Justin M Jacobs

US Patent:

8430210, Apr 30, 2013

Filed:

Jan 19, 2011

Appl. No.:

13/009701

Inventors:

Justin Jacobs - Menlo Park CA, US

Assignee:

Smart Lifts, LLC - Menlo Park CA

International Classification:

B66B 11/08
B66B 9/00
B66B 7/06

US Classification:

187249, 187257, 187258, 187266, 187404

Abstract:

An elevator system which utilizes four or more independently moving cabs in each elevator shaft. The lower cabs are connected to four spatially separated counterweights at four different counterweight connection points. The connection points are horizontally shifted on different cabs in order to prevent interference between cables, pulleys and counterweights. The top cab may be connected to one or two counterweights by connection points on the roof of the cab. The cabs are mounted on two tracks, each track on one side of the elevator shaft. The system includes a motor attached to each of the cabs by lift cables to facilitate the independent movement of all cabs. Existing buildings can be retrofit for compatibility with the present invention.

US Patent:

20130213743, Aug 22, 2013

Filed:

Mar 25, 2013

Appl. No.:

13/850107

Inventors:

Smart Lifts, LLC - , US
Justin Jacobs - Menlo Park CA, US

Assignee:

Smart Lifts, LLC - Menlo Park CA

International Classification:

B66B 9/00

US Classification:

187249

Abstract:

An elevator system which utilizes four or more independently moving cabs in each elevator shaft. The lower cabs are connected to four spatially separated counterweights at four different counterweight connection points. The connection points are horizontally shifted on different cabs in order to prevent interference between cables, pulleys and counterweights. The top cab may be connected to one or two counterweights by connection points on the roof of the cab. The cabs are mounted on two tracks, each track on one side of the elevator shaft. The system includes a motor attached to each of the cabs by lift cables to facilitate the independent movement of all cabs. Existing buildings can be retrofit for compatibility with the present invention.

US Patent:

20130306408, Nov 21, 2013

Filed:

Jul 26, 2013

Appl. No.:

13/952528

Inventors:

Justin Jacobs - Menlo Park CA, US

Assignee:

SMART LIFTS, LLC - Menlo Park CA

International Classification:

B66B 9/00

US Classification:

187249

Abstract:

An elevator system which utilizes a plurality of independently moving cabs and counterweights in each elevator shaft. Each cab is connected to one or more spatially separated counterweights at different counterweight connection points. The connection points are horizontally shifted on different cabs in order to prevent interference between cabs, cables, pulleys and counterweights. The top cab may have one counterweight cable and may be connected to one or more counterweights by connection points on the roof of the cab. The cabs are mounted on two opposing vertical guide rails, and each guide rail is mounted at the center of one side of the elevator shaft. The system includes a motor attached to each of the cabs by one or more lift cables to facilitate the independent movement of all cabs. Existing buildings can also be retrofit for compatibility with the present invention.

US Patent:

60446722, Apr 4, 2000

Filed:

Jul 27, 1999

Appl. No.:

9/371865

Inventors:

Justin Jacobs - San Francisco CA

International Classification:

B60R 2502

US Classification:

70209

Abstract:

A method for removing a steering wheel lock using a device having a main body having a center opening and a pair of supporting arms extending outwardly and downwardly. The device further comprises a central shaft extending through the center opening in the main body. The central shaft includes an externally threaded portion and a hook portion extending therefrom for grabbing the steering wheel lock. A crank arm having an internally threaded bore is rotatably mounted to the externally threaded portion of the central shaft. To remove a steering wheel lock from a steering wheel, the crank arm is manually rotated which advances the central shaft in an upward direction which in turn pulls at the grab point of the steering wheel lock while the supporting arms of the main body holds the remainder of the steering wheel lock in place, thereby bending the steering wheel lock. The steering wheel lock may be removed from the steering wheel when it either breaks, or is sufficiently bent to allow the hooks on the steering wheel lock to become disengaged from the rim of the steering wheel.

