International Business Machines Corporation - Armonk NY
International Classification:
G06K 956 G06K 964
US Classification:
382149
Abstract:
An advanced manufacturing inspection system includes a database containing a rasterized reference image of the product inspected at the inspection resolution, allowing for accurate representation of shaped features. The full image is stored in the system database and is accessed and fed in a raster manner to an electronic registration subsystem which aligns the reference data to the incoming thresholded product inspection data. The aligned reference and inspection data are driven to all parallel defect detection channels. A classifier block selects the output of the desired channels for recording into a defect memory. Alternatively, the thresholding of the inspection gray scale signal is done after registration such that thresholding can be controlled by the reference data. The system is flexible in rendering abnormalities between reference and gray scale inspection images and functions independently of image resolution because the reference and inspection images are of the same resolution. The defects to be rendered are dependent upon that specified by the product designers and the process engineers.
International Business Machines Corporation - Armonk NY
International Classification:
G06F 1500
US Classification:
395140
Abstract:
An image data processing circuit achieves high speed by storing precomputed values for each combination of pairs or groups of inputs at each of a normalization, parabola fitting, arbitration, selection and anti-aliasing stages. Normalization of input values, possibly together with data truncation, as a first stage permits the use of small memories having identical contents in each stage of the processor.
Mark A. Casparian - Poughkeepsie NY Donald C. Forslund - Wappingers Falls NY
Assignee:
International Business Machines Corporation - Armonk NY
International Classification:
G06K 932
US Classification:
382 44
Abstract:
An apparatus and method electronically registers or aligns ideal raster data to real raster data for subsequent processes such as inspection systems and image processing systems. The electronic image registration system receives ideal and real images in scrolling buffers wide enough to hold the width of the image and high enough to hold the difference in a skewed image. In other words, the real and ideal upper corners must be contained within the buffers for any possible kind of misalignment or distortion. Each buffer has a selector to randomly access frames of image in the vertical direction. Each buffer image frame is moved horizontally out of its lower swath and into its new position in the next upper swath. Horizontal movement of each buffer is independent, such that adjustable sequential access in the horizontal direction is available. The real image stream buffer selector addressing and clocking are held fixed during the registration phase, while the ideal image stream buffer selector address and clocking are in constant adjustment.
Apparatus And Method For Raster Generation From Sparse Area Array Output
International Business Machines Corporation - Armonk NY
International Classification:
G06F 1200 G06F 1562
US Classification:
39542107
Abstract:
A camera image data processor provides scan conversion at extremely high speed while allowing static and dynamic correction of image data particularly for a high data output rate CCD image transducer in a confocal imaging system for automated optical inspection in manufacturing processes. Scan conversion and data collation is accomplished at bit rates in excess of 1 Gigabyte by accessing a double buffer memory with different sequences of addresses covering a field of an image corresponding to a field in the memory during read and write operations. Highly parallel output is provided for confocal height data in a raster line by providing a delay equal to an integral multiple of the access time for a field for each confocally imaged height within a sample.
Ion Milling End Point Detection Method And Apparatus
William Harrington Brearley - Poughkeepsie NY Donald Charles Forslund - Wappingers Falls NY Douglas William Ormond - Wappingers Falls NY Gerald Joseph Sliss - Poughkeepsie NY
Assignee:
International Business Machines Corporation - Armonk NY
International Classification:
H01L 21306 G01N 2100
US Classification:
1566261
Abstract:
An ion milling end point detection method for etching coated substrates is disclosed comprising the use of a light measurement of light passing through a monitor substrate (e. g. , glass coated with the same material at about the same thickness as the coated substrate to be etched) during the milling process, comparing the light values with a reference value and determining the end point of the milling process based on said values. Coated and uncoated monitor substrates may also be employed together and the values compared to determine the end point. An apparatus for determining the end point of an ion milling process is also disclosed.
