Cardy J Louis

US Patent:

6852262, Feb 8, 2005

Filed:

May 9, 2002

Appl. No.:

10/142123

Inventors:

William C. Carson - Acton MA, US
Alexander T. Chenvainu - Brookline MA, US
Thomas A. Christman - Lexington MA, US
Kenneth E. Johnson - Hollis NH, US
Charles P. Kiricoples - Salem MA, US
Alejandro Lee - Cambridge MA, US
Cardy J. Louis - Raynham MA, US
Helge Zimmet - Waltham MA, US

Assignee:

The Gillette Company - Boston MA

International Classification:

B29D005/00
B28B007/22
B28B005/00
B29B013/00

US Classification:

264252, 264239, 264241, 264250, 264255, 264259, 2642711, 264275, 264279

Abstract:

Methods of manufacturing razor cartridges are provided. One method includes loading a support portion of a supported blade into an elongated blade slot defined by a core member, the core member being configured to define a portion of a molding cavity defining the shape of the cartridge housing; and delivering a resin to the molding cavity to form the housing and capture a portion of the blade in the resin. In another method, a plurality of razor cartridges are manufactured substantially simultaneously by (a) removably mounting each blade on a core member; (b) placing each core member in a molding cavity; and (c) delivering a resin to the molding cavities to form at least a portion of the cartridge housing and capture a portion of the blade in the resin. In other methods a flexible region is provided adjacent the blade ends by: (a) delivering a compliant material to the molding cavity to capture at least the ends of the blade; (b) placing the blade and molded compliant material in a second molding cavity defining the shape of the molded housing; and (c) delivering a resin to the second molding cavity to form the molded housing, or by (a) providing coring areas in the molding cavity beyond each of the blade ends, configured to provide a flexible region of plastic adjacent each blade end in the finished product; and (b) delivering a resin to the molding cavity. In some methods, the resin is delivered through a gate that is positioned so that a substantial portion of the resin flow goes by the blade ends before the molding cavity is filled.
