Anthony J Gallis

US Patent:

6695277, Feb 24, 2004

Filed:

Oct 16, 2002

Appl. No.:

10/271908

Inventors:

Anthony J. Gallis - Lake Hiawatha NJ

Assignee:

Harsco Technologies Corporation - Fairmont MN

International Classification:

E04G 17075

US Classification:

249191, 249217

Abstract:

A method of constructing a wall form and of forming a wall includes employing a modular concrete form system having a clamping device to clamp adjacent modular form members to one another. The clamping device includes an elongated bar, a pair of clamps mounted on the bar, and a pair of clip assemblies mounted on the bar, the bar being shaped to complementarily engage the perimeter frames of the modular form members. The jaws of the clamps retain the perimeter frames of the adjacent modular form members against the bar, which clamps the form members to the bar and retains them in a flush orientation with one another. The clip assemblies each having a slidable tie clip formed with an opening for receiving a portion of a tie therein. The tie is tapered and is nominally of a circular cross section and formed with a plurality of spaced groves at the alternate ends thereof.

US Patent:

20020092961, Jul 18, 2002

Filed:

Jan 12, 2001

Appl. No.:

09/759895

Inventors:

Anthony Gallis - Lake Hiawatha NJ, US

International Classification:

E04G011/02
E04G017/06

US Classification:

249/045000, 249/191000, 249/193000

Abstract:

A method of constructing a wall form and of forming a wall includes employing a modular concrete form system having a clamping device to clamp adjacent modular form members to one another. The clamping device includes an elongated bar, a pair of clamps mounted on the bar, and a pair of clip assemblies mounted on the bar, the bar being shaped to complementarily engage the perimeter frames of the modular form members. The jaws of the clamps retain the perimeter frames of the adjacent modular form members against the bar, which clamps the form members to the bar and retains them in a flush orientation with one another. The clip assemblies each having a slidable tie clip formed with an opening for receiving a portion of a tie therein. The tie is tapered and is nominally of a circular cross section and formed with a plurality of spaced groves at the alternate ends thereof.

US Patent:

20020100857, Aug 1, 2002

Filed:

Apr 20, 2001

Appl. No.:

09/839882

Inventors:

Anthony Gallis - Lake Hiawatha NJ, US

International Classification:

E04G011/08

US Classification:

249/045000, 249/191000, 249/193000, 249/219200

Abstract:

A clamping device is configured to clamp adjacent modular form members to one another. The clamping device includes an elongated bar and a pair of clamps mounted on the bar. A plurality of gusset plates are disposed on and protrude outwardly from the bar to complementarily engage the perimeter frames of the modular form members. The jaws of the clamps retain the perimeter frames of the adjacent modular form members against the bar, which clamps the form members to one another and retains them in a flush orientation with one another. The bar is generally channel shaped and includes a pair of reentrant legs adjacent a throat. A number of auxiliary attachments are cooperably mountable on the bar.

US Patent:

44012918, Aug 30, 1983

Filed:

Feb 4, 1981

Appl. No.:

6/231492

Inventors:

Anthony J. Gallis - Lake Hiawatha NJ

Assignee:

Harsco Corporation - Camp Hill PA

International Classification:

E04G 1100
E04G 1704

US Classification:

249196

Abstract:

A concrete wall form with an attachment inserted between extending abutting flanges of form panels to secure a workman's safety belt, the attachment being pivotally mounted and comprising an oval plate having two spaced circular holes.

