Jeffrey D Sandstrom

US Patent:

8460172, Jun 11, 2013

Filed:

Jul 29, 2010

Appl. No.:

12/846147

Inventors:

Eric Meyer - Andover MN, US
Jeffrey Sandstrom - Forest Lake MN, US
Robert Reetz - Rockford MN, US
Eric Fox - Prior Lake MN, US

Assignee:

Medtronic, Inc. - Minneapolis MN

International Classification:

A61B 19/00

US Classification:

600 37, 600229

Abstract:

A tissue stabilizer including an elongated arm, a collet, and a head-link assembly. The collet is disposed at a distal end of the arm. The head-link assembly includes a tube and a spreading mechanism. The tube forms an intermediate section and opposing arms each terminating at a tip. The spreading mechanism can adjust a lateral distance between the tips, and includes first and second articulating members each having a leg and a collet interface body. The first member further includes a female hinge feature, whereas the second member includes a male hinge feature differing from the female hinge feature. The legs of are mounted to discrete regions of the tube, and the male hinge feature is pivotably coupled to the female hinge feature. Automatic spreading of a lateral distance between the tips occurs in response to a compressive force applied to the collet interface bodies.

US Patent:

8480696, Jul 9, 2013

Filed:

Jun 16, 2005

Appl. No.:

11/155533

Inventors:

Cynthia T. Clague - Minnetonka MN, US
Michael J. Hobday - Lino Lakes MN, US
Raymond W. Usher - Coon Rapids MN, US
Roderick E. Briscoe - Rogers MN, US
Katherine S. Jolly - Eden Prairie MN, US
Ana R. Buhr - Minneapolis MN, US
Christopher P. Olig - Eden Prairie MN, US
Eric A. Meyer - Andover MN, US
Steven C. Christian - New Brighton MN, US
Tom P. Daigle - Corcoran MN, US
Robert H. Reetz - Rockford MN, US
Jeffrey D. Sandstrom - Forest Lake MN, US
James R. Keogh - Maplewood MN, US
Matthew D. Bonner - Plymouth MN, US
Scott E. Jahns - Hudson WI, US

Assignee:

Medtronic, Inc. - Minneapolis MN

International Classification:

A61B 17/22

US Classification:

606159

Abstract:

The invention provides a system and method for harvesting a vessel section. The system comprises a vessel support member, a handle, and a tubular cutting device. The vessel support member is introduced into the vessel section to be harvested. The tubular cutting device may comprise an outer tubular member or an outer and an inner tubular member. The outer tubular member carries at least one cutting element. The tubular member or members are advanced over the vessel section and vessel support member to core out the vessel section and tissue adjoining the vessel section.

US Patent:

20030069546, Apr 10, 2003

Filed:

Oct 4, 2001

Appl. No.:

09/969870

Inventors:

Jeffrey Sandstrom - Forest Lake MN, US
William Beling - Newbrighton MN, US
Kristin Finberg - Minneapolis MN, US
Ronald Travis - Spring Lake Park MN, US

International Classification:

A61M005/00

US Classification:

604/263000

Abstract:

A right angle safety needle has a base to which an arm is hingedly mounted at a proximal portion. The base has an opening at its distal portion wherethrough the vertical portion of the right angle needle extends. A well is formed adjacent the opening and a dam is provided on the side of the well away from the opening. To retract the needle from the opening, the horizontal portion of the needle, which may be encased in an arm, is rotated about the upright to which it is hingedly connected so that the needle is pivoted upwards and withdrawn from the opening. Once the tip of the needle clears the opening, due to the tip of the needle being offset from the body of the needle and the fact that the needle tends to flex forward, the tip of the needle is entrapped in the well adjacent to the opening. The dam forward of the well provides a backstop for any further forward movement of the tip of the needle, thereby fixedly retaining the needle within the well. Stops are provided in the device, at its arm and base, to prevent the needle from being further moved relative to the base once the tip of the needle is entrapped in the well of the base.

US Patent:

20050010095, Jan 13, 2005

Filed:

May 3, 2004

Appl. No.:

10/837947

Inventors:

Mark Stewart - Lino Lakes MN, US
Gary Fiedler - Forest Lake MN, US
Jeffrey Sandstrom - Forest Lake MN, US

International Classification:

A61B005/04
A61B018/14

US Classification:

600374000, 606041000

Abstract:

According to the present invention, a catheter having at least one multi-purpose lumen formed through the catheter terminates proximal a relatively complex-shaped distal portion thereof. In one form of this embodiment, the relatively complex-shaped distal portion comprises a looped portion having diagnostic- and/or ablation-type electrodes coupled thereto and an elongated diameter-adjusting member coupled proximal the distal end of the looped portion. The multi-purpose lumen may be used to alternately accommodate a variety of dedicated materials; such as, (i) a guide wire for initial deployment or later repositioning of the catheter, (ii) a volume or flow of a contrast media and the like, (iii) a deployable hollow needle or tube and the like used to biopsy adjacent tissue or dispense a therapeutic agent into a volume of tissue, and (iv) a cooling fluid, such as saline solution and the like dispensed at least during therapeutic tissue ablation procedures.

