Haytham M Hussein

US Patent:

6999818, Feb 14, 2006

Filed:

Apr 15, 2004

Appl. No.:

10/825900

Inventors:

Robert A. Stevenson - Canyon Country CA, US
Christine A. Frysz - Marriottsville MD, US
Haytham Hussein - Woodstock MD, US
Richard L. Brendel - Carson City NV, US

Assignee:

Greatbatch-Sierra, Inc. - Carson City NV

International Classification:

A61N 1/375
A61N 1/16

US Classification:

607 37, 607 36

Abstract:

A feedthrough terminal assembly for an active implantable medical device includes a conductive ferrule conductively coupled to a housing of the medical device, a feedthrough capacitor conductively coupled to the ferrule, an inductor closely associated with the capacitor in non-conductive relation, and a conductive terminal pin extending through the capacitor and the inductor. The terminal pin extends through the inductor in non-conductive relation and is conductively coupled to active electrode plates of the capacitor. In one preferred form, the terminal pin is wound about the inductor. Additionally, the inductor may be maintained in close association with the capacitor without forming a direct physical attachment therebetween.

US Patent:

7012192, Mar 14, 2006

Filed:

Mar 30, 2005

Appl. No.:

11/096003

Inventors:

Robert A. Stevenson - Santa Clarita CA, US
Richard L. Brendel - Carson City NV, US
Christine Frysz - Marriottsville MD, US
Haytham Hussein - Woodstock MD, US
Scott Knappen - Annapolis MD, US

International Classification:

H01L 23/02

US Classification:

174 525, 257699, 257708, 607116

Abstract:

A terminal assembly for active implantable medical devices includes a structural pad, in the form of a substrate or attached wire bond pad, for convenient attachment of wires from the circuitry inside the implantable medical device.

US Patent:

7038900, May 2, 2006

Filed:

May 10, 2004

Appl. No.:

10/842967

Inventors:

Robert A. Stevenson - Santa Clarita CA, US
Richard L. Brendel - Carson City NV, US
Christine Frysz - Marriottsville MD, US
Haytham Hussein - Woodstock MD, US
Scott Knappen - Annapolis MD, US
Ryan A. Stevenson - Santa Clarita CA, US

Assignee:

Greatbatch-Sierra, Inc. - Carson City NV

International Classification:

H01G 4/35

US Classification:

361302, 361303, 361305, 3613061, 3613063, 3613081, 333182, 333185

Abstract:

An electro-magnetic interference filter terminal assembly for active implantable medical devices includes a structural pad in the form of a substrate or attached wire bond pad, for convenient attachment of wires from the circuitry inside the implantable medical device to the capacitor structure via thermal or ultrasonic bonding, soldering or the like while shielding the capacitor from forces applied to the assembly during attachment of the wires.

US Patent:

7136273, Nov 14, 2006

Filed:

Oct 10, 2005

Appl. No.:

11/163198

Inventors:

Robert A. Stevenson - Canyon Country CA, US
Richard L. Brendel - Carson City NV, US
Christine A. Frysz - Marriottsville MD, US
Haytham Hussein - Woodstock MD, US
Matthew A. Dobbs - Gardnerville NV, US

Assignee:

Greatbatch-Sierra, Inc. - Carson City NV

International Classification:

H01G 4/35

US Classification:

361302, 3613062, 361311, 361313, 333182, 333185, 607 5

Abstract:

A feedthrough terminal assembly for an active implantable medical device utilizes an insert to establish a reliable electrical connection between capacitor electrode plates, via inner surface metallization of a capacitor aperture, and an associated terminal pin , which passes at least partially therethrough. The inserts are preferably resiliently flexible, such as a spring, to establish this connection. The insert also serves to establish a mechanical connection between the capacitor and the terminal pin.

