Edward Louis Taylor

US Patent:

6342264, Jan 29, 2002

Filed:

Oct 29, 1999

Appl. No.:

09/429993

Inventors:

John M. Raterman - Atlanta GA
Edward C. Taylor - Cumming GA
John E. Jackson - Alpharetta GA

Assignee:

Nordson Corporation - Westlake OH

International Classification:

B05D 102

US Classification:

427 8, 4272071, 427261, 427421

Abstract:

A method and apparatus for dispensing material, including adhesives, onto a substrate, including boxes and cartoons. A first and second dispenser are either operated in a dispense and standby mode or both dispense at least a portion of the dispensed pattern. The detection of a failure of one of the dispensing guns causes the other gun to dispense the complete pattern while de-activating the failed gun thereby maintaining production.

US Patent:

7084377, Aug 1, 2006

Filed:

Oct 31, 2003

Appl. No.:

10/698312

Inventors:

John M. Raterman - Atlanta GA, US
Edward C. Taylor - Cumming GA, US

Assignee:

Nordson Corporation - Westlake OH

International Classification:

H05B 1/02

US Classification:

219481, 219497, 219508, 392479

Abstract:

A device for carrying a heated liquid, and controlling the temperature of the heated liquid includes a liquid conveying element including a passage for carrying the heated liquid. First and second temperature sensing devices are operatively associated with the liquid conveying element to sense the temperature of the heated liquid. A controller is actively connected to the first temperature sensing device. The first temperature sensing device thereby senses the temperature of the heated liquid in the passage and conveys the temperature information or readings to the controller for use in the heater control. The second temperature sensing device is capable of being actively connected to the controller upon failure or malfunction of the first temperature sensing device.

US Patent:

8171973, May 8, 2012

Filed:

Jan 29, 2008

Appl. No.:

12/021547

Inventors:

Charles P. Ganzer - Cumming GA, US
Edward C. Taylor - Cumming GA, US
Leslie J. Varga - Cumming GA, US

Assignee:

Nordson Corporation - Westlake OH

International Classification:

B29C 47/12

US Classification:

156500, 15624411, 156578, 425192 R, 425380, 425464, 222478, 222525, 118315

Abstract:

A nozzle for dispensing molten thermoplastic material includes non-circular outlets spaced apart from one another in a predetermined pattern. The nozzle may be used to dispense patterns of adhesive that form closed geometric shapes, such as for use in making hermetic seals.

US Patent:

20050093295, May 5, 2005

Filed:

Oct 31, 2003

Appl. No.:

10/698274

Inventors:

David Byerly - Lawrenceville GA, US
Edward Taylor - Cumming GA, US

Assignee:

Nordson Corporation - Westlake OH

International Classification:

F16L027/04

US Classification:

285261000

Abstract:

A hydraulic swivel fitting for establishing a fluid connection with a liquid dispenser. The swivel fitting includes a fluid cavity housing a socket assembly, a ball member that rotates and tilts within the socket assembly, and a stem that is received within a bore in the ball member with a liquid-tight seal. The stem is movable within the bore so that axial forces applied to a supply conduit coupled with the stem are not transferred to the ball member. Instead, such axial forces are diverted from the stem to the housing of the swivel member and, subsequently, transferred from the housing to the liquid dispenser.

US Patent:

20120286072, Nov 15, 2012

Filed:

Dec 7, 2010

Appl. No.:

13/511058

Inventors:

Laurence B. Saidman - Duluth GA, US
Edward C. Taylor - Cumming GA, US

Assignee:

NORDSON CORPORATION - Westlake OH

International Classification:

B05B 1/30

US Classification:

2395331

Abstract:

A force amplifying driver system including an actuator () with a powered actuating member () mounted for movement along a first distance “X”. A driven member () mounted for movement along a second distance or working distance “Y” which is less than the first distance “X”. The powered actuating member () is movable through a gap “Z” before being mechanically coupled with the driven member () and subsequently moves with the driven member () along the second distance “Y”. Energy is transferred from the powered actuating member () to the driven member () along the second or working distance “Y”. The force amplifying driver system may be used for actuating a fluid jetting dispenser ().

US Patent:

20120292405, Nov 22, 2012

Filed:

Jan 7, 2011

Appl. No.:

13/516037

Inventors:

Steve Clark - Cumming GA, US
John M. Riney - Buford GA, US
Daniel T. Smulders - Cumming GA, US
Edward C. Taylor - Cumming GA, US

Assignee:

NORDSON CORPORATION - Westlake OH

International Classification:

B05B 1/28

US Classification:

239291

Abstract:

An apparatus for jetting liquid material in desired patterns includes a jetting module that is couplable to a source of liquid material A piston is disposed for movement within an interior chamber to rapidly develop high pressure within the module so that liquid material is jetted from through a pattern plate in a desired pattern.

US Patent:

20120312838, Dec 13, 2012

Filed:

Jan 7, 2011

Appl. No.:

13/515610

Inventors:

Justin A. Clark - Sugar Hill GA, US
John M. Riney - Buford GA, US
Edward C. Taylor - Cumming GA, US

Assignee:

Nordson Corporation - Westlake OH

International Classification:

B67D 7/80
B67D 3/00

US Classification:

2221465, 222 1, 222504

Abstract:

In one aspect, an adhesive dispensing system includes a dispensing module having an inlet and an outlet, a supply of hot melt adhesive maintained at low pressure, and a low pressure liquid passageway communicating between the supply and the inlet of the dispensing module . Liquid material is received through the inlet at a low pressure, and the dispensing module rapidly develops high pressure at the outlet to jet the liquid material from the outlet . In another aspect, an apparatus for jetting liquid material includes a dispenser body having a liquid chamber . A piston is movably disposed within the liquid chamber , from a position wherein a piston tip is spaced from a complimentary shaped recess , to a position wherein the piston tip effectively seals off the recess , then to a position wherein the piston tip is received within the recess to displace a discrete volume of liquid material from the recess

US Patent:

61233021, Sep 26, 2000

Filed:

Oct 30, 1998

Appl. No.:

9/183518

Inventors:

Edward C. Taylor - Cumming GA

Assignee:

Nordson Corporation - Westlake OH

International Classification:

A47B 9606

US Classification:

24823161

Abstract:

A uniaxial mounting for dispensing apparatus includes one or more uniaxial connecting portions on a dispenser and at least one support member having at least one complementary uniaxial mounting portion. The uniaxial mounting portions may include projections and generally complementary channels allowing rapid installation, removal and replacement of the dispenser. The support member may include a locking pivot for further adjustment capability. When dispensing heated liquids, a thermal insulator is incorporated to reduce heat conduction between the dispenser and the support member. The uniaxial mounting may have an alignment guide to ensure proper positioning of the dispenser along the axis of engagement between the uniaxial connecting portions.
