John M. Evans - Piqua OH Glenn D. Perrine - Eaton OH David V. Flaugher - Beavercreek OH
Assignee:
Stanhope Products Company - Brookville OH
International Classification:
B01D 5304
US Classification:
96135, 96147, 96154
Abstract:
A desiccant cartridge retention device used to secure desiccant cartridges ( ) to fluid flow tubes ( ) and/or canisters ( ) of receiver/dryer and accumulator assemblies ( ). Desiccant cartridge ( ) includes a cup ( ) extending along an axis ( ) and having spaced inner and outer wall portions ( ) connected by a transverse portion ( ) to define a chamber ( ) having an opening ( ) for receiving desiccant particles ( ). The inner wall portion ( ) defines a sleeve ( ) having first and second openings ( ) and further comprises an outer surface ( ) and an inner engagement surface ( ). The sleeve ( ) is adapted to receive and the inner engagement surface ( ) is adapted to cooperate with fluid flow tube ( ) such that the desiccant cartridge ( ) is secured thereto forming a proper seal therebetween. Outer wall portion ( ) includes a flange adapted to provide a snug compression fit within canister ( ) such that the desiccant container ( ) also is secured thereto. A cap ( ) is secured to the cup ( ) to secure the desiccant ( ) inside the chamber ( ).
Polypropylene Or Polyester Plastic Desiccant Cartridge With Fiberglass Filter And Bead Cage Ends
David V. Flaugher - Beavercreek OH, US Glen D. Perrine - Eaton OH, US John M. Evans - Piqua OH, US
Assignee:
Flow Dry Technology Ltd - Brookville OH
International Classification:
F25D 23/00
US Classification:
62271, 62 85, 62474
Abstract:
A desiccant container () which comprises a generally cylindrically cross-sectioned cup, two dual-density fiberglass discs (), desiccant material (), and a cap (). The cup includes an outer annular portion, an inner tubular portion, and a bottom which connect together to define a space within. The cap () has a planar portion with an aperture for receiving the inner wall portion of the cup and is designed for receipt in the chamber to cover the opening. The cap further includes an outer annular rim portion extending transversely from the planar portion. The peripheral flange portion having tabs with an edge portion which permit the cap to cooperate with the outer wall portion having tabs with an edge portion which permit the cap to cooperate with the outer wall portion so that the cap can be retained within the chamber in one of a number of axially spaced positions to prevent shifting of, and escape of the desiccant.
This invention relates to a desiccant cartridge () adapted for use in a canister () of an integrated receiver/dryer or accumulator assembly of an automotive air conditioning system wherein the canister () has an offset inlet port (). The desiccant cartridge () includes a desiccant cup () having a center tube () and a desiccant cap () including a planar portion () having a recessed port area () provided with a first aperture (), or first tube (), for cooperation with a side tube () and/or the offset inlet port () of the canister (). The cap () further includes a docking piece () provided with a second aperture (), or second tube (), for cooperating with the center tube () of the cup () when the cap () is retained therein. Notably, the docking piece () is designed to cooperate with the recessed port area (), preferably via a snap fit, to define a passageway () therebetween so that gas and/or fluid can enter the canister () via the inlet port (), circulate through the desiccant cartridge (), and finally exit via an outlet port ().
Desiccant Cartridge For An Integrated Condenser/Receiver And Method Of Making Same
John M. Evans - Piqua OH, US David V. Flaugher - Beavercreek OH, US Douglas E. LeConey - Clayton OH, US Glenn D. Perrine - Eaton OH, US
Assignee:
Flow Dry Technology, Inc. - Washington DC
International Classification:
F25B 43/00
US Classification:
62474, 62509
Abstract:
In accordance with one preferred embodiment, a desiccant cartridge () for insertion into an integrated condenser/receiver () comprises a rigid stand-off member () and a porous desiccant bag (). The preferred rigid stand-off member comprises spaced inner and outer pad portions and an elongated stand-off portion terminating in the inner pad portion. The inner pad may include a tab portion. The porous desiccant bag is positioned between the inner and outer pad portions and affixed to one or both of the inner and outer pad portions. A rigid cap with a plurality of holes may be provided to which a second end of the porous desiccant bag may be attached. The porous desiccant bag includes first and second flat end seals, one of which is secured to attachment tab portions.
