Carey W Zimmerman

US Patent:

6378789, Apr 30, 2002

Filed:

Jun 1, 2000

Appl. No.:

09/585849

Inventors:

Jeffrey Y. Chen - Seattle WA
John A. Boticki - Racine WI
Carey W. Zimmerman - Racine WI

Assignee:

S. C. Johnson Commercial Markets, Inc. - Sturtevant WI

International Classification:

B05B 730

US Classification:

239443, 239310, 239312, 239318, 239353, 239354, 239407, 239413, 239414, 2394161, 239436, 239527, 239528, 239444, 137889, 137894

Abstract:

A combination spray apparatus which allows for the selection of several different flowable materials to be sprayed from a single unit and at the site of the unit itself. In the preferred manner, the spray apparatus includes a trigger nozzle as well as the selection of two different materials to be sprayed through a second barrel portion. An eductor it utilized to draw selected materials into a spray stream. The combination spray apparatus is operable with water pressures which are customary to most cities and industries.

US Patent:

6954737, Oct 11, 2005

Filed:

Nov 5, 2001

Appl. No.:

09/992406

Inventors:

Sayed Javad Kalantar - Racine WI, US
Carey W. Zimmerman - Racine WI, US
Cameron Adams - Waukegan WI, US
Thomas E. Blenkhorn - Frankenmuth MI, US

Assignee:

JohnsonDiversey, Inc. - Sturtevant WI

International Classification:

G06E001/00
G06E003/00
G06G007/00
G06F015/18
G06F017/00

US Classification:

705 50, 705 7, 705 8

Abstract:

A system and method are shown for work management for facility maintenance. The system includes a central management server configured to receive a first set of information including tasks to be performed at a first facility and to generate a first work schedule for a first user selected to perform the first work schedule at the first facility. The system further includes a first client device at the first facility, where the first client device is configured to receive the first work schedule from the central management server and display the first work schedule to the first user via an electronic management interface. The electronic interface is further configured to receive task completion data from the first user and send the data to the central management server. When the central management server receives the task completion data, the central management server is configured to update a status of the work schedule based upon the task completion data received from the first user.

US Patent:

58629483, Jan 26, 1999

Filed:

Jun 14, 1996

Appl. No.:

8/668051

Inventors:

Brent Duchon - San Jose CA
Raymond McKinnon - Castro Valley CA
Carey W. Zimmerman - Racine WI
Michael J. Greaney - Castro Valley CA
A. Ross Cameron - Sidney, AU
Thomas A. Helf - New Berlin WI
Charles E. Seaman - Kenosha WI
John A. Boticki - Racine WI

Assignee:

SC Johnson Commerical Markets, Inc. - Sturtevant WI

International Classification:

B67D 100

US Classification:

222133

Abstract:

A docking station and bottle system 23 including a filling head 20 and bottle 22 which have a head interconnect 86 and a bottle interconnect 90, respectively, for fastening the bottle 22 to the filling 20 head in order to prevent spillage. The bottle interconnect 90 includes a fluid port 106 and a vent port 104 which are simultaneously opened from a closed position in order to allow the filling head 20 to draw concentrated fluid from the bottle 22 and mix the concentrated fluid with a diluting fluid such as water before being dispensed from a filling head nozzle 52. The bottle 22 includes identifying indicia 158 for purposes of tracking utilization of the bottle and the concentrated fluid contained therein. An information storage system 170 is associated with the bottle and filling head in order to provide records of such concentrated fluid utilization. A wall mounted docking station 200 including one or more filling heads 20 is also provided for.

US Patent:

59542403, Sep 21, 1999

Filed:

Jul 9, 1998

Appl. No.:

9/112092

Inventors:

Brent Duchon - San Jose CA
Raymond McKinnon - Castro Valley CA
Carey W. Zimmerman - Racine WI
Michael J. Greaney - Castro Valley CA
A. Ross Cameron - Sidney, AU
Thomas A. Helf - New Berlin WI
Charles E. Seaman - Kenosha WI
John A. Boticki - Racine WI

Assignee:

S. C. Johnson Commercial Markets, Inc. - Sturtevant WI

International Classification:

B67D 100

US Classification:

222484

Abstract:

A docking station and bottle system 23 including a filling head 20 and bottle 22 which have a head interconnect 86 and a bottle interconnect 90, respectively, for fastening the bottle 22 to the filling 20 head in order to prevent spillage. The bottle interconnect 90 includes a fluid port 106 and a vent port 104 which are simultaneously opened from a closed position in order to allow the filling head 20 to draw concentrated fluid from the bottle 22 and mix the concentrated fluid with a diluting fluid such as water before being dispensed from a filling head nozzle 52. The bottle 22 includes identifying indicia 158 for purposes of tracking utilization of the bottle and the concentrated fluid contained therein. An information storage system 170 is associated with the bottle and filling head in order to provide records of such concentrated fluid utilization. A wall mounted docking station 200 including one or more filling heads 20 is also provided for.

US Patent:

57656053, Jun 16, 1998

Filed:

Jun 14, 1996

Appl. No.:

8/663650

Inventors:

Gary L. Waymire - Menlo Park CA
Michael R. Barry - Palo Alto CA
Carey W. Zimmerman - Racine WI
Raymond McKinnon - Castro Valley CA
Thomas A. Helf - New Berlin WI
Charles E. Seaman - Kenosha WI

Assignee:

SC Johnson Commerical Markets, Inc. - Sturtevant WI

International Classification:

B65B 104

US Classification:

141100

Abstract:

A distributed concentrated chemical dispensing system 300 and method include a central station 302, one or more permanently mounted satellite stations 304, and one or more portable satellite stations 306. Local concentrated chemicals can be distributed from the central station 302 without being diluted to the satellite stations 304, 306 for final dilution. An information storage device 318 is provided for tracking and keeping records of the utilization of the concentrated chemicals.

US Patent:

61291250, Oct 10, 2000

Filed:

Jul 9, 1998

Appl. No.:

9/112673

Inventors:

Brent Duchon - San Jose CA
Raymond McKinnon - Castro Valley CA
Carey W. Zimmerman - Racine WI
Michael J. Greaney - Castro Valley CA
A. Ross Cameron - Sidney, AU
Thomas A. Helf - New Berlin WI
Charles E. Seaman - Kenosha WI
John A. Boticki - Racine WI

Assignee:

SC Johnson Commercial Markets, Inc. - Sturtevant WI

International Classification:

B65B 306

US Classification:

141 18

Abstract:

A docking station and bottle system 23 including a filling head 20 and bottle 22 which have a head interconnect 86 and a bottle interconnect 90, respectively, for fastening the bottle 22 to the filling 20 head in order to prevent spillage. The bottle interconnect 90 includes a fluid port 106 and a vent port 104 which are simultaneously opened from a closed position in order to allow the filling head 20 to draw concentrated fluid from the bottle 22 and mix the concentrated fluid with a diluting fluid such as water before being dispensed from a filling head nozzle 52. The bottle 22 includes identifying indicia 158 for purposes of tracking utilization of the bottle and the concentrated fluid contained therein. An information storage system 170 is associated with the bottle and filling head in order to provide records of such concentrated fluid utilization. A wall mounted docking station 200 including one or more filling heads 20 is also provided for.
