Eric J Johannsen

US Patent:

7877977, Feb 1, 2011

Filed:

Dec 12, 2008

Appl. No.:

12/314591

Inventors:

Eric James Johannsen - Washington IL, US
Kevin Lee Steiner - Tremont IL, US
Donovan Stuart Clarke - Hanna City IL, US
Jeffrey Paul Nash - Peoria IL, US
Jennifer Ann Brooks - Germantown Hills IL, US
Roger L. Recker - Dunlap IL, US

Assignee:

Caterpillar Inc. - Peoria IL

International Classification:

B62D 55/205
B62D 55/092

US Classification:

59 78, 305186, 59 351

Abstract:

A master link for a chain assembly is provided. The master link includes a body member with a first side, a second side positioned opposite the first side, a shoe surface configured to receive a track shoe, and a rail surface positioned opposite the shoe surface. The master link also includes first and second apertures extending through the body member from the first side to the second side and third and fourth apertures located between the first and second apertures. The master link also includes a strut member dividing the third and fourth apertures. The master link also includes a first gap located in the body member and extending from the first aperture to the third aperture and a second gap located in the body member and extending from the fourth aperture to the second aperture. The master link further includes a third gap located in the strut member and extending from the third aperture to the fourth aperture.

US Patent:

7959239, Jun 14, 2011

Filed:

Mar 25, 2008

Appl. No.:

12/076907

Inventors:

Mark Steven Diekevers - Metamora IL, US
Eric James Johannsen - Washington IL, US
Richard Edward Livesay - Peoria IL, US
Kevin Lee Steiner - Tremont IL, US

Assignee:

Caterpillar Inc. - Peoria IL

International Classification:

B62D 55/21

US Classification:

305104, 305106, 305202

Abstract:

A track assembly for a track-type machine is disclosed. The track assembly includes inner and outer track links. A rotatable bushing is positioned about a track pin and a sleeve bearing is positioned about the track pin. A first seal member is disposed between an inner track link and the rotatable bushing and a second seal member is disposed between inner and outer track links. A first thrust ring is engaged with the rotatable bushing and a second thrust ring is engaged with the sleeve bearing. A first contact member is engaged with the first seal member and a second contact member is engaged with the second seal member. The first and second contact members are configured to inhibit wear of the first and second seal members.

US Patent:

8336970, Dec 25, 2012

Filed:

Dec 16, 2008

Appl. No.:

12/314750

Inventors:

Eric James Johannsen - Washington IL, US
Mark Steven Diekevers - Germantown Hills IL, US

Assignee:

Caterpillar Inc. - Peoria IL

International Classification:

B62D 55/205

US Classification:

305201, 305198

Abstract:

A link for a track-type machine is disclosed. The link may have a body portion. The link may also have an aperture extending through the body portion. The aperture may have a cylindrical portion. Additionally, the aperture may have an annular groove formed in the cylindrical portion. The aperture may also have a tapered portion. The tapered portion may abut the cylindrical portion, and may taper toward the cylindrical portion.

US Patent:

8360535, Jan 29, 2013

Filed:

Nov 17, 2009

Appl. No.:

12/616224

Inventors:

Eric J. Johannsen - Washington IL, US
Daniel D. Angot - Peoria IL, US
Ming Zhang - Spring TX, US
Xiangyang Jiang - Dunlap IL, US
Constant B. Bissahoyo - Peoria IL, US
Alexander H. Hays - Peoria IL, US
Anthony Snyder - Canton IL, US

Assignee:

Caterpillar Inc. - Peoria IL

International Classification:

B62D 55/096

US Classification:

305137, 305194

Abstract:

An idler having an axis of rotation. The idler may include a hub with a flange. A plurality of rim members are positioned along a perimeter of the flange and have generally axially facing, opposite side surfaces. At least one of the side surfaces has a first interlocking formation. A clamping plate is connected to the flange. The clamping plate has a second interlocking formation coupled with the first interlocking formation. A dampening member interposes the first and second interlocking formations.

