Georgi I Kutiev

US Patent:

20090198447, Aug 6, 2009

Filed:

Feb 6, 2008

Appl. No.:

12/027155

Inventors:

EMMANUEL LEGENDRE - Houston TX, US
Jacques R. Tabanou - Houston TX, US
Jean Seydoux - Sugar Land TX, US
Koji Ito - Sugar Land TX, US
Fabienne Legendre - Houston TX, US
Georgi Kutiev - Sugar Land TX, US

International Classification:

G01V 3/38

US Classification:

702 11

Abstract:

Method and system for visualizing one or more properties of a subterranean earth formation while drilling a borehole using probability information from a modeling process. Probability waveforms based on information from a plurality of borehole stations may be plotted, either alone or superimposed onto other graphical representations, to provide a visual display that is easily interpreted by a user to make geosteering decisions. The probability waveforms include peaked sections that are proportional to the amount of uncertainty or error associated with a boundary estimate at a particular distance from an axis of the borehole. By providing a visual display of the uncertainty, a user can make better geosteering decisions.

US Patent:

20130038463, Feb 14, 2013

Filed:

Aug 9, 2011

Appl. No.:

13/205869

Inventors:

Denis Heliot - Sugar Land TX, US
Nicholas N. Bennett - Sugar Land TX, US
Georgi Kutiev - Houston TX, US
Emmanuel Legandre - Sevres, FR
Roger Griffiths - Schaffhausen, CH
Jean-Michel Denichou - Beijing, CN
Jean Seydoux - Rio de Janeiro, BR
Qiming Li - Sugar Land TX, US
Koji Ito - Sugar Land TX, US

International Classification:

G06T 11/20
G01V 3/00
G09G 5/02

US Classification:

3408531, 345440, 345589

Abstract:

An interactive display of results obtained from the inversion of logging data is produced by obtaining and inverting the logging data using a Monte-Carlo inversion. An interactive plot having a percentile scale plotted against a location parameter is produced and a particular percentile is selected using the interactive plot. A cross-section plot for the particular percentile using the results of the Monte-Carlo inversion is produced. The particular percentile can be a curve representing a best-fit solution or a polyline representing selected solutions. Background color/shading can be displayed on the interactive plot to indicate user-defined constraints have been applied. Uncertain features can be plotted on a corresponding cross-section display using fading. Clusters of solutions that are substantially equally likely, given the measurements at a particular drill location, can be identified and plotted. A cross-section constructed from the layered models belonging to a particular cluster can be overlaid on another cross-section.
