An improved ballcock assembly for a toilet water reservoir which provides quiet reservoir refill operation without requiring a conventional water discharge hush tube. Quiet refill operation is provided by discharging refill water through a plurality of openings which create individual streams of water which flow along the side surfaces of a standpipe having longitudinally extending external ridges or walls. The walls maintain the separation of the individual water streams which cascade down the standpipe surface. The outside surface of the standpipe is preferably tapered outwardly from top to bottom so that the water flows along a tapered surface which reinforces the cascading flow regime. The reduced flow for each stream and the cascading flow action combine to provide quiet refill operation. Since the ballcock assembly refill openings are above reservoir tank water level, water normally cannot be sucked through them and into the water supply system.
Charles T. Rothe - Providence KY Larry D. Gish - Robards KY
International Classification:
F16K 3134 F16K 3300
US Classification:
137414
Abstract:
A ballcock assembly having an upright standpipe for delivery of flush water, a control valve assembly at the upper end of the standpipe, and a float and ballast assembly slidably mounted for up and down movement relative to the standpipe and connected to the control valve assembly. The control valve assembly operates to open the valve to flow of flush water from the standpipe assembly in response to downward movement of the float and ballast assembly. When the float assembly is caused to rise by incoming flush water from the standpipe, it ultimately causes the control valve to shut off incoming flow of flush water from the standpipe.
Larry D. Gish - Robards KY Tim A. Frick - Strongsville OH Ross E. Kingman - Elyria OH Edward D. Kastelic - Sheffield Village OH
Assignee:
Moen Incorporated - North Olmsted OH
International Classification:
F16K 3134 F16K 3300
US Classification:
137426
Abstract:
An adjustable height fill valve for controlling the water level in a storage tank for a toilet includes a riser mounted in the tank and connected to a pressurized water supply. The riser includes an anti-siphon body telescopically mounted over a fixed shank. The anti-siphon body telescopically adjusts between retracted and extended positions. A pilot valve is mounted on the anti-siphon body in fluid communication with the water supply. A float is mounted in association with the pilot valve to selectively open or close the pilot valve depending on the water level in the tank. A latch on the anti-siphon body and a series of stops on the shank are releasably engageable to adjustably fix the position of the body on the shank between the retracted and extended positions. The stops comprise first and second sets of axially spaced and interleaved fingers which define a serpentine track into which the latch extends.