US Patent:

8613486, Dec 24, 2013

Filed:

Nov 4, 2010

Appl. No.:

12/939537

Inventors:

Eric J. Johannsen - Washington IL, US
Mark S. Diekevers - Metamora IL, US

Assignee:

Caterpillar Inc. - Peoria IL

International Classification:

B62D 55/12
B21L 3/00

US Classification:

305201, 305118, 305198

Abstract:

A bushing for use in a tracked undercarriage of a track-type machine includes a first end and a second end disposed opposite the first end. An outer surface extends between the first end and the second end and is shaped to engage a sprocket of the tracked undercarriage. The bushing also includes an annular inner surface disposed between the first end and the second end defining an internal cavity shaped to receive a track pin. An innermost portion of the inner surface forms a crown having a radius less than or equal to (PL)/[(24EπDR)(1−cos [(PL)/(16EπDR))] where L is the length of the bushing, P is the weight of the track-type machine, E is the Modulus of Elasticity of the bushing, and Ris a radius of the innermost portion of the annular internal cavity.

US Patent:

20060284485, Dec 21, 2006

Filed:

Jun 20, 2005

Appl. No.:

11/156377

Inventors:

Eric Johannsen - East Peoria IL, US
Mark Diekevers - Metamora IL, US
Michael Hasselbusch - Metamora IL, US

International Classification:

F16P 1/00

US Classification:

305203000

Abstract:

A cartridge bearing assembly for a track chain of a track type work machine is provided. The cartridge bearing assembly includes axial/radial load bearing insert members positioned about a pin, and a rotatable bushing positioned therebetween. Crowned sleeve bearings are disposed between the insert members and the pin, as well as between the pin and the rotatable bushing. Collars are disposed at opposite ends of the pin and fixedly coupled thereto, trapping the other components of the cartridge assembly therebetween. A method of operating a track type work machine is further provided, including reducing wear between coupled track links by reacting axial loads via insert members positioned about a track pin.

US Patent:

20110243648, Oct 6, 2011

Filed:

Mar 30, 2011

Appl. No.:

13/076294

Inventors:

ERIC J. JOHANNSEN - WASHINGTON IL, US
ROGER L. RECKER - DUNLAP IL, US
JASON L. SEBRIGHT - CHILLICOTHE IL, US
MARK J. KIESEL - PEORIA IL, US
GUANGHUI LIANG - Dunlap IL, US
MARK DIEKEVERS - Metamora IL, US

Assignee:

CATERPILLAR INC. - PEORIA IL

International Classification:

F16C 11/04
F16J 15/16
F16J 15/32

US Classification:

403119, 277503

Abstract:

A seal assembly can be incorporated into a track pin joint assembly including a pin defining a longitudinal axis, a first member and a second member both coaxial with the pin about the longitudinal axis. The first member is pivotable about the longitudinal axis with respect to the second member and includes a load ring engagement surface defining a seal cavity disposed in proximal relationship to the second member. A seal assembly including a seal ring and a load ring is disposed in the seal cavity and sealingly engages the first and second members. An axial segment of a seal ring engagement surface of the load ring extends over at least half the length, measured along the longitudinal axis, between a radial segment of the seal ring engagement surface and a radial segment of a first member engagement surface of the load ring. At least one of a load ring engagement surface of the first member and an axial segment of the first member engagement surface of the load ring includes a convex rounded portion.

US Patent:

20110254364, Oct 20, 2011

Filed:

Mar 30, 2011

Appl. No.:

13/076191

Inventors:

ERIC J. JOHANNSEN - WASHINGTON IL, US
ROGER L. RECKER - DUNLAP IL, US
JASON L. SEBRIGHT - CHILLICOTHE IL, US
MARK J. KIESEL - PEORIA IL, US
GUANGHUI LIANG - DUNLAP IL, US
MARK DIEKEVERS - METAMORA IL, US

Assignee:

CATERPILLAR INC. - PEORIA IL

International Classification:

B62D 55/21
B62D 55/15
F16J 15/34

US Classification:

305100, 277377

Abstract:

A seal assembly can be incorporated into a track pin joint assembly including a pin defining a longitudinal axis, a first member and a second member both coaxial with the pin about the longitudinal axis. The first member is pivotable about the longitudinal axis with respect to the second member and includes a load ring engagement surface defining, at least in part, an axially-extending seal cavity disposed in proximal relationship to the second member. A seal assembly including a seal ring and a load ring is disposed in the seal cavity and sealingly engages the first member and the second member. At least one of a load ring engagement surface of the first member and an axial segment of a first member engagement surface of the load ring includes a convex rounded portion extending over at least half the axial length thereof.
