Jeremy J Guillory

US Patent:

8584744, Nov 19, 2013

Filed:

Sep 13, 2010

Appl. No.:

12/880906

Inventors:

Mohan L. Soni - Katy TX, US
Gerald D. Lynde - Houston TX, US
Ronnie D. Russell - Cypress TX, US
Jeremy J. Guillory - Katy TX, US
Steve Rosenblatt - Houston TX, US

Assignee:

Baker Hughes Incorporated - Houston TX

International Classification:

E21B 33/08
E21B 27/04

US Classification:

166 99, 166162, 166311, 175323

Abstract:

A subterranean debris catcher swirls the incoming debris laden stream by putting grooves or spiral projections on the inside of the inlet pipe. The solids come out of openings in the side of the inlet pipe or the solids can exit near the top either directly into the enclosed solids holding volume as the liquid exits straight out or the solids can be discharged out the end of the inlet pipe into the bigger open space defined by the housing. In the latter case the inside housing wall can have a screen or vanes that slow down the solid particles as the fluid continues to a housing exit and eventually to an exit screen before being discharged to either go to the surface or recirculate back along the outside of the tool to the inlet pipe while picking up additional debris.

US Patent:

20110315390, Dec 29, 2011

Filed:

Aug 23, 2010

Appl. No.:

12/860985

Inventors:

Jeremy J. Guillory - Katy TX, US
Daniel R. Hart - Sugar Land TX, US
Gregory L. Hern - Porter TX, US

Assignee:

Baker Hughes Incorporated - Houston TX

International Classification:

E21B 34/14

US Classification:

166329

Abstract:

A tool for use in a wellbore which includes a housing having an axial flow bore and a piston sleeve moveably disposed within the flow bore. The tool is moveable between first and second operating positions by an actuation mechanism having a piston with a ball seat having a partially annular shape with an outer base and a plurality of retaining segments projecting radially inwardly therefrom. The tool can be moved between first and second operating positions with the use of actuating balls of different sizes that can be landed upon the ball seat.

US Patent:

20140014320, Jan 16, 2014

Filed:

Sep 13, 2013

Appl. No.:

14/026355

Inventors:

Gerald D. Lynde - Houston TX, US
Ronnie D. Russell - Cypress TX, US
Jeremy J. Guillory - Katy TX, US
Steve Rosenblatt - Houston TX, US

Assignee:

Baker Hughes Incorporated - Houston TX

International Classification:

E21B 27/04

US Classification:

166162

Abstract:

A subterranean debris catcher swirls the incoming debris laden stream by putting grooves or spiral projections on the inside of the inlet pipe. In some embodiments the solids come out of openings in the side of the inlet pipe and in others the solids can exit near the top either directly into the enclosed solids holding volume as the liquid exits straight out or the solids can be discharged out the end of the inlet pipe into the bigger open space defined by the housing. In the latter case the inside housing wall can have a screen or vanes that slow down the solid particles as the fluid continues to a housing exit and eventually to an exit screen before being discharged to either go to the surface or recirculate back along the outside of the tool to the inlet pipe while picking up additional debris.

US Patent:

20150000896, Jan 1, 2015

Filed:

Sep 16, 2014

Appl. No.:

14/487979

Inventors:

- Houston TX, US
Gerald D. Lynde - Houston TX, US
Ronnie D. Russell - Cypress TX, US
Jeremy J. Guillory - Katy TX, US
Steve Rosenblatt - Houston TX, US

Assignee:

BAKER HUGHES INCORPORATED - Houston TX

International Classification:

E21B 31/00
E21B 27/00

US Classification:

166 99

Abstract:

A subterranean debris catcher swirls the incoming debris laden stream by putting grooves or spiral projections on the inside of the inlet pipe. In some embodiments the solids come out of openings in the side of the inlet pipe and in others the solids can exit near the top either directly into the enclosed solids holding volume as the liquid exits straight out or the solids can be discharged out the end of the inlet pipe into the bigger open space defined by the housing. In the latter case the inside housing wall can have a screen or vanes that slow down the solid particles as the fluid continues to a housing exit and eventually to an exit screen before being discharged to either go to the surface or recirculate back along the outside of the tool to the inlet pipe while picking up additional debris.

US Patent:

20140374122, Dec 25, 2014

Filed:

Sep 8, 2014

Appl. No.:

14/479445

Inventors:

Thomas J. Fanguy - Broussard LA, US
Robert P. Fanguy - Broussard LA, US
Jake Ryan Guillory - Broussard LA, US
Jeremy Nathanael Guillory - Broussard LA, US

International Classification:

E21B 19/16
E21B 17/043

US Classification:

166380, 166 7751, 285 89

Abstract:

An improved fluid conduit union and method for hammerless attachment apparatus for hammerless coupling the ends of abutting fluid conduits, such as pipe, hoses, or attachment fitting conduits, comprising a ring-shaped conduit receptacle assembly threadedly engaged and fixed on a female fitting at one conduit end and a cylindrical ring-shaped locking assembly positioned around a male fitting at the other conduit end. The ring-shaped locking assembly has a lock ring positionable by a rotatable locking ring nut threadedly engaging the ring-shaped conduit receptacle. Rotation of the locking ring nut translates the lock ring against the male fitting and firmly seats the male fitting at one conduit end to the female fitting at the other conduit end where they are locked in place, all without rotation of either fluid conduit.

US Patent:

20140224496, Aug 14, 2014

Filed:

Feb 8, 2013

Appl. No.:

13/763370

Inventors:

- Houston TX, US
Marcus A. Avant - Kingwood TX, US
Jeremy J. Guillory - Katy TX, US
Donald P. Lauderdale - Cypress TX, US
Steve Rosenblatt - Houston TX, US

Assignee:

Baker Hughes Incorporated - Houston TX

International Classification:

E21B 34/14

US Classification:

1663344, 166373

Abstract:

A diffuser assembly has pairs of split rings rotationally locked to each other in an alternating array with other pairs of split rings where adjacent pairs are responsive to pressure differential to be biased toward a sliding sleeve or the surrounding housing in an alternating pattern. The split rings are made to have an interference initial fit to the sleeve or housing and the splits on adjacent rings are offset while a relation of a projection to a depression between adjacent rings prevents relative rotation to keep the desired circumferential offset in the splits between adjacent rings. End tapers can bias adjacent pairs in opposed directions responsive to applied differential pressure. The rings are preferably metallic and can have a coating to facilitate relative sliding and enhance durability.
