Joseph M Herko

US Patent:

40300153, Jun 14, 1977

Filed:

Oct 20, 1975

Appl. No.:

5/624217

Inventors:

Joseph Michael Herko - Boca Raton FL
James Maurice Joyce - Boca Raton FL

Assignee:

International Business Machines Corporation - Armonk NY

International Classification:

H02P 1332

US Classification:

321 2

Abstract:

Disclosed herein is an improved pulse width modulated (PWM) voltage regulator-converter system which can function, alone, as a switched voltage regulator system or in combination with a switched power converter, synchronized therewith to form an improved voltage regulator-converter/power converter system. In the pulse width modulated voltage regulator-converter embodiment of the invention, secondary windings of a "current mode" regulator-converter interstage transformer are coupled to regulator-converter power transistors in a push-push circuit configuration. Signals generated by a system clock means and an error signal, derived from the output of an averaging filter, drive a pulse width modulated control means connected to the primary windings of the regulator-converter interstage transformer to thereby increase the maximum regulated output voltage of the voltage regulator-converter system after conditioning in the averaging filter. In the pulse width modulated voltage regulator-converter/power converter embodiment of the invention, the aforementioned output voltage of the voltage regulator-converter system is coupled directly to a switched power converter connected in a push-pull circuit configuration. In turn, additional signals generated by the system clock means switch the power converter in synchronizm with the voltage regulator-converter system.
