Us Patents
Method Of Forming An Integrated Circuit Including Filling And Planarizing A Trench Having An Oxygen Barrier Layer
Reda R. Razouk - Sunnyvale CA Kulwant S. Egan - San Jose CA Wipawan Yindeepol - San Jose CA Waclaw C. Koscielniak - Santa Clara CA
Assignee:
National Semiconductor Corporation - Santa Clara CA
International Classification:
H01L 2162
US Classification:
438424
Abstract:
A trench which has walls intersecting a surface of a semiconductor substrate and an oxidation/diffusion barrier layer lining the walls is disclosed. The oxidation/diffusion barrier extends over the edges of the trench to prevent, for example, stress defects in the trench corners and vertical bird's beak formation within the trench. A filler material such as polysilicon is deposited within the trench followed by the deposition of a planarizing layer over the trench. After heat is applied, the planarizing layer flows to form a planarized layer over the trench. Using high pressure and phosphosilicate glass for the planarizing layer, the planarizing layer flows appropriately at low temperatures for short times.
Integrated Circuit With Trenches And An Oxygen Barrier Layer
Reda R. Razouk - Sunnyvale CA Kulwant S. Egan - San Jose CA Wipawan Yindeepol - San Jose CA Waclaw C. Koscielniak - Santa Clara CA
Assignee:
National Semiconductor Corporation - Santa Clara CA
International Classification:
H01L 2712
US Classification:
257513
Abstract:
A trench which has walls intersecting a surface of a semiconductor substrate and an oxidation/diffusion barrier layer lining the walls is disclosed. The oxidation/diffusion barrier extends over the edges of the trench to prevent, for example, stress defects in the trench corners and vertical bird's beak formation within the trench. A filler material such as polysilicon is deposited within the trench followed by the deposition of a planarizing layer over the trench. After heat is applied, the planarizing layer flows to form a planarized layer over the trench. Using high pressure and phosphosilicate glass for the planarizing layer, the planarizing layer flows appropriately at low temperatures for short times.
Forming A Self-Aligned Epitaxial Base Bipolar Transistor
Waclaw C. Koscielniak - Santa Clara CA Kulwant S. Egan - San Jose CA Jayasimha S. Prasad - San Jose CA
Assignee:
National Semiconductor Corporation - Santa Clara CA
International Classification:
H01K 27082
US Classification:
257565
Abstract:
An improved method and an apparatus for forming a self-aligned epitaxial base bipolar transistor in a semiconductor material is disclosed. The method of the invention involves forming an intrinsic base region formed by growing an epitaxial semiconductor material over a collector region. A raised sacrificial emitter core is then formed on the intrinsic base region followed by depositing a substantially conformal spacer layer over the sacrificial emitter core. Next, the spacer material is anisotropically etched such that a protective spacer ring is formed about the sacrificial emitter core. An extrinsic base is then formed by implanting dopant into the epitaxial base region wherein the sacrificial emitter core and the spacer ring preserve an emitter region. The spacer ring also serves to self-align the extrinsic base region to the emitter region. The protective sacrificial emitter core and spacer ring are then removed.
Forming A Self-Aligned Epitaxial Base Bipolar Transistor
Waclaw C. Koscielniak - Santa Clara CA Kulwant S. Egan - San Jose CA Jayasimha S. Prasad - San Jose CA
Assignee:
National Semiconductor Corporation - Santa Clara CA
International Classification:
H01L 21331
US Classification:
438341
Abstract:
An improved method and an apparatus for forming a self-aligned epitaxial base bipolar transistor in a semiconductor material is disclosed. The method of the invention involves forming an intrinsic base region formed by growing an epitaxial semiconductor material over a collector region. A raised sacrificial emitter core is then formed on the intrinsic base region followed by depositing a substantially conformal spacer layer over the sacrificial emitter core. Next, the spacer material is anisotropically etched such that a protective spacer ring is formed about the sacrificial emitter core. An extrinsic base is then formed by implanting dopant into the epitaxial base region wherein the sacrificial emitter core and the spacer ring preserve an emitter region. The spacer ring also serves to self-align the extrinsic base region to the emitter region. The protective sacrificial emitter core and spacer ring are then removed.
