US Patent:

6638378, Oct 28, 2003

Filed:

Jul 3, 2001

Appl. No.:

09/898731

Inventors:

Nelson B. OBryan - Woodbury MN
Robert R. Kieschke - Woodbury MN
Joel S. Peiffer - Maplewood MN

Assignee:

3M Innovative Properties Company - St. Paul MN

International Classification:

C23C 1854

US Classification:

148527, 148536, 148537, 427 79, 427101

Abstract:

A passive electrical article comprising (a) a first self-supporting substrate having two opposing major surfaces, (b) a second self-supporting substrate having two opposing major surfaces, and (c) an electrically insulating or electrically conducting layer comprising a polymer and having a thickness ranging from about 0. 5 to about 10 m between the first and second substrate, wherein a major surface of the first substrate in contact with the layer and a major surface of the second substrate in contact with the layer have an average surface roughness ranging from about 10 to about 300 nm and wherein a force required to separate the first and second substrates of the passive electrical article at a 90 degree peel angle is greater than about 3 pounds/inch (about 0. 5 kN/m), a printed wiring board or a flexible circuit comprising the passive electrical article, an electrical device comprising the printed wiring board or the flexible circuit comprising the passive electrical article, and a method of manufacturing the passive electrical article.

US Patent:

7572031, Aug 11, 2009

Filed:

Jan 31, 2007

Appl. No.:

11/669622

Inventors:

John C. Schultz - Afton MN, US
Andrew J Ouderkirk - Woodbury MN, US
Joel S. Peiffer - Maplewood MN, US
Nelson B. O'Bryan - Tamworth NH, US
John A. Wheatley - Lake Elmo MN, US
Cameron T. Murray - Lake Elmo MN, US

Assignee:

3M Innovative Properties Company - Saint Paul MN

International Classification:

F21V 33/00

US Classification:

362249, 362800

Abstract:

An illumination assembly includes a compliant substrate comprising a first and second electrically conductive foil separated by an electrically insulating layer. The insulating layer includes a polymer material loaded with particles that enhance thermal conductivity of the insulating layer. A plurality of LED dies are disposed on the first conductive foil.

US Patent:

7806560, Oct 5, 2010

Filed:

Jul 8, 2009

Appl. No.:

12/499171

Inventors:

John C. Schultz - Afton MN, US
Andrew J. Ouderkirk - Woodbury MN, US
Joel S. Peiffer - Maplewood MN, US
Nelson B. O'Bryan - Tamworth NH, US
John A. Wheatley - Lake Elmo MN, US
Cameron T. Murray - Lake Elmo MN, US

Assignee:

3M Innovative Properties Company - Saint Paul MN

International Classification:

F21V 33/00

US Classification:

36224902, 36224904, 362800

Abstract:

An illumination assembly includes a compliant substrate comprising a first and second electrically conductive foil separated by an electrically insulating layer. The insulating layer includes a polymer material loaded with particles that enhance thermal conductivity of the insulating layer. A plurality of LED dies are disposed on the first conductive foil.

US Patent:

20060286696, Dec 21, 2006

Filed:

Jun 21, 2005

Appl. No.:

11/157531

Inventors:

Joel Peiffer - Maplewood MN, US
Nelson O'Bryan - Woodbury MN, US

International Classification:

H01L 21/00
H01L 33/00

US Classification:

438027000, 257098000

Abstract:

A passive electrical article includes a first electrically conductive substrate having a major surface and a second electrically conductive substrate having a major surface. The major surface of the second substrate faces the major surface of the first substrate. An electrically resistive layer is on at least one of the major surface of the first substrate and the major surface of the second substrate. An electrically insulative layer is between the first and second substrates and in contact with the electrically resistive layer. The insulative layer is a polymer having a thickness ranging from about 1 μm to about 20 μm. The insulative layer has a substantially constant thickness.

US Patent:

20100208440, Aug 19, 2010

Filed:

Apr 30, 2010

Appl. No.:

12/771501

Inventors:

Joel S. Peiffer - Maplewood MN, US
Nelson B. O'Bryan - Woodbury MN, US

International Classification:

H05K 1/18
H01C 1/012
H01C 17/00

US Classification:

361763, 338314, 296101, 361761

Abstract:

A passive electrical article includes a first electrically conductive substrate having a major surface and a second electrically conductive substrate having a major surface. The major surface of the second substrate faces the major surface of the first substrate. An electrically resistive layer is on at least one of the major surface of the first substrate and the major surface of the second substrate. An electrically insulative layer is between the first and second substrates and in contact with the electrically resistive layer. The insulative layer is a polymer having a thickness ranging from about 1 μm to about 20 μm. The insulative layer has a substantially constant thickness.

US Patent:

20110108309, May 12, 2011

Filed:

Oct 21, 2010

Appl. No.:

12/909462

Inventors:

Joel S. Peiffer - Maplewood MN, US

International Classification:

H05K 1/09
C08L 63/00
C08K 3/22
C08K 3/36
H05K 1/03

US Classification:

174257, 523400, 523458, 523466, 174258

Abstract:

Provided is a dielectric material having a non-halogenated diaminodiphenylsulfone curing agent.

US Patent:

62742248, Aug 14, 2001

Filed:

Feb 1, 1999

Appl. No.:

9/241817

Inventors:

Nelson B. O'Bryan - Woodbury MN
Robert R. Kieschke - Woodbury MN
Joel S. Peiffer - Maplewood MN

Assignee:

3M Innovative Properties Company - St. Paul MN

International Classification:

B32B 300

US Classification:

428209

Abstract:

A passive electrical article comprising (a) a first self-supporting substrate having two opposing major surfaces, (b) a second self-supporting substrate having two opposing major surfaces, and (c) an electrically insulating or electrically conducting layer comprising a polymer and having a thickness ranging from about 0. 5 to about 10. mu. m between the first and second substrate, wherein a major surface of the first substrate in contact with the layer and a major surface of the second substrate in contact with the layer have an average surface roughness ranging from about 10 to about 300 nm and wherein a force required to separate the first and second substrates of the passive electrical article at a 90 degree peel angle is greater than about 3 pounds/inch (about 0. 5 kN/m), a printed wiring board or a flexible circuit comprising the passive electrical article, an electrical device comprising the printed wiring board or the flexible circuit comprising the passive electrical article, and a method of manufacturing the passive electrical article.
