Kevin P. McAlea - Austin TX Paul F. Forderhase - Austin TX Mark E. Ganninger - Pflugerville TX Frederic W. Kunig - Akron OH Angelo J. Magistro - Brecksville OH
Assignee:
DTM Corporation - Austin TX
International Classification:
B29C 3508 B29C 4102
US Classification:
264497
Abstract:
A composite powder specially adapted for use in selective laser sintering is disclosed. The composite powder includes a polymer powder dry mixed with a reinforcement powder, where the polymer powder has a melting temperature substantially lower than that of the reinforcement powder. In the case where nearfully dense parts are to be formed, the first constituent powder is preferably a semi-crystalline powder, for example nylon 11, of a composition suitable for forming near-fully dense parts when used unblended in selective laser sintering; if porous parts are desired, the polymer powder is an amorphous powder, such as polycarbonate, polystyrene, acrylates, and styrene/acrylate copolymers. The reinforcement powder is preferably microspheres of glass, preferably coated to enhance wetting and adhesion with the polymer powder when selective laser sintering is performed. Besides improving the stiffness and heat resistance of the part produced, the composite powder widens the process window over that provided by unblended powder, provides improved dimensional accuracy in the part produced, and facilitates roughbreakout and smooth finishing of the part produced.
Sinterable Semi-Crystalline Powder And Near-Fully Dense Article Formed Therewith
Elmer D. Dickens - Richfield OH Biing L. Lee - Broadview Heights OH Glenn A. Taylor - Twinsburg OH Angelo J. Magistro - Brecksville OH Hendra Ng - E. Cleveland OH Kevin McAlea - Austin TX Paul F. Forderhase - Austin TX
Assignee:
DTM Corporation - Austin TX
International Classification:
C08G 6914
US Classification:
528323
Abstract:
A laser-sinterable powder product has been prepared having unique properties which allow the powder to be sintered in a selective laser sintering machine to form a sintered part which is near-fully dense. For most purposes, the sintered part is indistinguishable from another part having the same dimensions made by isotropically molding the powder. In addition to being freely flowable at a temperature near its softening temperature, a useful powder is disclosed that has a two-tier distribution in which substantially no primary particles have an average diameter greater than 180. mu. m, provided further that the number average ratio of particles smaller than 53. mu. m is greater than 80%, the remaining larger particles being in the size range from 53. mu. m to 180. mu. m. A powder with slow recrystallization rates, as evidenced by non-overlapping endothermic and exothermic peaks in their differential scanning calorimetry characteristics for scan rates of on the order of 10. degree. C. to 20. degree. C. per minute, will also result in sintered parts that are near-fully dense, with minimal dimensional distortion.
Sinterable Semi-Crystalline Powder And Near-Fully Dense Article Formed Therein
Elmer Douglas Dickens - Richfield OH Biing Lin Lee - Broadview Heights OH Glenn Alfred Taylor - Houston TX Angelo Joseph Magistro - Brecksville OH Hendra Ng - E. Cleveland OH Kevin P. McAlea - Austin TX Paul F. Forderhase - Austin TX
Assignee:
DTM Corporation - Austin TX
International Classification:
C08G 6914
US Classification:
528323
Abstract:
A laser-sinterable powder product has been prepared having unique properties which allow the powder to be sintered in a selective laser sintering machine to form a sintered part which is near-fully dense. For most purposes, the sintered part is indistinguishable from another part having the same dimensions made by isotropically molding the powder. In addition to being freely flowable at a temperature near its softening temperature, a useful powder is disclosed that has a two-tier distribution in which substantially no primary particles have an average diameter greater than 180. mu. m, provided further that the number average ratio of particles smaller than 53. mu. m is greater than 80%, the remaining larger particles being in the size range from 53. mu. m to 180. mu. m. A powder with slow recrystallization rates, as evidenced by non-overlapping or slightly overlapping endothermic and exothermic peaks in their differential scanning calorimetry characteristics for scan rates of on the order of 10. degree. C. to 20. degree. C. per minute, will also result in sintered parts that are near-fully dense, with minimal dimensional distortion.
Sinterable Semi-Crystalline Powder And Near-Fully Dense Article Formed Therewith
Elmer Douglas Dickens - Richfield OH Biing Lin Lee - Broadview Heights OH Glenn Alfred Taylor - Houston TX Angelo Joseph Magistro - Brecksville OH Hendra Ng - E. Cleveland OH Kevin P. McAlea - Austin TX Paul F. Forderhase - Austin TX
Assignee:
DTM Corporation - Austin TX
International Classification:
C08G 6914
US Classification:
528323
Abstract:
A laser-sinterable powder product has been prepared having unique properties which allow the powder to be sintered in a selective laser sintering machine to form a sintered part which is near-fully dense. For most purposes, the sintered part is indistinguishable from another part having the same dimensions made by isotropically molding the powder. In addition to being freely flowable at a temperature near its softening temperature, a useful powder is disclosed that has a two-tier distribution in which substantially no primary particles have an average diameter greater than 180. mu. m, provided further that the number average ratio of particles smaller than 53. mu. m is greater than 80%, the remaining larger particles being in the size range from 53. mu. m to 180. mu. m. A powder with slow recrystallization rates, as evidenced by non-overlapping or slightly overlapping endothermic and exothermic peaks in their differential scanning calorimetry characteristics for scan rates of on the order of 10. degree. C. to 20. degree. C. per minute, will also result in sintered parts that are near-fully dense, with minimal dimensional distortion.
