Liquid Cooled Heat Sink With Cold Plate Retention Mechanism
view source
US Patent:

7414844, Aug 19, 2008
Filed:

Dec 12, 2006
Appl. No.:

11/637633
Inventors:

Michael J. Wilson - Racine WI, US
Jonathan Wattelet - Gurnee IL, US
Donald Lightner - Franksville WI, US
Richard DeKeuster - Racine WI, US
Ernest H. Dubble - Lancaster PA, US
Gregg J. Baldassarre - Lititz PA, US
Assignee:

Thermal Corp. - Wilmington DE
International Classification:

H05K 7/20
US Classification:

361699, 361701, 361702, 361704, 257714, 257718, 165 804, 174 151
Abstract:

A system for cooling electronic components with a surface having one or more electronic components, including an integrated circuit, mounted thereon. A liquid cooled heat exchanger located in overlying contacting relation with the integrated circuit. A resilient cold plate coupled to the surface so as to be biased by a portion of the liquid cooled heat exchanger thereby providing a forced engagement between the liquid cooled heat exchanger, the integrated circuit, and the resilient cold plate.

Plate Fins With Vanes For Redirecting Airflow
view source
US Patent:

20040200608, Oct 14, 2004
Filed:

Apr 11, 2003
Appl. No.:

10/412800
Inventors:

Gregg Baldassarre - Lititz PA, US
International Classification:

F28D015/00
F28D001/04
F28F001/20
US Classification:

165/181000, 165/151000, 165/104210
Abstract:

A fin for a heat sink is provided that includes a plate having a surface and an edge and at least one vane projecting outwardly from the surface and arranged relative to the edge so as to redirect a portion of a stream of air that is impinging upon the edge. A heat transfer system is also provided that includes a heat pipe having an elongate side and a fan that is arranged so as to direct a stream of air toward the elongate side of the heat pipe. At least one plate is arranged in parallel relation to a stream of air created by the fan. The plate includes an opening with the heat pipe positioned within the opening, a surface and an edge and at least one vane projecting outwardly from the surface and arranged relative to the edge so as to redirect a portion of the stream of air that is impinging upon the edge from the fan.

Liquid Cooled Heat Sink With Cold Plate Retention Mechanism
view source
US Patent:

20060050483, Mar 9, 2006
Filed:

Sep 7, 2005
Appl. No.:

11/220456
Inventors:

Michael Wilson - Racine WI, US
Jonathan Wattelet - Gurnee IL, US
Donald Lightner - Franksville WI, US
Richard DeKeuster - Racine WI, US
Ernest Dubble - Lancaster PA, US
Gregg Baldassarre - Lititz PA, US
International Classification:

H05K 7/20
US Classification:

361702000, 361689000, 361699000
Abstract:

A system for cooling electronic components with a surface having one or more electronic components, including an integrated circuit, mounted thereon. A liquid cooled heat exchanger located in overlying contacting relation with the integrated circuit. A resilient cold plate coupled to the surface so as to be biased by a portion of the liquid cooled heat exchanger thereby providing a forced engagement between the liquid cooled heat exchanger, the integrated circuit, and the resilient cold plate.
