Joel Dean Galliher

US Patent:

48437069, Jul 4, 1989

Filed:

Oct 13, 1987

Appl. No.:

7/107611

Inventors:

Thomas A. Luther - Matthew NC
Robert E. Ward - Charlotte NC
Joel D. Galliher - Charlotte NC
William J. Ryan - Muskego WI

Assignee:

The Warner & Swasey Company - Cleveland OH

International Classification:

B21D 5310

US Classification:

291495R

Abstract:

A roller bearing installation, in which one or more roller bearing assemblies (30A, 30B, 30C) are prepackaged in a housing (18) having corresponding recesses (28A, 28B, 28C) receiving each bearing assembly (30A, 30B, 30C). An angled gib plate (52A, 52B, 52C) is bedded in each recess, each gib plate (52) including an inclined section (54) mating with an inclined surface (58) on a bearing assembly cover (72) to allow a bearing depth adjustment by lengthwise adjustment of the bearing assembly (30) in its recess, enabling position adjustment of the supported structure (10) and bearing preload adjustment. Accurate alignment of the bearing assembly (30) is achieved by a ball plunger (100) urging the same against a guide surface (57) of the gib plate (52). A fixture (110) is used to precisely locate each gib plate (52A, 52B, 52C) in a recess (28) whjile a moldable bonding material (109) in which each gib plate (52) is bedded sets up. Electromagnetic coils (146, 148) are used to releasably hold each gib plate (52) on a respective locator arm (134, 136) during the process.

US Patent:

47309458, Mar 15, 1988

Filed:

Oct 31, 1986

Appl. No.:

6/925208

Inventors:

Thomas A. Luther - Matthew NC
Robert E. Ward - Charlotte NC
Joel D. Galliher - Charlotte NC
William J. Ryan - Muskego WI

Assignee:

The Warner & Swasey Company - Cleveland OH

International Classification:

F16C 2906
F16C 2912

US Classification:

384 45

Abstract:

A roller bearing installation, in which one or more roller bearing assemblies (30A, 30B, 30C) are prepackaged in a housing (18) having corresponding recesses (28A, 28B, 28C) receiving each bearing assembly (30A, 30B, 30C). An angled gib plate (52A, 52B, 52C) is bedded in each recess, each gib plate (52) including an inclined section (54) mating with an inclined surface (58) on a bearing assembly cover (72) to allow a bearing depth adjustment by lengthwise adjustment of the bearing assembly (30) in its recess, enabling position adjustment of the supported structure (10) and bearing preload adjustment. Accurate alignment of the bearing assembly (30) is achieved by a ball plunger (100) urging the same against a guide surface (57) of the gib plate (52). A fixture (110) is used to precisely locate each gib plate (52A, 52B, 52C) in a recess (28) while a moldable bonding material (109) in which each gib plate (52) is bedded sets up. Electromagnetic coils (146, 148) are used to releasably hold each gib plate (52) on a respective locator arm (134, 136) during the process.

US Patent:

48631493, Sep 5, 1989

Filed:

Oct 3, 1988

Appl. No.:

7/253398

Inventors:

Thomas A. Luther - Matthew NC
Robert E. Ward - Charlotte NC
Joel D. Galliher - Charlotte NC
William J. Ryan - Muskego WI

Assignee:

The Warner & Swasey Company - Cleveland OH

International Classification:

B25B 1102

US Classification:

269 8

Abstract:

A roller bearing installation, in which one or more roller bearing assemblies (30A, 30B, 30C) are prepackaged in a housing (18) having corresponding recesses (28A, 28B, 28C) receiving each bearing assembly (30A, 30B, 30C). An angled gib plate (52A, 52C, 52C) is bedded in each recess, each gib plate (52) including an inclined section (54) mating with an inclined surface (58) on a bearing assembly cover (72) to allow a bearing depth adjustment by lengthwise adjustment of the bearing assembly (30) in its recess, enabling position adjustment of the supported structure (10) and bearing preload adjustment. Accurate alignment of the bearing assembly (30) is achieved by a ball plunger (100) urging the same against a guide surface (57) of the gib plate (52). A fixture (110) is used to precisely locate each gib plate (52A, 52B, 52C) in a recess (28) while a moldable bonding material (109) in which each gib plate (52) is bedded sets up. Electromagnetic coils (146, 148) are used to releasably hold each gib plate (52) on a respective locator arm (134, 136) during the process.
