Daniel E. Siegfried - Fort Collins CO, US David Matthew Burtner - Fort Collins CO, US Scott A. Townsend - Fort Collins CO, US John Keem - Bloomfield Hills MI, US Valery Alexeyev - Moscow, RU Vsevolod Zelenkov - Moscow, RU Mark Krivoruchko - Zelenograd, RU
Assignee:
Veeco Instruments, Inc. - Woodbury NY
International Classification:
H01J 7/24
US Classification:
31511181, 250423 R
Abstract:
An ion source design and manufacturing techniques allows longitudinal cathode expansion along the length of the anode layer source (ALS). Cathode covers are used to secure the cathode plates to the source body assembly of an ion source. The cathode covers allow the cathode plate to expand along the longitudinal axis of the ion source, thereby relieving the stress introduced by differential thermal expansion. In addition, the cathode cover configuration allows for less expensive cathode plates, including modular cathode plates. Such plates can be adjusted relative to the cathode-cathode gap to prolong the life of a given cathode plate and maintain source performance requirements. A cathode plate in a linear section of an ion source has symmetrical edges and can, therefore, be flipped over to exchange the first (worn) cathode edge with the second (unworn) cathode edge.
David Matthew Burtner - Fort Collins CO, US Scott A. Townsend - Fort Collins CO, US Daniel E. Siegfried - Fort Collins CO, US Viacheslav V. Zhurin - Fort Collins CO, US
An ion source is cooled using a cooling plate that is separate and independent of the anode. The cooling plate forms a coolant cavity through which a fluid coolant (e. g. , liquid or gas) can flow to cool the anode. In such configurations, the magnet may be thermally protected by the cooling plate. A thermally conductive material in a thermal transfer interface component can enhance the cooling capacity of the cooling plate. Furthermore, the separation of the cooling plate and the anode allows the cooling plate and cooling lines to be electrically isolated from the high voltage of the anode (e. g. , using a thermally conductive, electrically insulating material). Combining these structures into an anode subassembly and magnet subassembly can also facilitate assembly and maintenance of the ion source, particularly as the anode is free of coolant lines, which can present some difficulty during maintenance.
Daniel E. Siegfried - Fort Collins CO, US David Matthew Burtner - Fort Collins CO, US Scott A. Townsend - Fort Collins CO, US Valery Alexeyev - Moscow, RU
A modular ion source design relies on relatively short modular core ALS components, which can be coupled together to form a longer ALS while maintaining an acceptable tolerance of the anode-cathode gap. Many of the modular components may be designed to have common characteristics so as to allow use of these components in ion sources of varying sizes. A flexible anode can adapt to inconsistencies in the ion source body and module joints to hold a uniform anode-cathode gap along the length of the ALS. A clamp configuration fixes the cooling tube to the ion source body, thereby avoiding heat-introduced warping to the source body during manufacturing.
A thermal control plate is easily removable and replaceable in an ion source. The ion source has a removable anode assembly, including the thermal control plate, that is separable and from a base assembly to allow for ease of servicing consumable components of the anode assembly. The thermal control plate may support a gas distributor and an anode in the anode assembly. The thermal control plate may have a port for passing working gas from one side of the thermal control plate to the other. An interface surface on the thermal control plate may have a pattern of recesses to allow the working gas to disperse underneath the gas distributor.
An ion source has a removable anode assembly that is separable and from a base assembly to allow for ease of servicing the consumable components of the anode assembly. Such consumables may include a gas distributor, a thermal control plate, an anode, and one or more thermal transfer sheets interposed between other components. A pole piece and a cathode may also be part of the anode assembly. The anode assembly may be attached to the base assembly via the pole piece.
A gas distributor is easily removable and replaceable in an ion source. The ion source has a removable anode assembly, including the gas distributor, that is separable and from a base assembly to allow for ease of servicing consumable components of the anode assembly. The gas distributor may be mounted to a thermal control plate in the anode assembly with several set screws. The gas distributor may be disk-shaped with counterbores in a surface to recess the heads of the set screws. Alternately, the gas distributor may be clamped or held in place by other structures or components of the ion source.
One or more thermal transfer sheets are easily removable and replaceable in an ion source. The ion source has a removable anode assembly, including the thermal transfer sheets, that is separable and from a base assembly to allow for ease of servicing consumable components of the anode assembly. The thermal transfer sheets may be interposed between the consumable components within the anode assembly. The thermal transfer sheets may be thermally conductive and either electrically insulating or conductive.
Grid Transparency And Grid Hole Pattern Control For Ion Beam Uniformity
Ikuya Kameyama - Fort Collins CO, US Daniel E. Siegfried - Fort Collins CO, US
Assignee:
Veeco Instruments, Inc. - Woodbury NY
International Classification:
G06F 17/50
US Classification:
703 2, 703 7, 716 21, 355 67
Abstract:
A design process for varying hole locations or sizes or both in an ion beam grid includes identifying a control grid to be modified; obtaining a change factor for the grid pattern; and using the change factor to generate a new grid pattern. The change factor is one or both of a hole location change factor or a hole diameter change factor. Also included is an ion beam grid having the characteristic of hole locations or sizes or both defined by a change factor modification of control grid hole locations or sizes or both.
