Brandon D Barnard

US Patent:

20120175474, Jul 12, 2012

Filed:

Nov 23, 2011

Appl. No.:

13/303681

Inventors:

Brandon Barnard - Evansville IN, US
Karl Fritze - Hastings MN, US

International Classification:

H05K 7/00
F16B 47/00
H01F 7/02

US Classification:

2481221, 24828831

Abstract:

A holder for an electronic device includes a head with elastically flexible portions configured to removably receive the electronic device with a snap-fit interlock, a neck for supporting the head relative to a surface, and a ball and socket connector coupling the neck to the head, the ball and socket connector configured to allow adjustment of the yaw, the pitch, and the roll of the electronic device with respect to the neck when the electronic device is coupled to the head.

US Patent:

D682281, May 14, 2013

Filed:

Nov 23, 2011

Appl. No.:

29/407176

Inventors:

Brandon Barnard - Evansville IN, US
Karl Fritze - Hastings MN, US

Assignee:

Aspire Innovation, LLC - Evansville IN

International Classification:

0807

US Classification:

D14447

US Patent:

20160315496, Oct 27, 2016

Filed:

Dec 28, 2015

Appl. No.:

14/979989

Inventors:

Brandon Barnard - Evansville IN, US

International Classification:

H02J 7/02
H02J 7/00

Abstract:

An inductive charging station that induces an electric current in an electronic device thereby charging the electronic device. The inductive charging station generally includes a base, a vertical portion, and a top member. The base includes a charging module in electrical communication with a transmitter part disposed in the top member such that when the electronic device's receiver is in communication with the transmitter part, the receiver is in electrical communication with the system's charging module, thereby charging the electronic device. The top member defines a first member in pivotal communication within a bore disposed in a second member. In application, the second member is configured to pivot through a 360-degree angle such that the electronic device can be rotatably positioned with the second member.

US Patent:

20140168890, Jun 19, 2014

Filed:

Dec 12, 2013

Appl. No.:

14/104013

Inventors:

Brandon Barnard - Evansville IN, US

International Classification:

F16M 11/12
H05K 7/14

US Classification:

36167955, 248562, 2481812

Abstract:

A holder for an electronic device includes a head configured to removably receive and securely hold the electronic device. The head includes a first portion and a second portion that is slidably movable with respect to the first portion for adjustment to a size of the electronic device, wherein the first and second portions are biased toward each under a force of a spring. A damper is operatively positioned between the first portion and the second portion so as to dampen the movement of the second portion with respect to the first portion under the bias of the spring.