US Patent:

20180354752, Dec 13, 2018

Filed:

Aug 20, 2018

Appl. No.:

16/105924

Inventors:

- Menlo Park CA, US
Justin Jacobs - Menlo Park CA, US

International Classification:

B66B 9/00
B66B 11/00

Abstract:

An elevator system comprising multiple elevator cabs operating independently in an elevator shaft. Each cab comprises a pair of underslung suspension cables, equally spaced apart from the center of the cab; a lift motor at a top surface of the shaft having an axle with a traction sheave at each end of the axle; each set of suspension cables connected at a first end to a hook at the top surface, engaging a pulley connected to a counterweight, engaging a first traction sheave, engaging a cab pulley, slung under the cab, engaging a second cab pulley and terminating at a second end connected to the top surface. Each set of four cab pulleys of each elevator cab is progressively and symmetrically located closer to the center of each cab, so that suspension cables, counterweights, pulleys, hooks, lift motors, axles, and traction sheaves will not horizontally or vertically conflict with each other.

US Patent:

20170275137, Sep 28, 2017

Filed:

Mar 25, 2016

Appl. No.:

15/081741

Inventors:

- Menlo Park CA, US
Justin Jacobs - Menlo Park CA, US

International Classification:

B66B 9/00
B66B 11/00

Abstract:

An elevator system comprising multiple elevator cabs operating independently in an elevator shaft. Each cab comprises a pair of underslung suspension cables, equally spaced apart from the center of the cab; a lift motor at a top surface of the shaft having an axle with a traction sheave at each end of the axle; each set of suspension cables connected at a first end to a hook at the top surface, engaging a pulley connected to a counterweight, engaging a first traction sheave, engaging a cab pulley, slung under the cab, engaging a second cab pulley and terminating at a second end connected to the top surface. Each set of four cab pulleys of each elevator cab is progressively and symmetrically located closer to the center of each cab, so that suspension cables, counterweights, pulleys, hooks, lift motors, axles, and traction sheaves will not horizontally or vertically conflict with each other.

US Patent:

20170088393, Mar 30, 2017

Filed:

Sep 28, 2015

Appl. No.:

14/868293

Inventors:

- Menlo Park CA, US
Justin Jacobs - Menlo Park CA, US

International Classification:

B66B 1/24
B66B 9/00

Abstract:

A system and method for controlling multiple elevator cabs in an elevator shaft of a structure, where at least one elevator shaft having a plurality of zones, each zone representing at least one floor of the structure; at least one zone having at least one sensor; at least two elevator cabs moveable within the shaft, each cab moveable independently of other cabs; and a controller that determines movement of each cab into a zone. A first cab preceding any other cab, designated a leading cab; each cab following the leading cab, designated as a trailing cab; each cab moveable in the same direction of travel to service zones until each cab reaches its designated end zone; wherein the controller only instructs a trailing cab to move into a zone with a sensor, after the sensor in the zone detects a cab that was located in such zone has exited that zone thereby preventing collisions.

US Patent:

20170088399, Mar 30, 2017

Filed:

Sep 28, 2015

Appl. No.:

14/868295

Inventors:

- Menlo Park CA, US
Justin Jacobs - Menlo Park CA, US

International Classification:

B66B 9/00
B66B 9/16

Abstract:

An elevator system permitting horizontal movement of a normally vertically moving elevator cabin, the elevator cabin being automatically attached to or detached from an elevator frame and horizontally moved to or from another elevator shaft or other destination. While an elevator cabin is supported on an elevator frame or other surface, various cables, rods, plugs and other equipment are automatically connected to or disconnected from the elevator cabin to enable vertical or horizontal motion of the elevator cabin. Once disconnected from such devices, the elevator cabin can be propelled horizontally out of the elevator frame and elevator shaft, onto other surfaces, such as floors of a building, and move horizontally to another destination. An elevator cabin may also be horizontally moved into an elevator shaft and onto the surface of an elevator frame, and connected to the frame, thus enabling such cabin to then move vertically within an elevator shaft.
