Gregory S Kalata

US Patent:

7258139, Aug 21, 2007

Filed:

Nov 25, 2003

Appl. No.:

10/721312

Inventors:

Robert V. Perusek - Madison OH, US
David J. Hasak - Concord OH, US
Gregory S. Kalata - Avon OH, US
Douglas A. Nordstrom - Shaker Heights OH, US
Timothy Maruna - Chardon OH, US

Assignee:

Swagelok Company - Solon OH

International Classification:

F16K 11/00

US Classification:

137884

Abstract:

The present invention provides for a bridge fitting for use in a fluid manifold system for being in fluid communication with two or more surface mounted fluid components having an inlet port and an adjacent outlet port. The invention also provides for a housing with a first port connected to a second port, with an internal fluid passageway joining the first and second ports and at least one projection extending from the housing. The bridge fittings may be mounted in a channel block having a groove and an aligned hole for receiving the projection. Another embodiment of the invention provides for a modular surface mount check valve with a valve body having a mounting flange connected thereto, the flange being substantially planar and having an inlet passage located about the center of the flange and an outlet passage located adjacent the inlet passage. The body further comprises a valve chamber in fluid communication with the inlet passage and the outlet passage, the chamber further comprising a valve seat formed at the juncture of the inlet passage and the chamber, and a poppet positioned in the chamber, and a spring mounted in the valve chamber for biasing the poppet towards the valve seat. The invention also provides an air actuated surface mount flow control valve comprising a valve body having a mounting flange connected thereto and the flange being substantially planar and having an inlet passage located about the center of the flange and an outlet passage located adjacent the inlet passage, the body further comprising a cavity in fluid communication with the inlet passage and the outlet passage, a stem positioned in the cavity, and a spring mounted in the cavity for biasing a first end of the stem in sealing engagement with the inlet passage and the outlet passage, the stem further comprising an internal fluid passageway in fluid communication with an actuator fluid compartment located under a lower surface of the stem, and the external source of pressure.

US Patent:

7562677, Jul 21, 2009

Filed:

Jul 27, 2007

Appl. No.:

11/881595

Inventors:

Robert V. Perusek - Madison OH, US
David J. Hasak - Concord OH, US
Gregory S. Kalata - Avon OH, US
Douglas A. Nordstrom - Shaker Heights OH, US
Timothy Maruna - Chardon OH, US

Assignee:

Swagelok Company - Solon OH

International Classification:

F16K 11/10

US Classification:

137884, 251367

Abstract:

A bridge fitting for use with two or more surface mounted components includes a housing having at least a first port disposed on a first side of the housing, at least a second port non-coaxial with the first port and disposed on a second side of the housing opposite the first side of the housing, and an internal fluid passageway connecting the first and second ports. The internal fluid passageway is configured to limit fluid flow within the bridge fitting to a single path between the first and second ports.

US Patent:

20080041478, Feb 21, 2008

Filed:

Oct 30, 2007

Appl. No.:

11/928271

Inventors:

Robert Perusek - Madison OH, US
David Hasak - Concord OH, US
Gregory Kalata - Avon OH, US
Douglas Nordstrom - Shaker Heights OH, US
Timothy Maruna - Chardon OH, US

Assignee:

SWAGELOK COMPANY - Solon OH

International Classification:

F16K 11/00

US Classification:

137884000

Abstract:

A bridge fitting for use with two or more surface mounted components includes a housing having at least a first port disposed on a first side of the housing, at least a second port non-coaxial with the first port and disposed on a second side of the housing opposite the first side of the housing, and an internal fluid passageway connecting the first and second ports. The internal fluid passageway is configured to limit fluid flow within the bridge fitting to a single path between the first and second ports.

US Patent:

20080041479, Feb 21, 2008

Filed:

Oct 31, 2007

Appl. No.:

11/931126

Inventors:

Robert Perusek - Madison OH, US
David Hasak - Concord OH, US
Gregory Kalata - Avon OH, US
Douglas Nordstrom - Shaker Heights OH, US
Timothy Maruna - Chardon OH, US

Assignee:

SWAGELOK COMPANY - Solon OH

International Classification:

F16K 11/00

US Classification:

137884000

Abstract:

A bridge fitting for use with two or more surface mounted components includes a housing having at least a first port disposed on a first side of the housing, at least a second port non-coaxial with the first port and disposed on a second side of the housing opposite the first side of the housing, and an internal fluid passageway connecting the first and second ports. The internal fluid passageway is configured to limit fluid flow within the bridge fitting to a single path between the first and second ports.