US Patent:

44732090, Sep 25, 1984

Filed:

Jan 15, 1982

Appl. No.:

6/339774

Inventors:

Anthony J. Gallis - Lake Hiawatha NJ
Thomas P. Kyritz - Teaneck NJ

Assignee:

Harsco Corporation - Camp Hill PA

International Classification:

E04G 1700

US Classification:

249191

Abstract:

Prefabricated modular wallform units are formed with panels designed to mate against one another and to define an aperture through which a tie rod can pass. End rails at the mating edges of the panels have webs, interior end flanges to fit against a sheet of sheathing material (e. g. , plywood), and exterior end flanges to be supported against strongback walers. Elongated kerfs are formed in mating edges of the interior and exterior end flanges. These mate to define a universal through-passage suitable for any of a variety of types of tie rod. A median flange extends along the length of the mating side of the web on a line intermediate the end flanges. The median flanges are narrower than the respective end flanges and serve as distance fingers for locating the tie rods. Universal holes are also provided in the webs adjacent the median flanges and on the sides away from the interior end flanges. A T-bolt can be inserted through the universal holes of two mating end rails to join two mating panels together.

US Patent:

44226179, Dec 27, 1983

Filed:

Jan 15, 1982

Appl. No.:

6/339776

Inventors:

Anthony J. Gallis - Lake Hiawatha NJ

Assignee:

Harsco Corporation - Camp Hill PA

International Classification:

E04G 1100

US Classification:

249 19

Abstract:

An edge joist is provided for installation along an edge of a wallform sheathing panel. The edge joist is generally formed as a S-beam. A front flange thereof is generally L-shaped and engages the rear surface of the panel at one edge thereof. A rear flange is arranged generally parallel to the front flange and has a provision, such as a T-channel bolt slot, for connecting to wallform walers. A stepped web connects the lower edge of the front flange to an upper edge of the rear flange, and preferably includes a lower web plate extending back from the lower edge of the front flange, a riser extending slopingly back and upward from the rear plate, and an upper web plate extending rearward from the top of the riser to the rear flange. The front flange can have a toe plate overlapping and protecting the panel edge and a flange plate extending upward along the rear surface of the panel. Preferably, beads are formed along the lower surface of the web lower plate to form seals when edge joists are butted together.

US Patent:

43569935, Nov 2, 1982

Filed:

Jan 15, 1981

Appl. No.:

6/225203

Inventors:

Anthony J. Gallis - Lake Hiawatha NJ
Prabh S. Ahluwalia - Brooklyn NY

Assignee:

Harsco Corporation - Camp Hill PA

International Classification:

B28B 700
B28B 734

US Classification:

249 27

Abstract:

Corner forming apparatus is disclosed, including novel generally L-shaped member having a seating flange projecting from one leg of the member substantially parallel to the other leg. The seating flange is adapted to shield an edge of a panel when the panel is seated on the seating flange. The other leg of the L-shaped member is securable to a panel-support beam mounted on the back of said panel, and is provided with at least one aperture therein to receive fastening elements for securing another panel to the other leg such that a surface of the other panel and the outer surface of said one leg are substantially coplanar. Also a unique outside corner waler useful with the inside corner forming member in quick and accurate assembly of a complete corner wall form. Said waler having a major leg and a minor leg each joined at one end at right angles by an apertured web and being of respectively different heights such that said waler seats at about a 45. degree. angle.

US Patent:

44051123, Sep 20, 1983

Filed:

Apr 9, 1982

Appl. No.:

6/367108

Inventors:

Max Doubleday - Caldwell NJ
Anthony J. Gallis - Lake Hiawatha NJ

Assignee:

Harsco Corporation - Camp Hill PA

International Classification:

E04G 1700

US Classification:

249207

Abstract:

A gang form or tie rod holding bolt is adapted for holding a tie rod passing through abutting frames of prefabricated panel units, the frames having mating slots. The tie rod holding bolt includes a body portion and a slot leg for extending through the mating slots, a middle leg for loading the frames, and a tie rod engaging leg for transferring a load from the tie rod to the holding bolt. The form slot leg and the middle leg are horizontally offset to straddle the tie rod and the middle leg is adapted to transfer the load to the frames, thereby providing the bolt with great stability under heavy loads. The design avoids eccentric load on the bolt. An assembly includes the bolt, tie rod, wedge pin and two frames.
