US Patent:

20080217914, Sep 11, 2008

Filed:

Mar 5, 2007

Appl. No.:

11/715087

Inventors:

Russell P. Rutledge - Big Spring TX, US
Richard D. Burchett - Coahoma TX, US
Floyd L. Brownfield - Big Spring TX, US

International Classification:

F16L 39/00
B23P 19/04
B23Q 17/00

US Classification:

285319, 2940701, 29460, 29464

Abstract:

An improved design and a method of assembly of end fittings to sucker rods which may be of conventional length or continuous sucker rods is described herein. The end fittings and rods are assembled so as to form wedges which enhance the connectability of the end fitting to the rod, and further, the wedge or wedges approach the rod asymptotically so as to avoid any abrupt discontinuities in the wedge or wedges thus substantially eliminating stress concentration areas and potential failure areas in the rod. The assembly method provides for integrity in the rod to end fitting assembly to promote longer connection life and fewer shop rejections and field failures.
