National Semiconductor
Member of Technical Staff
Integre Technologies, Llc Dec 2005 - Aug 2006
Senior Scientist
Rochester Institute of Technology Dec 2003 - Nov 2005
Distinguished Researcher
Intrinsix Corp. Jan 2001 - Dec 2003
Rfic Architect
Lsi Corporation Jan 1998 - Jan 2001
Distinguished Rf Engineer
(no longer actively engineering) since Dec 2010
Retiree
Synaptics Corp. 2010 - 2010
Senior Engineering Consultant
Clyde Washburn, Consultant Jan 2009 - Dec 2010
Sole Proprietor
National Semiconductor Corp. Apr 2007 - Dec 2008
Member of Technical Staff
Rochester Institute of Technology 2003 - 2005
Distinguished Researcher
Clyde Washburn - Victor NY Robert Bowman - Fairport NY
Assignee:
LSI Logic Corporation - Milpitas CA
International Classification:
H01L 3500
US Classification:
327513, 327565
Abstract:
A deice maximizes the allowable granularity of adjustment of a bus driver line characteristics by compensating for temperature variations by selecting components that have an opposite and approximately equal thermal coefficient. In the first aspect, component parts may be made smaller because their tolerances need not be made so precise. In the second aspect, duplicating the circuitry with matching characteristics allows one circuit to be operational while the other circuit is tested or dormant. Switching between the two circuits is performed seamlessly with no interruption of device operation.
Oscillator Having Unidirectional Current Flow Between Resonant Circuit And Active Devices
An oscillator provides output signals over a range of oscillating frequencies includes an resonant circuit, at least one active circuit device operatively coupled to the resonant circuit to supply energy to the resonant circuit, and at least one unidirectional device coupled to the active circuit device. The unidirectional device permits current to flow between the active circuit device and the resonant circuit when the active circuit device adds energy to the resonant circuit, and impedes a drain of energy from the resonant circuit due to increased output signal amplitude.
A circuit and method are disclosed herein for a crystal oscillator, wherein the Q of the resonant network is not reduced through the loading effects of the oscillators resistive bias network. The oscillator is configured as an operational transconductance amplifier (OTA) coupled to the resonant network. The OTA creates a negative resistance, which compensates for energy lost to resistance within the resonant network, thereby sustaining oscillation at the resonant frequency. Instead of using bias resistors to set and maintain the operating point of the oscillator, another OTA (with a high output impedance) injects a current into the resonant network to bias the oscillator. Advantageously, this technique avoids the reduction in Q that occurs when bias resistors are connected across the high effective parallel resistance of the resonant crystal. The higher Q benefits frequency stability and phase jitter characteristics of the oscillator.
A bandgap reference voltage generating circuit includes a proportional to absolute temperature (PTAT) voltage generating means generating a PTAT voltage. A complementary to absolute temperature (CTAT) voltage generating means generates a CTAT voltage. A temperature coefficient determining means interconnects the PTAT voltage generating means and the CTAT voltage generating means.
Disclosed are hybrid heterodyne transmitters and receivers for use in communications systems, or other systems, and the corresponding methods for hybrid heterodyne transmitting and receiving. A heterodyne receiver for converting a continuous time modulated signal to a discrete time digital baseband signal includes a sigma-delta modulator. The sigma-delta modulator is a sigma-delta analog-to-digital converter constructed and arranged to receive a modulated signal at an RF carrier frequency and provide a quantized output at a first intermediate frequency. The heterodyne receiver may also include a digital mixer constructed and arranged to receive a data stream quantized by the sigma-delta analog-to-digital converter and receive a signal at a second mixing frequency. The digital mixer then provides digital signals representative of a baseband signal suitable for digital signal processing.
Low-Cost Atsc-Receiver-Compatible Digital Tv Modulator
A method and apparatus by which ATSC-receiver-compatible digital TV signals may be generated without most of the discrete and/or high-complexity components required by the ATSC specification, through the use of a precomputation of digital filter coefficients that consolidates multiple functions into a single step, and through the derivation of multiple required carrier frequencies using a single oscillator circuit. The resulting design meets all requirements of the ATSC specification, reducing significantly the cost of the necessary signal-processing functions, and in a manner compatible with the VLSI (very-large-scale-integrated) circuit technologies of the field.
A bandgap reference voltage generating circuit includes a proportional to absolute temperature (PTAT) voltage generating means generating a PTAT voltage. A complementary to absolute temperature (CTAT) voltage generating means generates a CTAT voltage. A temperature coefficient determining means interconnects the PTAT voltage generating means and the CTAT voltage generating means.
Systems And Methods For Signaling And Interference Detection In Sensor Devices
Clyde Washburn - Victor NY, US Eric Bohannon - Henrietta NY, US Imre Knausz - Fairport NY, US Kirk Hargreaves - Sunnyvale CA, US
Assignee:
SYNAPTICS INCORPORATED - Santa Clara CA
International Classification:
G06F 3/041
US Classification:
345173
Abstract:
An input device processing system comprises a sensor module that transmits a first transmitter signal with a transmitter electrode and receives a resulting signal with a receiver electrode. The first transmitter signal comprises a first transmitter frequency, and the resulting signal comprises effects corresponding to the first transmitter signal. A demodulation module demodulates the resulting signal to produce a first signal (e.g., an upper sideband signal) and a second signal (a lower sideband signal), selectably determines a first measurement of a change in capacitive coupling between the transmitter electrode and the receiver electrode based on at least one of the first and second signals, and determines positional information for an input object based on the first measurement.
Clyde Washburn 1981 graduate of Park View High School in South hill, VA is on Classmates.com. See pictures, plan your class reunion and get caught up with Clyde and other high ...
