Gary M Fishback

US Patent:

51016974, Apr 7, 1992

Filed:

Mar 26, 1990

Appl. No.:

7/499062

Inventors:

Gary M. Fishback - Santa Barbara CA

Assignee:

Plenum Corporation - Santa Barbara CA

International Classification:

B25B 2304

US Classification:

81434

Abstract:

A power driven electric reversible variable speed screwdriver is provided with a collated screwstrip feeder having a barrel which slides axially with respect to the blade and housing of a power screwdriver gun, is rotatably axially supported on the tool head of the gun in axial alignment with the gun blade, is locked by structure on the housing against rotation on the tool head. The orifice of the barrel is placeable in abutment with a sheet of drywall material to be fastened as the blade and gun housing reciprocates from an extended position relative to the barrel, at which a screw is fed through an opening in the barrel side into the barrel bore, to a retracted position relative to the barrel, at which the tip of the blade extends to an position beyond the barrel orifice to a position determined by rotary adjustment of a link connected to the tool head. The barrel and blade are selectively latchable in the retracted position to permit the screwdriver to be used in uncollated, single screw applications. The feeder includes a fixedly attached magazine or, alternatively, a guide for a remotely supplied screw strip, and, optionally, a cut-off for interconnecting strip material.

US Patent:

47780940, Oct 18, 1988

Filed:

Oct 2, 1987

Appl. No.:

7/104443

Inventors:

Gary M. Fishback - Santa Barbara CA

Assignee:

The Dimpling Nailing Gun Company - Santa Barbara CA

International Classification:

B25C 104

US Classification:

227 66

Abstract:

A nail and dimpler driving apparatus for a nailing gun is provided having a barrel with a short hardened metal dimpler which slides longitudinally in the end of the barrel and comprises a hardened metal piston having a broadened face at its end extending symmetrically on opposite sides of a metal plunger which extends longitudinally from the lower center of the piston face in alignment with an orifice through the dimpler. The piston reciprocates to impact a shoulder at the inner end of the dimpler. The barrel has a longitudinal rail extending along the top of its bore to maintain the piston and dimpler in angular alignment and to guide nails fed into the bore from an opening located in the side of the barrel between the tip of the retracted plunger and the dimpler shoulder. The rail has a longitudinal groove in its lower edge to aid in guiding the nails and in providing clearance for the residue of web material used to join the nails in flexible collated strips.

US Patent:

57021996, Dec 30, 1997

Filed:

Nov 9, 1995

Appl. No.:

8/555527

Inventors:

Gary M. Fishback - Coyote NM
Dennis M. Egan - El Cajon CA
Hilary Stelmar - El Cajon CA

Assignee:

Plasphalt Project Ltd. Co. - Coyote NM

International Classification:

C08L 9500
E01C 1100

US Classification:

404 17

Abstract:

An asphaltic concrete or paving material includes from 5 to 20 percent or more of granular recycled plastic, which supplements or replaces the rock aggregate component of the mixture. The material produces a structurally superior paving material and longer lived roadbed. The paving material includes any and all residual classes of recyclable plastic, including thermosetting plastics and other plastics having little to no current widespread utility. The material produces roadbeds of higher strength with less total asphalt thickness and having greater water impermeability, and is most useful for all layers below the surface layer. The recyclable plastic component of the material is preferably a mixture of all recyclable classes 3 through 7, or of those materials from such classes from which potentially more valuable recyclable materials have been selectively removed. The paving product is preferably formed by a process of shredding or mechanically granulating used and industrial waste plastic to a no. 4 to 1/2 inch sieve size, and preferably to 1/4 inch to 3/8 inch granules.

US Patent:

60008776, Dec 14, 1999

Filed:

Dec 22, 1997

Appl. No.:

8/995954

Inventors:

Gary M. Fishback - Coyote NM
Dennis M. Egan - El Cajon CA
Hilary Stelmar - El Cajon CA

Assignee:

Plasphalt Project Ltd. Co. - Albuquerque NM

International Classification:

E01C 726

US Classification:

404 17

Abstract:

An asphaltic concrete or paving material includes at least 5 percent, and preferably from 5 to 20 percent, of granular recycled plastic, which supplements or replaces the rock aggregate component of the mixture. The material produces a structurally superior paving material and longer lived roadbed. The plastic may include any and all residual classes of recyclable plastic, including thermosetting plastics and other plastics having little to no current widespread utility. The material produces roadbeds of higher strength with less total asphalt thickness and having greater water impermeability, and is most useful for all layers below the surface layer. The recyclable plastic component of the material is preferably a mixture of all recyclable classes 3 through 7, or of those materials from such classes from which potentially more valuable recyclable materials have been selectively removed. The paving product is preferably formed by a process of shredding or mechanically granulating used and industrial waste plastic to a no. 4 to 1/2 inch sieve size, and preferably to 1/4 inch to 3/8 inch granules.
