Harold E Shedd

US Patent:

45478279, Oct 15, 1985

Filed:

Jul 5, 1983

Appl. No.:

6/510668

Inventors:

Harold E. Shedd - Nicholson GA

International Classification:

H02H 320

US Classification:

361 55

Abstract:

A self-contained fused unit for the protection of electrical appliances against damage caused by abnormal power surges is disclosed. Fuses are selected so that the proper amperage required to operate any appliance can be delivered through the power surge isolator while full protection of the appliance against abnormal power surges is provided. Varistors connected between terminals of the device augment the protective action of fuses in the event that certain kinds of power surges are encountered which are so fast that fuses may not blow in time to protect the appliance. In such cases, the instantly decreased resistance in the varistors assures grounding of the excessive current without damage to the appliance occurring.

US Patent:

45008620, Feb 19, 1985

Filed:

Feb 18, 1983

Appl. No.:

6/467947

Inventors:

Harold E. Shedd - Nicholson GA

International Classification:

H01H 3900

US Classification:

337 32

Abstract:

A self-contained device to protect electrical appliances from damage or destruction caused by abnormal power surges due to lightening and other causes is plugged into any household electrical outlet and has a receptacle for the plug of the power cord leading to an appliance. The unitary device contains readily replaceable fuses directly in line with the appliance power line and the fuses are chosen to allow the appliance to receive the necessary power to operate while preventing it from receiving excessive damaging power. Extreme power surges due to lightening and the like are prevented from jumping the gap between the end terminals of blown fuses by following a grounding power stop clipped onto the fuse bodies near one pair of their end terminals and leading directly to a grounding conductor. The device is embodied in either a 110 v or 220 v configuration with two and three fuses respectively, and is also embodied in a television receiver protective arrangement.