US Patent:

20100213705, Aug 26, 2010

Filed:

Feb 19, 2010

Appl. No.:

12/709084

Inventors:

Peter C. Williams - Cleveland Heights OH, US
Mark A. Clason - Orwell OH, US
Cal R. Brown - Lyndhurst OH, US
Dale C. Arstein - Highland Heights OH, US
Jeffrey S. Rayle - Fairview Park OH, US
John D. Karkosiak - Broadview Heights OH, US
Gregory S. Kalata - Avon OH, US

Assignee:

Swagelok Company - Solon OH

International Classification:

F16L 25/04
F16L 19/065

US Classification:

2853323, 285354

Abstract:

A conduit fitting of the type having first and second threaded fitting components and at least one conduit gripping device, further includes a stroke limiting member that allows the fitting to be pulled up by applying a predetermined torque. In one embodiment, the stroke limiting member may be a non-integral torque collar and in another embodiment the stroke limiting member may be two engaging surfaces integrally formed with the fitting components. Alternatively, the fitting may also be pulled up by turns. In still another embodiment, a stroke limiting member is provided that may be used to enable a fitting that is designed to be pulled up by turns to also be pulled up by torque. The stroke limiting member facilitates many remakes of the fitting, including remakes by torque.

US Patent:

20130207385, Aug 15, 2013

Filed:

Oct 14, 2011

Appl. No.:

13/878828

Inventors:

Peter C. Williams - Cleveland Heights OH, US
Daniel G. Trivett - Mayfield Heights OH, US
Mark A. Clason - Orwell OH, US
Cal R. Brown - Lyndhurst OH, US
Douglas S. Welch - Chesterland OH, US
Ronald Hamilton - Cleveland OH, US
Douglas J. McClure - Mentor OH, US
William J. Knaggs - Medina OH, US
Justin Hamilton - Lakewood OH, US
Benjamin Chan - Mayfield Heights OH, US
Gregory S. Kalata - Avon OH, US

Assignee:

Swagelok Company - Solon OH

International Classification:

F16L 37/26
B23P 19/00

US Classification:

285307, 2952503

Abstract:

A push to connect fitting includes a body member adapted to receive a conduit end, a conduit comprising a first end that can be axially inserted into the body member and a conduit gripping device attached to an exterior surface of the conduit, and a retainer that retains the conduit in place when said conduit is fully inserted into the body member. Additional embodiments include providing a seal with the fitting that seals the exterior surface of the conduit, an optional load retaining sleeve for the conduit gripping device, and an optional gimbal. The push to connect aspect may be realized in the form of a single action unthreaded mechanical connection.

US Patent:

54620813, Oct 31, 1995

Filed:

Aug 24, 1994

Appl. No.:

8/295205

Inventors:

Robert V. Perusek - Euclid OH
Ulrich H. Koch - Chagrin Falls OH
Gregory S. Kalata - Parma OH

Assignee:

Nupro Company - Willoughby OH

International Classification:

F16K 1724

US Classification:

137498

Abstract:

A poppet type excess flow valve comprises a body forming a valve chamber having a first portion of a first diameter adjacent a first end and a second portion of a second smaller diameter adjacent second end. A valve seat is located between the first and second portions of the valve chamber. A poppet element is mounted in the valve chamber and includes a first section in the form of a hollow cylindrical body extending into the second portion of the valve chamber and terminating therein in an open end. The outer diameter of the hollow cylindrical body section is only slightly less than the diameter of the second portion of the valve chamber for guided sliding movement therein. The poppet element further includes a second section located in the first portion of the valve chamber and including an end wall carrying a valving surface extending radially outward for cooperation with the valve seat. A compression coil spring maintains the poppet element continually biased under a predetermined force toward the inlet port, and flow passages are formed through the hollow cylindrical body portion of the poppet element at a location closely adjacent the valving surface.

US Patent:

20210247005, Aug 12, 2021

Filed:

Apr 25, 2019

Appl. No.:

17/049455

Inventors:

- Solon OH, US
Ronald P. Campbell - Shaker Heights OH, US
Douglas J. McClure - Mentor OH, US
Cal R. Brown - Lyndhurst OH, US
Peter C. Williams - Cleveland Heights OH, US
Douglas S. Welch - Chesterland OH, US
Stephen J. Zaborszki - Northfield OH, US
Richard J. Mlinarik - Mantua OH, US
Robert A. Fotta - Burton OH, US
Matthew K. Messer - Mentor OH, US
Gregory S. Kalata - Avon OH, US

International Classification:

F16L 19/10

Abstract:

A ferrule subassembly for a conduit fitting includes first and second ferrules. The first female includes a front body portion defining a forward tapered surface, a rear body portion defining an interior camming surface, and a retaining extension joined with the rear body portion radially outward of the camming surface and extending axially rearward and radially inward from the inner axial portion. The second ferrule includes a front portion having a tapered forward contact surface adjacent the first ferrule camming surface, an outer radial portion extending axially rearward of the forward contact surface, and a recessed portion axially rearward of the outer radial portion. An end portion of the retaining extension is received in the recessed portion of the second female to retain the ferrule with the first ferrule as a discontinuous subassembly.
