Dale E Hileman

US Patent:

54053960, Apr 11, 1995

Filed:

Jul 1, 1993

Appl. No.:

8/085714

Inventors:

Mark A. Heldreth - Mentone IN
Dale E. Hileman - Akron IN
Jay T. Vansickle - Leesburg IN

Assignee:

Zimmer, Inc. - Warsaw IN

International Classification:

A61F 238

US Classification:

623 20

Abstract:

A modular tibial prosthesis contains a dovetail mechanism (4, 5 & 14) and a posterior tongue (15) and groove (8) arrangement. The dovetail mechanism cooperates with a reinforcing component (22) to allow alternate use of a spined component (20) with the same base plate (1).

US Patent:

62176188, Apr 17, 2001

Filed:

Oct 26, 1999

Appl. No.:

9/426620

Inventors:

Dale E. Hileman - Akron IN

Assignee:

Bristol-Myers Squibb Company - New York NY

International Classification:

A61F 238

US Classification:

623 2033

Abstract:

An orthopaedic knee component for implanting within a proximal tibia includes a tibial tray with a distally extending stem, a proximal tibial plateau and a post extending from the tibial plateau. The post defines an axis of rotation. An intermediate carrier has an opening in which the post is disposed. The carrier is pivotal about the axis of rotation. A bearing carried by the tibial tray has an articular bearing surface for engagement with a femoral component. The bearing has a recess in which the intermediate carrier is disposed. The projection, carrier and recess allow pivotal movement of the bearing relative to the tibial plateau about the axis of rotation.
