Jan Z Zywot

US Patent:

8232702, Jul 31, 2012

Filed:

Jul 30, 2010

Appl. No.:

12/846980

Inventors:

Jan Zywot - Centerville OH, US
Xiaochuan Jia - Centerville OH, US
Norman K. Austin - West Chester OH, US

Assignee:

GE Aviation Systems, LLC - Grand Rapids MI

International Classification:

H02K 3/48

US Classification:

310214, 310262

Abstract:

A high-speed sleeveless rotor for an electric machine is provided. The rotor includes a shaft rotatable about a longitudinal axis, and a rotor core circumscribing at least a portion of the shaft wherein the rotor core includes an axially oriented slot. The slot includes a radially outer slot opening, a radially inner slot floor, and a slot sidewall extending therebetween. The slot floor includes a topstick attachment member extending radially outward from the slot floor and configured to engage a topstick positioned in the slot opening and the slot sidewall includes a shoulder configured to engage the topstick, preventing radially outward movement of the topstick.

US Patent:

20080093850, Apr 24, 2008

Filed:

May 3, 2007

Appl. No.:

11/797451

Inventors:

Dinesh Taneja - Vandalia OH, US
Hao Huang - Troy OH, US
Gary Padgett - Kettering OH, US
Jan Zywot - Centerville OH, US
Paul Wirsch - Springboro OH, US
Mohamed Abbas - Huber Heights OH, US

International Classification:

B64D 31/02
F02N 11/04

US Classification:

29003600R, 24405300A, 290047000

Abstract:

An aircraft starting and generating system includes a first starter/main machine assembly that includes a first exciter and a first main machine, and second starter/main machine assembly that includes a second exciter and a second main machine. The system also includes a permanent magnet generator (PMG) that is connected to the first and second starter/main machine assemblies. The system further includes a first inverter/converter/controller (ICC) that is connected to the first starter/main machine assembly and to the PMG, and a second ICC that is connected to the second starter/main machine assembly and to the PMG. The first and second ICCs generate AC power to respective drive the first and second starter/main machine assemblies in a start mode of the starting and generating system for starting a prime mover of the aircraft, and the first and second ICCs convert AC power, respectively obtained from the PMG after the prime mover has been started, to DC power in a generate mode of the starting and generating system.

US Patent:

20110252807, Oct 20, 2011

Filed:

Apr 20, 2010

Appl. No.:

12/763441

Inventors:

Hao Huang - Troy OH, US
Jan Zywot - Centerville OH, US

Assignee:

GENERAL ELECTRIC COMPANY - Schenectady NY

International Classification:

F02C 7/275

US Classification:

60788

Abstract:

An assembly for a gas turbine engine comprising an accessory gearbox comprising a drive gear and a starter/generator mechanically mounted to the accessory gearbox. The starter/generator comprising a rotatable shaft, a pinion gear carried by the shaft, a main machine carried by the shaft, a permanent magnet generator (PMG) carried by the shaft and an exciter carried by the shaft.

US Patent:

20120159964, Jun 28, 2012

Filed:

Dec 28, 2010

Appl. No.:

12/979579

Inventors:

Hao Huang - Troy OH, US
Jan Zywot - Centerville OH, US

Assignee:

GENERAL ELECTRIC COMPANY - Schenectady NY

International Classification:

F02C 7/26

US Classification:

60786

Abstract:

An assembly for a gas turbine engine comprising an accessory gearbox comprising a drive gear and pinion gear and a starter/generator mechanically mounted to the accessory gearbox. The starter/generator comprising a housing and a portion of a rotatable shaft with a safety disconnect where the safety disconnect is located within the housing of the starter/generator.

US Patent:

20210322910, Oct 21, 2021

Filed:

Jun 24, 2021

Appl. No.:

17/356970

Inventors:

- Grand Rapids MI, US
Richard Louis Heil - Medway OH, US
Jan Zywot - Centerville OH, US

International Classification:

B01D 45/16
F04B 23/02
F04B 39/16

Abstract:

An air-oil separator assembly can include an air-oil mixture inlet, an air outlet, and an oil outlet, a housing defining a cylindrical separating cavity, and an outlet conduit disposed within the separating cavity, wherein, outlet conduit is adapted to receive oil removed by the air-oil separator assembly from a flow containing an air-oil mixture fluid received by the air-oil mixture inlet.

US Patent:

20190224602, Jul 25, 2019

Filed:

Jan 19, 2018

Appl. No.:

15/875401

Inventors:

- Grand Rapids MI, US
Richard Louis Heil - Medway OH, US
Jan Zywot - Centerville OH, US

International Classification:

B01D 45/16
F04B 39/16

Abstract:

An air-oil separator assembly can include an air-oil mixture inlet, an air outlet, and an oil outlet, a housing defining a cylindrical separating cavity, and an outlet conduit disposed within the separating cavity, wherein, outlet conduit is adapted to receive oil removed by the air-oil separator assembly from a flow containing an air-oil mixture fluid received by the air-oil mixture inlet.

US Patent:

20160285332, Sep 29, 2016

Filed:

Nov 4, 2013

Appl. No.:

15/029917

Inventors:

- SE, Grand Rapids MI, US
Xiaochuan JIA - Centerville OH, US
Jan ZYWOT - Centerville OH, US

International Classification:

H02K 1/32
H02K 19/16
H02K 19/02
H02K 1/02
H02K 1/26

Abstract:

A rotor assembly for an electric machine includes a core having at least one post and a cap wherein electrical windings are wound about the rotor assembly to define a pole. The rotation of the rotor and rotor pole relative to a stator generates a current supplied from the electric machine to a power consuming device.

US Patent:

20150249370, Sep 3, 2015

Filed:

Feb 28, 2014

Appl. No.:

14/193666

Inventors:

- Grand Rapids MI, US
Hao Huang - Troy OH, US
Xiaochuan Jia - Centerville OH, US
Jan Zywot - Centerville OH, US

Assignee:

GE Aviation Systems LLC - Grand Rapids MI

International Classification:

H02K 3/24
H02K 9/197
H02K 3/18

Abstract:

A rotor assembly for an electric machine includes a core having at least one post and a cap wherein electrical windings are wound about the rotor assembly to define a pole. The rotation of the rotor and rotor pole relative to a stator generates a current supplied from the electric machine to a power consuming device.
