Jon M Ballou

US Patent:

8511688, Aug 20, 2013

Filed:

Feb 23, 2011

Appl. No.:

13/033538

Inventors:

David Gordon Wilson - Winchester MA, US
Jon M. Ballou - Beverly MA, US

Assignee:

Praxair Technology, Inc. - Danbury CT

International Classification:

F16L 17/00

US Classification:

277314, 277312, 277602, 277603, 29592, 29428, 29446, 29450, 29452

Abstract:

An exemplary embodiment disclosed herein relates to an articulatable sealing device. The device includes a plurality of seal elements each of which is urgable against a seal-surface, a fixing member tightenable about a perimeter of the seal elements, and a retractor in operable communication with the plurality of seal elements and able to move the plurality of seal elements in a desired direction.

US Patent:

20070089283, Apr 26, 2007

Filed:

Oct 17, 2006

Appl. No.:

11/582233

Inventors:

David Wilson - Winchester MA, US
Jon Ballou - Beverly MA, US

International Classification:

B21D 39/03

US Classification:

029428000

Abstract:

An exemplary embodiment disclosed herein relates to an articulatable sealing device. The device includes a plurality of seal elements each of which is urgable against a seal-surface, a fixing member tightenable about a perimeter of the seal elements, and a retractor in operable communication with the plurality of seal elements and able to move the plurality of seal elements in a desired direction.

US Patent:

20080251234, Oct 16, 2008

Filed:

Apr 16, 2007

Appl. No.:

11/735835

Inventors:

David Gordon Wilson - Winchester MA, US
Jon M. Ballou - Beverly MA, US
Kelly Ward - Peabody MA, US

Assignee:

WILSON TURBOPOWER, INC. - WOBURN MA

International Classification:

F23L 15/02

US Classification:

165 8

Abstract:

A regenerator wheel is disclosed. The regenerator wheel includes a framework, a plurality of ports disposed within the framework, with at least one port of the plurality of ports separated from another port by the framework. The regenerator wheel also includes a plurality of matrixes aligned individually with the plurality of ports.

US Patent:

20090000761, Jan 1, 2009

Filed:

Jun 29, 2007

Appl. No.:

11/770960

Inventors:

David Gordon Wilson - Winchester MA, US
Jon M. Ballou - Beverly MA, US

Assignee:

WILSON TURBOPOWER, INC. - Woburn MA

International Classification:

F28D 17/04

US Classification:

165 8

Abstract:

A regenerative heat exchanger having an energy-storing drive system includes a high heat capacity matrix rotable about an axis and a drive system that is in operable communication with the high heat capacity matrix and is capable of rotating the high heat capacity matrix about the axis. An energy-storage mechanism is in operable communication with the drive system. The energy-storage mechanism is capable of controlling an acceleration and/or deceleration of rotation of the high heat capacity matrix thus reducing an amount of energy required to be input into the drive system to rotate the high heat capacity matrix.

US Patent:

20090000762, Jan 1, 2009

Filed:

Jun 29, 2007

Appl. No.:

11/770904

Inventors:

David Gordon Wilson - Winchester MA, US
Jon M. Ballou - Beverly MA, US
Kelly Ward - Peabody MA, US

Assignee:

WILSON TURBOPOWER, INC. - Woburn MA

International Classification:

F23L 15/02

US Classification:

165 9

Abstract:

Disclosed is a regenerative heat exchanger including a brush-seal configuration to prevent mixing of fluid flows. The regenerative heat exchanger includes a regenerator, and at least two conduits, each conduit having a matrix end abutting a face of the regenerator matrix. The at least two conduits carrying at least two fluid flows, the fluid flows which pass through the regenerator matrix. The regenerative heat exchanger includes a plurality of brush-seals, each brush-seal located at a matrix end of each conduit without contacting the matrix, thereby sealing around a periphery of each conduit to prevent mixing of fluid flows. Also disclosed is a method for establishing a minimal gap between a regenerator matrix of a regenerative heat exchanger and a plurality of brush-seals.

US Patent:

57352755, Apr 7, 1998

Filed:

Jun 13, 1996

Appl. No.:

8/661794

Inventors:

Jon Ballou - Beverly MA
Francis J. Porter - Millis MA
August O. Westner - Winchester MA

International Classification:

A61B 316

US Classification:

128645

Abstract:

A tonometer for measuring intraocular pressure of an eye is described. The tonometer includes an eyepiece having a conduit extending through an outer surface. The outer surface is concave shaped to conform to an eyeball. The tonometer also includes a plunger extending through the conduit having a head at a first end and having a probe at a second end which extends beyond the outer surface of the eyepiece so as to contact the eyeball when the eyepiece is positioned to conform to the eyeball. The tonometer also includes a fluid reservoir having a top and a bottom. The bottom of the reservoir is sealed by a membrane that is in juxtaposition with the head of the plunger. In addition, the tonometer includes an indicator positioned in the fluid reservoir for measuring a level of fluid in the reservoir. The level of fluid in the reservoir is proportional to an intraocular pressure of the eyeball when the eyepiece is positioned to conform to the eyeball.

US Patent:

46712046, Jun 9, 1987

Filed:

May 16, 1986

Appl. No.:

6/864097

Inventors:

Jon M. Ballou - Danvers MA

Assignee:

Varian Associates, Inc. - Palo Alto CA

International Classification:

F28F 900
B05C 1302

US Classification:

118 59

Abstract:

Apparatus for thermal transfer with a semiconductor wafer in a vacuum processing chamber includes a platen with a surface for supporting the wafer, a clamping ring for clamping the wafer to the platen, and passages for supplying a low pressure gas into a thermal transfer region between the wafer and the platen surface. A low compliance seal surrounds the thermal transfer region and inhibits the gas from reaching the processing chamber without overstressing the wafer. The seal includes an elastomer ring having an elongated cross-section, and a sealing groove having a first groove portion for gripping one edge of the ring and a second groove portion which receives the other edge of the ring by bending deformation thereof when a wafer is clamped to the platen. In a preferred embodiment, the ring has a parallelogram-shaped cross-section and is oriented at an acute angle to the platen surface.

US Patent:

20200098540, Mar 26, 2020

Filed:

Sep 23, 2019

Appl. No.:

16/578847

Inventors:

- Gloucester MA, US
Jon Ballou - Beverly MA, US
James P. Buonodono - Amesbury MA, US

Assignee:

Varian Semiconductor Equipment Associates, Inc. - Gloucester MA

International Classification:

H01J 37/08
H01J 37/04

Abstract:

In one embodiment, an ion extraction optics for extracting a plurality of ion beams is provided. The ion extraction optics may include, an extraction plate, the extraction plate defining a cut-out region, the cut-out region being elongated along a first direction. The extraction apparatus may include a slidable insert, the slidable insert disposed to overlap the cut-out region, and slidably movable with respect to the extraction plate, along the first direction, wherein the slidable insert and cut-out region define a first aperture and a second aperture.
