Billy Eugene Harold

US Patent:

39945235, Nov 30, 1976

Filed:

Jun 25, 1975

Appl. No.:

5/590196

Inventors:

Billy E. Harold - Taylor MI

International Classification:

B60P 308

US Classification:

296 1A

Abstract:

A vehicle transport trailer including a low bed trailer capable of transporting a load of six full-sized sedans, a load of six pick-up trucks, a mixed load of vans and full-sized sedans, and further mixed loads of pick-up trucks, vans, compact sedans and other vehicles. The vehicle transport trailer in one embodiment relates to a load carried entirely within the limits and confines of a trailer structure without requiring storage of any vehicle on or above the tractor drawing the trailer. An optional embodiment includes the combination of a trailer constructed in accordance with the present invention, and further including an above the tractor cab arrangement for an additional vehicle. These referred to load arrangements are made possible by particular track and elevating mechanism arrangements and in some cases by a particular orientation of the vehicles with a loading sequence related to their relative position on the trailer.

US Patent:

42214220, Sep 9, 1980

Filed:

Mar 27, 1978

Appl. No.:

5/890236

Inventors:

Billy E. Harold - Taylor MI

International Classification:

B60P 308

US Classification:

410 26

Abstract:

A vehicle transport tractor and trailer of the stinger-steered type including a specialized sliding track and pivotal head ramp used in connection with the tractor. The combination is capable of transporting a load of nine large cars, or as many as ten small cars with equal facility. The tractor and trailer combination is likewise capable of handling an important variety of mixed loads which are commercially needed and include vans and pick-up trucks as well as conventional cars and station wagons.

US Patent:

41068050, Aug 15, 1978

Filed:

Jun 2, 1976

Appl. No.:

5/692060

Inventors:

Billy Harold - Taylor MI

International Classification:

B62C 100

US Classification:

296 1A

Abstract:

A vehicle transport trailer including a low bed trailer capable of transporting a load of eight large station wagons and cars, a load of six pick-up trucks, a load of nine small cars, eight mini pick-up trucks, and a broad variety of mixed loads of pick-up trucks, vans, large cars and small cars. The vehicle transport trailer relates to a load of automotive vehicles which are carried entirely within the limits and confines of the self-contained trailer structure without requiring storage of any new vehicle on or above the tractor used to draw the trailer. The several embodiments of the invention are made possible by particular specialized track and track elevating mechanism constructions, and in some cases by a particular orientation of loaded and carried vehicles with a loading sequence related to their relative positions on the trailer.

US Patent:

39604012, Jun 1, 1976

Filed:

Jul 25, 1974

Appl. No.:

5/491811

Inventors:

Billy E. Harold - Taylor MI

International Classification:

B60P 308

US Classification:

296 1A

Abstract:

A vehicle transport trailer including a low bed trailer capable of transporting a load of seven full size station wagons and sedans, a load of five pick-up trucks and one intermediate size sedan, a load of ten sub-compact size cars and a broad variety of mixed loads of pick-up trucks, vans, intermediate size sedans, full size sedans, sub-compact and the like cars. The vehicle transport trailer relates to a load of automotive vehicles which are carried entirely within the limits and confines of the self-contained trailer structure without requiring storage of any vehicle on or above the tractor used to draw the trailer. The several embodiments of the invention are made possible by particular specialized track and track elevating mechanism constructions, and in some cases by a particular orientation of the loaded and carried vehicles with a loading sequence related to their relative positions on the trailer.