US Patent:

7145076, Dec 5, 2006

Filed:

Feb 7, 2006

Appl. No.:

11/307434

Inventors:

Scott Knappen - Annapolis MD, US
Robert Naugler - Eldersburg MD, US
Haytham Hussein - Woodstock MD, US
Thomas Shipman - Frisco MD, US
Richard Brendel - Carson City NV, US
Christine Frysz - Marriottsville MD, US

Assignee:

Greatbatch, Inc. - Clarence NY

International Classification:

H01J 5/00

US Classification:

174 506, 174 5056, 174 5061, 361302, 29 2542

Abstract:

A feedthrough terminal pin assembly includes an outer ferrule hermetically sealed through a braze joint to an insulator seated within the ferrule is described. The insulator is also hermetically brazed to at least one terminal pin. The terminal pin is provided with a braze retention structure such as an annular groove that prevents braze material from filleting past the groove. Similarly, either the ferrule or the insulator is provided with a retention structure such as an annular groove that prevents braze material spill out from the insulator/ferrule interface. In that manner, the braze retention structures keep braze material from accumulating in unwanted areas where it could adversely affect hermeticity as well as proper attachment of an EMI filter to the feedthrough assembly.

US Patent:

7310216, Dec 18, 2007

Filed:

Jul 14, 2005

Appl. No.:

11/182289

Inventors:

Robert A. Stevenson - Santa Clarita CA, US
Richard L. Brendel - Carson City NV, US
Christine Frysz - Marriottsville MD, US
Haytham Hussein - Woodstock MD, US
Scott Knappen - Annapolis MD, US
Ryan A. Stevenson - Santa Clarita CA, US

Assignee:

Greatbatch-Sierra, Inc. - Canyon Country CA

International Classification:

H01G 4/35

US Classification:

361302, 361303, 3613061, 3613062, 361320, 3613215, 607 5, 607 36, 607 37

Abstract:

An electro-magnetic interference filter terminal assembly for active implantable medical devices includes a structural pad in the form of a substrate or attached wire bond pad, for convenient attachment of wires from the circuitry inside the implantable medical device to the capacitor structure via thermal or ultrasonic bonding, soldering or the like while shielding the capacitor from forces applied to the assembly during attachment of the wires.

US Patent:

7493167, Feb 17, 2009

Filed:

Nov 1, 2005

Appl. No.:

11/163848

Inventors:

Haytham Hussein - Woodstock MD, US
Christine A. Frysz - Marriottsville MD, US
Robert A. Stevenson - Canyon Country CA, US

Assignee:

Greatbatch-Sierra, Inc. - Carson City NV

International Classification:

A61N 1/375

US Classification:

607 36, 607 63

Abstract:

An active implantable medical device (AIMD) having a magnetic shield on its housing for shielding the interior of the device from magnetic fields originating outside the housing. The magnetic shield is created using a magnetic absorbing coating on the inner surface of the housing. The AIMD includes an area of the housing left without the magnetic shield, a magnetic window, adjacent to a magnetically actuated device located inside of the housing. The magnetic window permits activation of the magnetically actuated device.

US Patent:

7623335, Nov 24, 2009

Filed:

Apr 19, 2006

Appl. No.:

11/308662

Inventors:

Robert A. Stevenson - Canyon Country CA, US
Richard L. Brendel - Carson City NV, US
Christine A. Frysz - Marriottsville MD, US
Haytham Hussein - Woodstock MD, US
Scott Knappen - Annapolis MD, US
Ryan A. Stevenson - Santa Clarita CA, US

Assignee:

Greatbatch-Sierra, Inc - Clarence NY

International Classification:

H01G 4/35

US Classification:

361302, 3613061, 361303, 361305, 3613012, 333182, 333183, 333185

Abstract:

A feedthrough terminal assembly for active implantable medical devices includes a structural wire bond pad for a convenient attachment of wires from either the circuitry inside the implantable medical device or wires external to the device. Direct attachment of wire bond pads to terminal pins enables thermal or ultrasonic bonding of lead wires, while shielding the capacitor or other delicate components from the forces applied to the assembly during attachment of the wires.
