Carl Lee Beckman

US Patent:

20070193754, Aug 23, 2007

Filed:

Feb 23, 2006

Appl. No.:

11/360838

Inventors:

Carl Beckman - Fresno CA, US
John Beckman - Fresno CA, US

International Classification:

A01B 33/00

US Classification:

172041000

Abstract:

The linear actuated reciprocating garden hoe of the present invention is an effective and easy to use gardening tool for removing weeds and unwanted grasses and for cultivating ground. Specifically, the present invention discloses a reciprocating hoe having a hoe blade attached to a second end of a handle, a linear actuator mounted on the handle near the second end thereof and a linkage assembly interconnecting the linear actuator and hoe blade. A hoe mounting bracket mounts the hoe blade to the second end of the handle. The pivoting mechanism has a reciprocating rod connected to the linear actuator, a linkage bracket connected to the hoe blade and a linkage lever interconnecting the reciprocating rod and linkage bracket. Preferably, the range of reciprocation of the hoe blade is limited to a range of 2 to 3 millimeters to minimize risk to the user, bystanders or cultivated vegetation.

US Patent:

20140021698, Jan 23, 2014

Filed:

Jul 22, 2012

Appl. No.:

13/555181

Inventors:

Nancy E. Beckman - Fresno CA, US
Carl L. Beckman - Fresno CA, US

International Classification:

B62B 3/02

US Classification:

280651

Abstract:

A cart for supportably transporting a plurality of bags by the handles of the bags when the bags have one or more items therein. The cart allows the user to easily transport full bags and, relative to standard carts, reduces the likelihood that the bags will spill. The cart has a collapsible frame assembly with a first frame member and a second frame member, a bag support assembly for receiving and retaining the bags, a handle for pushing the cart and a pair of wheel assemblies to allow the cart to move across a surface. The frame assembly is in a generally X-shaped configuration with one of the frame members configured to shorten or lengthen to place the cart in an upright position or a collapsed position. A pull pin is used to automatically fix the position of the cart and allow the user to raise or collapse the cart.

US Patent:

D682500, May 14, 2013

Filed:

Jul 22, 2012

Appl. No.:

29/427748

Inventors:

Nancy E. Beckman - Fresno CA, US
Carl L. Beckman - Fresno CA, US

International Classification:

1202

US Classification:

D34 12
