Jeffrey J Vannorden from 10 Gauthier Dr, Clifton Park Center, NY 12065, age 53, Phone: 5183739352

Us Patents

Robotic Placement Machine For Optical Bonding, System And Method Of Use Thereof
view source
US Patent:

20120180935, Jul 19, 2012
Filed:

Jan 19, 2011
Appl. No.:

13/009385
Inventors:

Jeffrey James VanNorden - Clifton Park NY, US
Andrew John Nally - Greenfield NY, US
Jonathan Neal Urquhart - Saratoga Springs NY, US
International Classification:

B32B 17/06
B05C 5/02
B65G 47/26
US Classification:

156102, 4147491, 4147493, 4147521, 156356
Abstract:

A robotic placement machine including a base operably connected to the Y axis actuator and the X axis actuator, a first Z axis actuator coupled to the first end of the base, the first Z axis actuator capable of moving up and down a first Z axis, a second Z axis actuator coupled to the second end of the base, the second Z axis actuator capable of moving up and down a second Z axis, and a pick and place plate operably connected to the first Z axis actuator and the second Z axis actuator, wherein the first Z axis actuator and the second Z axis actuator are each capable of moving independently of each other to tilt the pick and place plate is provided. Furthermore, a system comprising a first machine, second machine, and third machine to eliminate air bubbles when bonding two substrates is also provided. A method of optical bonding is further provided.

Machine For Optical Bonding, System And Method Of Use Thereof
view source
US Patent:

20120234459, Sep 20, 2012
Filed:

Jun 4, 2012
Appl. No.:

13/487448
Inventors:

Andrew John Nally - Greenfield NY, US
Jonathan Neal Urquhart - Saratoga Springs NY, US
Jeffrey James VanNorden - Clifton Park NY, US
Assignee:

PRECISION VALVE & AUTOMATION, INC. - Cohoes NY
International Classification:

B32B 37/14
B05C 11/00
B32B 41/00
B32B 37/06
B32B 38/18
B05C 5/00
B32B 37/12
US Classification:

156 64, 118323, 118697, 156538, 156378, 1563809, 156 60, 901 30
Abstract:

An adhesive application valve comprising an applicator, a Z-axis actuator operably connected to the applicator, wherein the Z-axis actuator and the rotation device are each capable of moving independently of each other to position the applicator in a position to apply an amount of adhesive to a top substrate prior to bonding with a bottom substrate is provided. Furthermore, a machine comprising an end effector, and an adhesive application valve configured to apply an amount of adhesive onto the top substrate, the end effector configured to place the top substrate into a position of engagement with the adhesive application valve, and place the top substrate onto the bottom substrate to facilitate initial contact between the adhesive applied to the top substrate and a fill material applied to the bottom substrate is also provided. A method of optical bonding is further provided.

Robotic Placement Machine For Optical Bonding, System And Method Of Use Thereof
view source
US Patent:

20130272835, Oct 17, 2013
Filed:

Mar 18, 2013
Appl. No.:

13/845978
Inventors:

Jeffrey James VanNorden - Clifton Park NY, US
Jonathan Neal Urquhart - Saratoga Springs NY, US
International Classification:

B65G 47/26
US Classification:

4147521, 4147491, 414800
Abstract:

A robotic placement machine including a base operably connected to the Y axis actuator and the X axis actuator, a first Z axis actuator coupled to the first end of the base, the first Z axis actuator capable of moving up and down a first Z axis, a second Z axis actuator coupled to the second end of the base, the second Z axis actuator capable of moving up and down a second Z axis, and a pick and place plate operably connected to the first Z axis actuator and the second Z axis actuator, wherein the first Z axis actuator and the second Z axis actuator are each capable of moving independently of each other to tilt the pick and place plate is provided. Furthermore, a system comprising a first machine, second machine, and third machine to eliminate air bubbles when bonding two substrates is also provided. A method of optical bonding is further provided.

Spray Dispensing Method For Applying Liquid Metal
view source
US Patent:

20090149021, Jun 11, 2009
Filed:

Dec 11, 2007
Appl. No.:

11/954158
Inventors:

Michael D. Hillman - Los Altos CA, US
Gregory L. Tice - Los Altos CA, US
Oscar Woo - Santa Cruz CA, US
Amir Salehi - San Jose CA, US
Ronald J. Smith - New Berlin WI, US
Sean A. Bailey - Menlo Park CA, US
Anwyl M. McDonald - Oakland CA, US
Clayton R. Anderson - El Cerrito CA, US
James M. Crowder - Greenwich NY, US
Jeffrey J. VanNorden - Clifton Park NY, US
Jonathan N. Urquhart - Saratoga Springs NY, US
Assignee:

APPLE INC. - Cupertino CA
International Classification:

H01L 21/44
US Classification:

438654, 257E21476
Abstract:

Embodiments of a method for applying a thermal-interface material are described. During this method, a first surface of a heat-removal device and a second surface of a semiconductor die are prepared. Next, a region on a given surface, which is at least one of the first surface and the second surface, is defined. Then, the thermal-interface material is applied to at least the region, where the thermal-interface material includes a material that is a liquid metal over a range of operating temperatures of the semiconductor die.

