Henry J Frisch from 5636 Blackstone Ave, Chicago, IL 60637, age 81, Phone: 7739551696

view source

Use Of Flat Panel Microchannel Photomultipliers In Sampling Calorimeters With Timing
view source
US Patent:

8604440, Dec 10, 2013
Filed:

Mar 9, 2011
Appl. No.:

13/044442
Inventors:

Henry Frisch - Chicago IL, US
Jean-Francois Genat - Boulogne-Billancourt, FR
Hervé Grabas - Chicago IL, US
Chien-Min Kao - Wilmette IL, US
Chin-Tu Chen - Lisle IL, US
Heejong Kim - Chicago IL, US
Fukun Tang - Chicago IL, US
Jeffrey W. Elam - Elmhurst IL, US
Anil U. Mane - Downers Grove IL, US
Assignee:

The University of Chicago - Chicago IL
International Classification:

G01T 1/164
US Classification:

250367
Abstract:

Large-area, flat-panel photo-detectors with sub-nanosecond time resolution based on microchannel plates are provided. The large-area, flat-panel photo-detectors enable the economic construction of sampling calorimeters with, for example, enhanced capability to measure local energy deposition, depth-of-interaction, time-of-flight, and/or directionality of showers. In certain embodiments, sub-nanosecond timing resolution supplies correlated position and time measurements over large areas. The use of thin flat-panel viewing radiators on both sides of a radiation-creating medium allows simultaneous measurement of Cherenkov and scintillation radiation in each layer of the calorimeter. The detectors may be used in a variety of applications including, for example, medical imaging, security, and particle and nuclear physics.

Large Area, Pico-Second Resolution, Time Of Flight Detectors
view source
US Patent:

20070187596, Aug 16, 2007
Filed:

Oct 19, 2006
Appl. No.:

11/583299
Inventors:

Henry Frisch - Chicago IL, US
Harold Sanders - Chicago IL, US
Fukun Tang - Chicago IL, US
Tim Credo - Highland Park IL, US
International Classification:

G21K 7/00
US Classification:

250309000
Abstract:

A detector for detecting a particle is disclosed. The detector includes a charge emitter that emits a charge in response to receipt of the particle, an anode for receiving the emitted charge, and electronics for determining whether there is received charge on the anode. The anode may include a pad for receiving the charge and a plurality of conduits (such as transmission lines) for transmitting the charge to the electronics. The anode may be designed to reduce the variance in the path length from the pad of the anode to the electronics. For example, the plurality of conduits in the anode may be constructed such that the transit time of the charge from the pad varies less than a predetermined time. Further, a capacitive element may be included in the detector in order to capacitively couple with the charge emitter. The capacitive element may include a grid that is in the same layer as the pads of the anode in order to provide a short and less variable circuit return path to the charge emitter.

Micro-Channel Plate Detector
view source
US Patent:

20110210259, Sep 1, 2011
Filed:

Feb 22, 2011
Appl. No.:

13/032395
Inventors:

Jeffrey W. Elam - Elmhurst IL, US
Michael J. Pellin - Naperville IL, US
Karen Byrum - Batavia IL, US
Henry J. Frisch - Chicago IL, US
Seon W. Lee - Westmont IL, US
International Classification:

G01T 1/20
B05D 5/12
US Classification:

25037011, 427123, 427595
Abstract:

A method and system for providing a micro-channel plate detector. An anodized aluminum oxide membrane is provided and includes a plurality of nanopores which have an Al coating and a thin layer of an emissive oxide material responsive to incident radiation, thereby providing a plurality of radiation sensitive channels for the micro-channel plate detector.
