Edward C Korsberg

US Patent:

7366774, Apr 29, 2008

Filed:

Jan 31, 2003

Appl. No.:

10/357184

Inventors:

Anthony Gerard Gibart - New Berlin WI, US
David A. Vasko - Macedonia OH, US
Paul G. Kucharski - Waukesha WI, US
Joseph A. Lenner - Hudson OH, US
Edward C. Korsberg - Solon OH, US

Assignee:

Rockwell Automation Technologies, Inc. - Mayfield Heights OH

International Classification:

G06F 15/173
G06F 11/00

US Classification:

709224, 370253, 370522, 370 13, 370 14

Abstract:

A high reliability network provides for measurements of network delays through pairs of transmissions of local clock values used in a first message to deduce clock value offsets and in a second message to reveal network delays.

US Patent:

7930041, Apr 19, 2011

Filed:

Sep 29, 2008

Appl. No.:

12/240462

Inventors:

Edward C. Korsberg - Solon OH, US
David A. Vasko - Solon OH, US
Darren R. Klug - Willoughby OH, US
Petr Ptacek - Chagrin Falls OH, US

Assignee:

Rockwell Automation Technologies, Inc. - Mayfield Heights OH

International Classification:

G05B 11/01
G06F 13/00

US Classification:

700 19, 700 3, 700 14, 710110

Abstract:

An industrial control system communicating among various control elements via a serial network synchronizes the scanning loops associated with collecting and forwarding data along the network so as to substantially reduce transmission delay and jitter, using synchronization information passed along the network.

US Patent:

57376263, Apr 7, 1998

Filed:

Mar 14, 1996

Appl. No.:

8/616999

Inventors:

Kenwood H. Hall - Stow OH
David A. Vasko - Macedonia OH
Edward Korsberg - Solon OH
Michael S. Pelley - Cleveland OH

Assignee:

Allen-Bradley Company, Inc. - Milwaukee WI

International Classification:

G06F 1300
G06F 1314

US Classification:

39580001

Abstract:

A communication network for an industrial control system permits multiple masters and complex network topologies by transmitting data as packets through paths of nodes on the networks. The packets containing data are preceded by an OPEN message which pre-configured each node with the necessary information to process the stream of succeeding packets in an efficient manner and thus to reduce the necessary overhead in the transmission of each data packet. Each node receiving the OPEN message evaluates its resources and if those resources are insufficient to reliably handle the indicated packets, a message is returned to the originating node indicating that a connection cannot be formed.

US Patent:

20180248799, Aug 30, 2018

Filed:

Apr 30, 2018

Appl. No.:

15/966985

Inventors:

- Mayfield Heights OH, US
Jonathan D. Bradford - Harpersfield OH, US
Anthony G. Gibart - New Berlin WI, US
Kenwood H. Hall - Hudson OH, US
Kendal R. Harris - Mentor OH, US
Raymond R. Husted - Middlefield OH, US
Edward C. Korsberg - Solon OH, US
Gregory A. Majcher - Broadview Heights OH, US
Scott A. Pierce - Concord Township OH, US
Gregg M. Sichner - Mentor OH, US
Patrick D. Telljohann - Solon OH, US
Robert J. Kretschmann - Bay Village OH, US

International Classification:

H04L 12/741
H04L 12/437
H04L 12/417
H04L 12/407
G05B 19/418

Abstract:

A method and system for interacting with data frames passing through a module connected to an industrial network is disclosed. Each module includes an aggregation unit located on the network interface above the physical layer. To transmit data, the aggregation unit reads a header from a dynamic data packet to determine if the module is a participant module for the packet. If so, the aggregation unit inserts data from the module into the data packet and transmits the packet to another module. To receive data, the aggregation unit reads a header from the data packet to determine whether the data. packet includes data for the module. If so, the aggregation unit reads the data and passes the data packet to another module. If the aggregation unit determines that a data packet is not intended for the module, the data packet is passed to another module with no further interaction.

US Patent:

20160294692, Oct 6, 2016

Filed:

Mar 30, 2016

Appl. No.:

15/084661

Inventors:

- Mayfield Heights OH, US
Jonathan D. Bradford - Harpersfield OH, US
Anthony G. Gibart - New Berlin WI, US
Kenwood H. Hall - Hudson OH, US
Kendal R. Harris - Mentor OH, US
Raymond R. Husted - Middlefield OH, US
Edward C. Korsberg - Solon OH, US
Gregory A. Majcher - Broadview Heights OH, US
Scott A. Pierce - Concord Township OH, US
Gregg M. Sichner - Mentor OH, US
Patrick D. Telljohann - Solon OH, US
Robert J. Kretschmann - Bay Village OH, US

International Classification:

H04L 12/741
G05B 19/418

Abstract:

A method and system for interacting with data frames passing through a module connected to an industrial network is disclosed. Each module includes an aggregation unit located on the network interface above the physical layer. To transmit data, the aggregation unit reads a header from a dynamic data packet to determine if the module is a participant module for the packet. If so, the aggregation unit inserts data from the module into the data packet and transmits the packet to another module. To receive data, the aggregation unit reads a header from the data packet to determine whether the data packet includes data for the module. If so, the aggregation unit reads the data and passes the data packet to another module. If the aggregation unit determines that a data packet is not intended for the module, the data packet is passed to another module with no further interaction.

US Patent:

20160283427, Sep 29, 2016

Filed:

Mar 24, 2016

Appl. No.:

15/079873

Inventors:

- Mayfield Heights OH, US
Gregory A. Majcher - Broadview Heights OH, US
Robert J. Kretschmann - Bay Village OH, US
Sivaram Balasubramania - Solon OH, US
Kendal R. Harris - Mentor OH, US
Edward C. Korsberg - Solon OH, US

International Classification:

G06F 13/40
G06F 13/42

Abstract:

A method and system for assigning slot addresses to modules in an industrial control system is disclosed. The modules are set up in a daisy chain topology. On power-up, a first module in the chain reads its slot address from a user configurable input or sets its slot address to a default value. The first module communicates to its immediate right neighbor using a special, one-hop message. The neighboring modules communicate to receive each other's information. The first module then sets an enable signal between the modules and sends a slot number to the neighbor in a firmware message. The neighbor checks if the enable signal is set and verifies that the slot number is a valid slot number. If so, then the neighboring module accepts the slot and repeats the same procedure to its next immediate neighbor, and so on until the last module.