Ultrasonic Device And Method For Non-Destructive Evaluation Of Polymer Composites
Barbara J. McKinley - Castleton NY Dean S. Matsumoto - Niskayuna NY Robert S. Gilmore - Burnt Hills NY Kevin P. McAlea - Austin TX
Assignee:
General Electric Company - Schenectady NY
International Classification:
G01N 2918
US Classification:
73597
Abstract:
An ultrasonic measurement device and a method for a non-destructive evaluation of polymer composites having discontinuous fibers distributed therein. The device has one or a plurality of substantially matched pairs of transducers disposed on wedge shaped focuser and a relay, the focuser and relay each have their impedances substantially matched to that of the polymer composite being analyzed. The device is placed on a surface of the composite with the apexes of the focuser and relay in close contact with the surface. A velocity of a substantially longitudinal ultrasonic wave generated by the first transducer and received by the second transducer after its passage through the composite is determined at several angles of orientations about a center point, and the measured velocities of the ultrasonic wave are processed through a computer having software to determine the physical attributes of the composite, such as weight percentage of fibers present in the composite, Young's modulus, shear modulus and Poisson's ratio of the composite.
Method Of Forming Three-Dimensional Articles Using Thermosetting Materials
Udaykumar Lakshminarayan - Austin TX Kevin P. McAlea - Austin TX Richard B. Booth - Pflugerville TX
Assignee:
DTM Corporation - Austin TX
International Classification:
B22F 102 B22F 326
US Classification:
419 2
Abstract:
A method of fabricating articles, such as prototype parts and prototype tooling for injection molding, is disclosed. The method begins with the fabrication of the article in a "green" state by the selective laser sintering, or another additive thermal process, applied to a composite powder, preferably a powder of metal particles coated with a thermoplastic polymer. Both the green article and also an aqueous emulsion of a thermosetting material are then preheated to a temperature below the glass transition temperature of the thermoplastic polymer, and the green article is then infiltrated with the aqueous emulsion. The thermosetting material may be a thermosetting polymer with an appropriate cross-linking agent, or may be a cross-linking agent that will react with the thermoplastic binder polymer. After infiltration, the article is dried, and a rigid skeleton of a thermosetting material is now present within the structure of the article. Further processing may now be performed.
Selective Laser Sintering Of Polymer Powder Of Controlled Particle Size Distribution
Kevin P. McAlea - Austin TX Paul F. Forderhase - Austin TX Richard B. Booth - Pflugerville TX
Assignee:
DTM Corporation - Austin TX
International Classification:
B27N 300 B32B 3100
US Classification:
1562728
Abstract:
A powder for use in selective laser sintering, from which prototype articles and masters for molds may be formed, is disclosed. The powder is formed by spray drying a polymer emulsion to yield a distribution of particles of substantially spherical shape. The powder is then air classified to remove excessively small particles from the distribution; the powder may also be screened to remove large particles therefrom, as well. The resulting distribution of particle sizes, by volume, preferably has a mean particle size of between about 20. mu. and about 50. mu. , with preferably less than about 5% (by volume) of its particles with a size of less than about 15. mu. and less than about 2% (by volume) of its particles with a size of greater than about 75. mu. The powder is subjected to selective laser sintering to produce an article of approximately 55% to 75% of theoretical density. The article may be used as a prototype article or part, or as a pattern or master for a mold.
Resumes
Executive Vice President Healthcare And Metals Business Units
3D Systems since 2007
SVP & GM Production Printers
3D Systems 2004 - 2007
Vice President Marketing
3D Systems 2001 - 2004
VP & GM 3D Systems Europe
DTM Corporation 1993 - 2001
Vice President Marketing & Business Dev
General Electric 1985 - 1993
Manager Polymer Physics Program
Education:
University of Delaware 1981 - 1985
PhD, Chemical Engineering
University of California, Berkeley 1977 - 1981
BS, Chemical Engineering
Skills:
Vendor Management Stereolithography 3D Printing Strategic Planning Product Development Rapid Prototyping Product Management Business Development Manufacturing Cross Functional Team Leadership Management Operations Management Sales Management New Business Development Strategy Engineering Product Marketing Business Strategy R&D Direct Sales
