Douglas Thomas Resch

US Patent:

6612740, Sep 2, 2003

Filed:

Mar 24, 2000

Appl. No.:

09/533868

Inventors:

Douglas T. Resch - Rochester NY
Bruce W. Konte - Pittsford NY
Edgar G. Earnhart - Hilton NY
Scott H. Schwallie - Rochester NY
Michael R. McGovern - Rochester NY

Assignee:

Eastman Kodak Company - Rochester NY

International Classification:

A61B 614

US Classification:

378169

Abstract:

An intraoral x-ray film packet is taught which has an outer envelope wherein one of the two opposing outer sheets is more rigid than the other such that it has a tensile modulus of at least about 700 Kg/cm. This is preferably accomplished by making both sheets from a thermoplastic material such as PVC and reducing the amount of plasticizer in the more rigid of the two sheets to less than 30%. A continuous perimetric seal is formed affixing the two outer sheets together and forming a perimetric laminated edge which is substantially coplanar with the more rigid of the two sheets. A film chip resides between the two outer sheets. A comfort-enhancing perimetric edge bead is injection molded directly onto the perimetric laminated edge.

US Patent:

6474864, Nov 5, 2002

Filed:

Mar 24, 2000

Appl. No.:

09/534516

Inventors:

Douglas T. Resch - Rochester NY
Bruce W. Konte - Pittsford NY
Edgar G. Earnhart - Hilton NY
Edward B. Richter - Rochester NY
Scott H. Schwallie - Rochester NY
Gary E. Merz - Rochester NY
Michael R. Mcgovern - Rochester NY

Assignee:

Eastman Kodak Company - Rochester NY

International Classification:

A61B 614

US Classification:

378169, 378168

Abstract:

An intraoral x-ray film packet is taught which has an outer envelope wherein one of the two opposing outer sheets is more rigid than the other and serves as a stiffening sheet such that it has a tensile modulus of at least about 700 Kg/cm. This is preferably accomplished by making both sheets from a thermoplastic material such as PVC and reducing the amount of plasticizer in the more rigid of the two sheets to less than 30%. A continuous perimetric seal is formed affixing the two outer sheets together and forming a perimetric laminated edge which is substantially coplanar with the more rigid of the two sheets. A film chip resides between the two outer sheets. The coplanar perimetric laminated edge and the added rigidity aid in improving accurate sizing of each individual packet and prevention of deflection of the marginal area of individual packets in subsequent operations.
