrical (circular or non-circular) configuration with a hollow plunger component coaxially positioned within the cylindrical walls. Beneath the plunger component is contained a quantity of disinfectant solution such that when the plunger is directed downward the disinfectant solution is forced upward between the walls of the double walled container and through dispensing ports directed into the interior where the applicator is positioned. The contained motion of the plunger component downward under the directed force of the applicator brings the base of the hollow plunger into contact with the base wall of the container and causes the collapse of the hollow plunger. A second liquid/gel contained within the hollow plunger is then directed up and out of its enclosed volume through ports aligned with the applicator. The design is intended to accommodate a wide variety of compounds and applicators. Wherever the dispensing of two different compounds (liquids/gels) is required in a sequential manner, the present invention finds applicability.

US Patent:

20230021069, Jan 19, 2023

Filed:

Jul 18, 2022

Appl. No.:

17/867636

Inventors:

William R. MEREDITH - Raleigh NC, US
Annette Johnson MEREDITH - Raleigh NC, US

International Classification:

A61M 5/315
A61M 5/28

Abstract:

A syringe device with preferred and alternate embodiments structured to store, mix (if appropriate), and dispense multiple compounds (fluids, gels, suspensions, powdered solids, etc.) without the need for multiple syringes or the repeated use of a syringe. In a first embodiment, the device stores two separate compounds for use and mixes the compounds before dispensing the combined mixture. In a second embodiment, the device stores two separate fluids for use and dispenses the first fluid followed sequentially by dispensing the second. The device may be used with a variety of dispensing structures such as an applicator or a cannula (syringe needle). The present invention finds specific application, for example, in a syringe device for storing and combining a diluent with a lyophilized drug/vaccine. Overall, the device structures a unique arrangement of chambers and channels for the accurate storage, mixing, and dispensing of multiple compounds (fluids, gels, suspensions, powdered solids, etc.).
