Harry C Ives

US Patent:

7679297, Mar 16, 2010

Filed:

Aug 4, 2006

Appl. No.:

11/499548

Inventors:

William A. Stygar - Albuquerque NM, US
Michael E. Cuneo - Albuquerque NM, US
Daniel I. Headley - Albuquerque NM, US
Harry C. Ives - Albuquerque NM, US
Ramon J. Leeper - Albuquerque NM, US
Michael G. Mazarakis - Albuquerque NM, US
Craig L. Olson - Albuquerque NM, US
John L. Porter - Sandia Park NM, US
Tim C. Wagoner - Albuquerque NM, US

Assignee:

Sandia Corporation - Albuquerque NM

International Classification:

H05H 9/00

US Classification:

315505, 315501, 315 541

Abstract:

A petawatt pulsed-power accelerator can be driven by various types of electrical-pulse generators, including conventional Marx generators and linear-transformer drivers. The pulsed-power accelerator can be configured to drive an electrical load from one- or two-sides. Various types of loads can be driven; for example, the accelerator can be used to drive a high-current z-pinch load. When driven by slow-pulse generators (e. g. , conventional Marx generators), the accelerator comprises an oil section comprising at least one pulse-generator level having a plurality of pulse generators; a water section comprising a pulse-forming circuit for each pulse generator and a level of monolithic triplate radial-transmission-line impedance transformers, that have variable impedance profiles, for each pulse-generator level; and a vacuum section comprising triplate magnetically insulated transmission lines that feed an electrical load. When driven by LTD generators or other fast-pulse generators, the need for the pulse-forming circuits in the water section can be eliminated.

US Patent:

47345861, Mar 29, 1988

Filed:

Mar 6, 1986

Appl. No.:

6/836883

Inventors:

Charles E. Crist - Albuquerque NM
Harry C. Ives - Albuquerque NM
Gordon T. Leifeste - Albuquerque NM
Robert B. Miller - Albuquerque NM

Assignee:

The United States of America as represented by the United States
Department of Energy - Washington DC

International Classification:

H01J 3304

US Classification:

2505031

Abstract:

A self-contained hermetically sealed foil changer for advancing a portion of foil web into a position normal to the path of a high energy particle beam. The path of the beam is defined generally by an aperture plate and cooperating axially movable barrel such that the barrel can be advanced toward the plate thereby positioning a portion of the foil across the beam path and sealing the foil between the barrel and the plate to form a membrane across said beam path. A spooling apparatus contained in the foil changer permits selectively advancing a fresh supply of foil across the beam path without breaking the foil changer seal.
