David R Taeusch

US Patent:

48576964, Aug 15, 1989

Filed:

Apr 22, 1988

Appl. No.:

7/185128

Inventors:

David R. Taeusch - Ypsilanti MI
Clinton J. Wohlmuth - Columbus IN

Assignee:

Raycon Textron Inc. - Ann Arbor MI

International Classification:

B23K 2600

US Classification:

2191217

Abstract:

A process and apparatus for drilling precision small diameter holes in fuel nozzle parts includes the process of directing a laser beam against the nozzle part at a first hole drilling station to form an undersized hole therethrough and thereafter positioning the nozzle part with the laser hole formed therethrough in alignment with a wire electrode of an electrical discharge machine and controlling the energy input to the electrode wire and advancing it with respect to the preformed laser hole so as to form a precision hole diameter and surface finish throughout the length of the laser beam formed hole as EDM particles are flushed through a flow path defined by the laser hole from one face to the opposite face of a part wall.