Optical Bonding Method
view source
US Patent:

20200316931, Oct 8, 2020
Filed:

Mar 13, 2020
Appl. No.:

16/817886
Inventors:

- Choes NY, US
Jonathan Neal Urquhart - Saratoga Springs NY, US
Jeffrey James VanNorden - Clifton Park NY, US
International Classification:

B32B 37/14
B32B 17/10
B32B 37/12
B32B 38/18
Abstract:

Optically bonding a first substrate to a second substrate, or vice versa, by contacting an adhesive on the second substrate with a fill material of the first substrate.

Machine For Optical Bonding, System And Method Of Use Thereof
view source
US Patent:

20180215131, Aug 2, 2018
Filed:

Jan 19, 2018
Appl. No.:

15/875256
Inventors:

- Cohoes NY, US
Jonathan Neal Urquhart - Saratoga Springs NY, US
Jeffrey James VanNorden - Clifton Park NY, US
International Classification:

B32B 37/14
B32B 17/10
B32B 37/12
B32B 38/18
B05C 5/02
Abstract:

An optical bonding machine is provided that includes a robotic placement machine having a Z axis actuator coupled to a first end of a base portion of the robotic placement machine, the Z axis actuator capable of moving up and down a Z axis, and a pick and place plate operably connected to the Z axis actuator, and a vertically oriented adhesive application valve configured to apply an amount of adhesive onto an underside of a substrate, the underside of the substrate facing down when the amount of adhesive is applied, wherein the pick-and-place plate of the robotic placement machine manipulates the substrate within the optical bonding machine such that the substrate receives the amount of adhesive prior to being optically bonded to an other substrate; wherein a movement of the robotic placement machine is controllable over at least 3 axes.

Machine For Optical Bonding, System And Method Of Use Thereof
view source
US Patent:

20160159061, Jun 9, 2016
Filed:

Mar 28, 2014
Appl. No.:

14/228551
Inventors:

Andrew John Nally - Greenfield NY, US
Jonathan Neal Urquhart - Saratoga Springs NY, US
Jeffrey James VanNorden - Clifton Park NY, US
Assignee:

PRECISION VALVE & AUTOMATION, INC. - Cohoes NY
International Classification:

B32B 37/14
B32B 38/18
B32B 37/12
Abstract:

An adhesive application valve comprising an applicator, a Z-axis actuator operably connected to the applicator, wherein the Z-axis actuator and the rotation device are each capable of moving independently of each other to position the applicator in a position to apply an amount of adhesive to a top substrate prior to bonding with a bottom substrate is provided. Furthermore, a machine comprising an end effector, and an adhesive application valve configured to apply an amount of adhesive onto the top substrate, the end effector configured to place the top substrate into a position of engagement with the adhesive application valve, and place the top substrate onto the bottom substrate to facilitate initial contact between the adhesive applied to the top substrate and a fill material applied to the bottom substrate is also provided. A method of optical bonding is further provided.

Machine For Optical Bonding, System And Method Of Use Thereof
view source
US Patent:

20140305574, Oct 16, 2014
Filed:

Mar 28, 2014
Appl. No.:

14/228621
Inventors:

Andrew John Nally - Greenfield NY, US
Jonathan Neal Urquhart - Saratoga Springs NY, US
Jeffrey James VanNorden - Clifton Park NY, US
Assignee:

PRECISION VALVE & AUTOMATION, INC. - Cohoes NY
International Classification:

B32B 37/14
US Classification:

156 99
Abstract:

An adhesive application valve comprising an applicator, a Z-axis actuator operably connected to the applicator, wherein the Z-axis actuator and the rotation device are each capable of moving independently of each other to position the applicator in a position to apply an amount of adhesive to a top substrate prior to bonding with a bottom substrate is provided. Furthermore, a machine comprising an end effector, and an adhesive application valve configured to apply an amount of adhesive onto the top substrate, the end effector configured to place the top substrate into a position of engagement with the adhesive application valve, and place the top substrate onto the bottom substrate to facilitate initial contact between the adhesive applied to the top substrate and a fill material applied to the bottom substrate is also provided. A method of optical bonding is further provided.
