Kenneth L Zagorski

US Patent:

20050253024, Nov 17, 2005

Filed:

May 12, 2004

Appl. No.:

10/844090

Inventors:

Kenneth Zagorski - Houston TX, US
Joseph Donoghue - Houston TX, US
Michael Bock - Houston TX, US

International Classification:

F16L003/00

US Classification:

248065000

Abstract:

A pipe anchor having: a base cradle with a lug; a top cradle with a lug and secured to the base cradle so as to encircle a pipe within the base cradle and the top cradle; a locking mechanism with opposite mating components attached to the base cradle and the top cradle; at least one lug attached to the pipe; and insulation material filling a space between the pipe and the cradles, wherein the insulation material engages the at least one lug of the pipe and the lugs of the cradles.

US Patent:

20130022783, Jan 24, 2013

Filed:

Feb 28, 2012

Appl. No.:

13/406561

Inventors:

Kenneth L. Zagorski - Houston TX, US
Joseph Donoghue - Houston TX, US
Mike Bock - Cypress TX, US

International Classification:

B32B 3/10

US Classification:

428134, 428137

Abstract:

A reinforced insulation material having one or more sheets of insulation material having a plurality of voids in each sheet, wherein the sheets are operably connected to each other in a layered configuration, the voids mate to each other to create cylindrical or rectilinear pathways for insertion of adhesive or synthetic material to adhere the sheets into a layered or sandwiched configuration. The voids may be a variety of shapes including circles, squares, rectangles or other suitable shapes that upon formation of the layered sheets line up to permit insertion of material or dowels to create a reinforced assembly. The layers may be formed into a variety of shapes including a semicircular shape to go around a pipe, or a block of material. The finished assembly withstands compressive forces and provides insulation when in place around pipes or under tanks.

US Patent:

20130048798, Feb 28, 2013

Filed:

Aug 26, 2011

Appl. No.:

13/219206

Inventors:

Michael E. Bock - Houston TX, US
Joseph A. Donoghue - Houston TX, US
Kenneth L. Zagorski - Houston TX, US

International Classification:

F16L 3/10

US Classification:

248 675

Abstract:

A pipe anchor is disclosed having a pipe trunnion stop for attaching to an outer surface of a pipe by welding. A mating top cradle and bottom cradle generally encircle and hold a length of the pipe. The bottom cradle has a pass-through to accommodate the pipe trunnion stop. There is a base onto which the bottom cradle sets, the base includes a void into which the pipe trunnion is secured. An insulation layer is positioned between the pipe and the top cradle and bottom cradle, and around the pipe trunnion stop. A bolting assembly on the top cradle portion and a mating bolting assembly on the bottom cradle portion secures the top cradle portion and the bottom cradle portion to each other. Another embodiment includes multiple pipe trunnion stops along with respective pass-through and base void sections.

US Patent:

20150316176, Nov 5, 2015

Filed:

Jun 15, 2015

Appl. No.:

14/739902

Inventors:

Kenneth L. Zagorski - Houston TX, US
Joseph A. Donoghue - Houston TX, US
Michael E. Bock - Houston TX, US

International Classification:

F16L 3/10
F16L 59/14

Abstract:

A pipe anchor is disclosed having a pipe trunnion stop for attaching to an outer surface of a pipe by welding. A mating top cradle and a bottom cradle generally encircle and hold a length of the pipe. The bottom cradle has a pass-through to accommodate the pipe trunnion stop. There is a base onto which the bottom cradle sets, the base includes a void into which the pipe trunnion stop is secured. An insulation layer is positioned between the pipe and the top cradle and bottom cradle, and around the pipe trunnion stop. A bolting assembly on the top cradle and a mating bolting assembly on the bottom cradle secure the top cradle and the bottom cradle to each other. Another embodiment includes multiple pipe trunnion stops along with respective pass-through and base void sections.