US Patent:

20080161841, Jul 3, 2008

Filed:

Oct 16, 2007

Appl. No.:

11/974914

Inventors:

Cynthia T. Clague - Minnetonka MN, US
Michael J. Hobday - Lino Lakes MN, US
Raymond W. Usher - Coon Rapids MN, US
Roderick E. Briscoe - Rogers MN, US
Katherine S. Olig - Eden Prairie MN, US
Ana R. Menk - Minneapolis MN, US
Christopher P. Olig - Eden Prairie MN, US
Eric A. Meyer - Andover MN, US
Steven C. Christian - New Brighton MN, US
Thomas P. Daigle - Corcoran MN, US
Robert H. Reetz - Rackford MN, US
Jeffrey D. Sandstrom - Forest Lake MN, US
James R. Keogh - Maplewood MN, US
Matthew D. Bonner - Plymouth MN, US
Scott E. Jahns - Hudson WI, US
Philip J. Haarstad - Chanhassen MN, US

International Classification:

A61B 17/3205

US Classification:

606159

Abstract:

Embodiments of the invention provide a cutting device and method of vessel harvesting. The cutting device can include at least one tubular member, a cutting element, and a centering member. The cutting device can include at least one tubular member with a flexible section and a cutting element. The method of vessel harvesting can include spacing a cutting element of the cutting device from the vessel as the cutting element is advanced over the vessel.

US Patent:

20080161843, Jul 3, 2008

Filed:

Oct 16, 2007

Appl. No.:

11/974922

Inventors:

Cynthia T. Clague - Minnetonka MN, US
Michael J. Hobday - Lino Lakes MN, US
Raymond W. Usher - Coon Rapids MN, US
Roderick E. Briscoe - Rogers MN, US
Katherine S. Olig - Eden Prairie MN, US
Ana R. Menk - Minneapolis MN, US
Christopher P. Olig - Eden Prairie MN, US
Eric A. Meyer - Andover MN, US
Steven C. Christian - New Brighton MN, US
Thomas P. Daigle - Corcoran MN, US
Robert H. Reetz - Rockford MN, US
Jeffrey D. Sandstrom - Forest Lake MN, US
James R. Keogh - Maplewood MN, US
Matthew D. Bonner - Plymouth MN, US
Scott E. Jahns - Hudson WI, US
Philip J. Haarstad - Chanhassen MN, US

International Classification:

A61B 17/32
A61M 5/00
A61M 31/00
A61M 5/178
A61B 19/00

US Classification:

606167, 604264, 604509, 60416413, 128898

Abstract:

Embodiments of the invention provide a vessel support system and a method of vessel harvesting. The system can include a cutting device, a catheter adapted to be inserted into a section of the vessel in order to support the vessel as the cutting device is advanced over the vessel, and a cannula adapted to be coupled to the vessel and adapted to receive the catheter as the catheter is inserted into the section of the vessel. The method can include orienting a cutting device coaxially with the cannula and the catheter and advancing the cutting device over the cannula, the catheter, and the section of the vessel in order to core out the section of the vessel and a portion of the surrounding tissue.

US Patent:

20080167669, Jul 10, 2008

Filed:

Oct 16, 2007

Appl. No.:

11/974906

Inventors:

Cynthia T. Clague - Minnetonka MN, US
Michael J. Hobday - Lino Lakes MN, US
Raymond W. Usher - Coon Rapids MN, US
Roderick E. Briscoe - Rogers MN, US
Katherine S. Olig - Eden Prairie MN, US
Ana R. Menk - Minneapolis MN, US
Christopher P. Olig - Eden Prairie MN, US
Eric A. Meyer - Andover MN, US
Steven C. Christian - New Brighton MN, US
Thomas P. Daigle - Corcoran MN, US
Robert H. Reetz - Rockford MN, US
Jeffrey D. Sandstrom - Forest Lake MN, US
James R. Keogh - Maplewood MN, US
Matthew D. Bonner - Plymouth MN, US
Scott E. Jahns - Hudson WI, US
Philip J. Haarstad - Chanhassen MN, US

International Classification:

A61B 17/32
A61B 17/22

US Classification:

606159

Abstract:

Embodiments of the invention provide a vessel tensioning handle and method of placing tension on a section of a vessel being harvested. The handle can include a housing, a bobbin assembly, a vessel tensioning tape, and a tensioning device member. The tensioning device member can be coupled to a cannula that is coupled to the vessel. The method can include using the vessel tensioning tape to place tension on the section of the vessel as the cutting device is advanced over the vessel.

US Patent:

20080249546, Oct 9, 2008

Filed:

Jan 7, 2008

Appl. No.:

11/970319

Inventors:

Jeffrey D. Sandstrom - Forest Lake MN, US
Eric A. Meyer - Andover MN, US
Damian A. Jelich - Cottage Grove MN, US
Robert H. Reetz - Rockford MN, US
Roderick E. Briscoe - Rogers MN, US

International Classification:

A61B 17/08

US Classification:

606153

Abstract:

A surgical connection apparatus including a plurality of delivery assemblies, a housing assembly, and a drive mechanism. The delivery assemblies each include an outer member, an inner member, and optionally a retention member. The inner member is disposed within the outer member, terminates at a distal tip and forms an internal passage that is open at a window. The delivery assemblies releasably retain a self-closing clip. The housing assembly maintains the delivery assemblies in a generally circular arrangement. The drive mechanism operates to transition the delivery assembly in releasing a self-closing clip from the corresponding delivery assembly. With this construction, a plurality of self-closing clips can be simultaneously deployed in a manner effectuating, for example, an end-to-side anastomosis.