Douglas E. LeConey - Clayton OH, US John M. Evans - Piqua OH, US David V. Flaugher - Beavercreek OH, US
Assignee:
Flow Dry Technology, Inc. - Brookville OH
International Classification:
B01D 53/02
US Classification:
96134, 96135, 96136, 96147, 55514
Abstract:
Desiccant bag and filter assembly adapted for insertion into an integrated condenser dryer chamber of a vehicle or mobile air conditioning system or the like. A support member () lies along the exterior of a desiccant containing pouch () with the pouch secured at both of its longitudinal ends to the support. A filter member is integral with the assembly and positioned at one end of the pouch. Rigid stand off members () are positioned at respective ends of the assembly.
Desiccant Container Having Cap Retaining Nib Segments
A container for particulate desiccant comprises a cup and a cap. The cup includes spaced inner and outer wall portions connected by a transverse web portion to define a chamber having an opening. The cap is designed for receipt in the chamber to cover the opening. In addition, the cap has a hole for receiving the inner wall portion of the cup. The outer wall portion includes a number of nib segments which are arranged into axially spaced nib groupings. The nib segments within each of the nib groupings are circumferentially spaced-apart. The cap includes an edge portion which permits the cap to be retained between axially adjacent nib groupings thus retaining the cap within the chamber in one of a number of axially spaced positions.
David Flaugher - Beavercreek OH Douglas E. LeConey - Clayton OH Glenn Perrine - Eaton OH Raymond B. Wood - Brookville OH
Assignee:
Stanhope Products Company - Brookville OH
International Classification:
F26B 2106
US Classification:
34 80
Abstract:
A container is provided for housing desiccant material therein and for facilitating fluid flow therethrough to a surrounding environment. The container comprises a cup member including a base or bottom wall member and a generally cylindrically shaped outer wall connected to the base or bottom wall member to thereby define a housing. A plurality of openings extend through the outer wall and provide communication between the housing and the surrounding environment. At least one recessed, relief portion is provided in communication with one of the openings. The recessed, relief portion has an outer diameter dimension less than the outer diameter dimension of the cup member. Accordingly, when the cup is snugly received in an associated canister or the like, a relief area is formed that defines a fluid flow channel along the interface of the cup member and canister.
Desiccant Container Having Mount For Canister Tube And Inner Wall Extension Portion
David Flaugher - Beavercreek OH Glenn Perrine - Eaton OH Stephen F. Sullivan - Boardman OH Raymond B. Wood - Brookville OH
Assignee:
Stanhope Products Company - Brookville OH
International Classification:
B01D 5304
US Classification:
96135
Abstract:
A container for particulate desiccant comprises a cup and a cap. The cup includes spaced inner and outer wall portions connected by a transverse web portion to define a chamber having an opening for receiving the desiccant. The cap is designed for receipt in the chamber to cover the opening. In addition, the cap has a hole for receiving the inner wall portion of the cup. The inner wall portion includes a stepped inner surface defining an intermediate flange for preventing a canister pipe from passing completely through the inner wall portion. The inner wall portion also includes a beveled inner end surface which tapers radially inwardly in a direction toward the transverse web portion to facilitate insertion of the canister pipe into the inner wall portion. An inner wall extension portion is coaxially joined with the inner wall portion at a web side of the cup to facilitate return of dehydrated air or fluid to an air conditioning system. The canister pipe, inner wall portion and inner wall extension portion cooperate to define a return passage for the dehydrated air or fluid that passes over the desiccant in the chamber.
