Leonard A Nass

US Patent:

20140276289, Sep 18, 2014

Filed:

Mar 17, 2014

Appl. No.:

14/216030

Inventors:

- Eatontown NJ, US
Leonard Nass - Eatontown NJ, US

International Classification:

A61H 9/00
A61H 1/00

US Classification:

601152, 601151

Abstract:

A deep vein thrombosis prevention garment includes a central panel formed to have three (3) sequentially filled air chambers separated from each other with a pressure resistive valve, a left side panel, and a right side panel formed with a number of attachment straps having an integral fastener. The first air chamber receives air from a pump. When the air within the first air chamber reaches a predetermined air pressure, the pressure resistive valve between the first air chamber and the second air chamber allows air to pass from the first air chamber to a second air chamber. When the air within the second air chamber reaches a predetermined air pressure, the pressure resistive valve between the second air chamber and the third air chamber allows air to pass from the second chamber to the third air chamber. A membrane panel allows air to escape the sequentially filled air chambers.

US Patent:

20140276290, Sep 18, 2014

Filed:

Mar 17, 2014

Appl. No.:

14/216244

Inventors:

- Eatontown NJ, US
Leonard Nass - Eatontown NJ, US

International Classification:

A61H 9/00

US Classification:

601152

Abstract:

A compact mini air pump includes a rectangular, box-shaped body having a standard AC power cord extending from it, two air supply output ports, and a control and information panel with user-operated buttons and status lights located on its front side. Within the hollow interior of the body is an air compressor, a dual-output electromechanical valve having to two air output tubes, an air pressure sensor, a DC battery power supply, an AC power connection, and an electronic circuit board controlling the mini air pump's function. The air supply output ports, an extension of the air tubes within the body, supply air to Intermittent Pneumatic Compression (“IPC”) Therapy device garments through flexible air supply tubes. The mini air pump device is sized to be held by one hand for portability.

US Patent:

20140276291, Sep 18, 2014

Filed:

Mar 17, 2014

Appl. No.:

14/216290

Inventors:

- Eatontown NJ, US
Leonard Nass - Eatontown NJ, US

International Classification:

A61H 9/00

US Classification:

601152

Abstract:

A digital display air pump includes a rectangular, box-shaped body having a standard AC power cord extending from it, two air supply output ports, and a control and information panel located on its front side with user-operated buttons, a digital display for showing air pressure and alarm codes, a variable air pressure set dial, and status lights. Within the hollow interior of the body is an air compressor, a dual-output electromechanical valve having to two air output tubes, an air pressure sensor, an AC power connection, an internal loudspeaker, and an electronic circuit board controlling the digital display air pump's function. The air supply output ports, an extension of the air tubes within the body, supply air to Intermittent Pneumatic Compression (“IPC”) Therapy device garments through flexible air supply tubes.

US Patent:

20140276292, Sep 18, 2014

Filed:

Mar 17, 2014

Appl. No.:

14/216866

Inventors:

- Eatontown NJ, US
Leonard Nass - Eatontown NJ, US

International Classification:

A61H 9/00
A61H 1/00

US Classification:

601152, 601151

Abstract:

A deep vein thrombosis prevention garment having an integrated air bladder includes a body having a central panel, a left side panel, and a right side panel formed with a number of attachment straps having an integral fastener, such as Velcro brand hook and loop fasteners. The central panel is formed to have a single air chamber receiving air from a pump through a flexible air supply tube. The central panel, left side panel and right side panel are formed from a single material which does not require a skin-safe liner or other combination of materials. A single-chamber bladder is attached to the central panel. A cover panel covers the single-chamber bladder and is attached along its perimeter to the central panel. The cover panel and the body are made from the same material which can be placed against a patient's skin.

US Patent:

20140276293, Sep 18, 2014

Filed:

Mar 17, 2014

Appl. No.:

14/217000

Inventors:

- Eatontown NJ, US
Leonard Nass - Eatontown NJ, US

International Classification:

A61H 9/00
A61H 1/00

US Classification:

601152, 601148

Abstract:

An adhesive single chamber deep vein thrombosis prevention garment includes a body having a central panel, a left side panel, and a right side panel formed with attachment straps having hook and loop integral fasteners. The central panel is formed to have a single air chamber which receives air from a pump through a flexible air supply tube. The inside of the single air chamber is coated with a tacky adhesive layer providing distal-to-proximal sequential inflation as air is progressively introduced into the chamber, thereby creating a distal-to-proximal pressure gradient on a patient's limb. The central, left side and right side panels are formed from a single material which does not require a skin-safe liner or other combination of materials. A cover panel attached to the central panel to cover the single-chamber bladder and the body is made from the same material which can be placed against a patient's skin.

US Patent:

20140276294, Sep 18, 2014

Filed:

Mar 17, 2014

Appl. No.:

14/217068

Inventors:

- Eatontown NJ, US
Leonard Nass - Eatontown NJ, US

Assignee:

Compression Therapy Concepts, Inc. - Eatontown NJ

International Classification:

A61H 9/00
A61H 1/00

US Classification:

601152, 601148

Abstract:

A deep vein thrombosis prevention garment includes a central panel formed with sequentially filled inner, intermediate and outer air chambers separated from each other with pressure resistive valves, a left side panel, and a right side panel formed with a number of attachment straps having an integral fastener. The inner air chamber receives air from a pump. When the air within the inner air chamber reaches a predetermined air pressure, the pressure resistive valve between the inner air chamber and the intermediate air chamber allows air to pass from the inner air chamber to an intermediate air chamber. When the air within the intermediate air chamber reaches a predetermined air pressure, the pressure resistive valve between the intermediate air chamber and the outer air chamber allows air to pass from the intermediate chamber to the outer air chamber. A membrane panel allows air to escape the sequentially filled air chambers.

US Patent:

20140276295, Sep 18, 2014

Filed:

Mar 17, 2014

Appl. No.:

14/217147

Inventors:

- Eatontown NJ, US
Leonard Nass - Eatontown NJ, US

International Classification:

A61H 1/00
A61H 9/00

US Classification:

601152, 601151

Abstract:

A deep vein thrombosis prevention garment includes a body having a central panel, a left side panel, and a right side panel formed with a number of attachment straps having an integral fastener, such as Velcro brand hook and loop fasteners. The central panel is formed with a single air chamber containing a single expandable air bladder receiving air from a pump through a flexible air supply tube. The central panel, left side panel and right side panel are formed from a single material which does not require a skin-safe liner or other combination of materials. The single chamber with nested expandable bladder is attached to the central panel. A cover panel covers the chamber having an expandable bladder, and is attached along its perimeter to the central panel. The cover panel and the body are made from the same material which can be placed against a patient's skin.

US Patent:

20140276296, Sep 18, 2014

Filed:

Mar 17, 2014

Appl. No.:

14/217178

Inventors:

- Eatontown NJ, US
Leonard Nass - Eatontown NJ, US

International Classification:

A61H 9/00
A61H 1/00

US Classification:

601152, 601151

Abstract:

A deep vein thrombosis prevention garment includes three (3) chambered polymer having an integral welded filling tube forming three (3) sequentially filled air chambers. The aft chambers receive air from an integrated fill tube attached to pump. When the air within the first air chamber reaches a predetermined air pressure, air begins to pass into a second air chamber at a higher rate, and similarly, when the air within the second air chamber reaches a predetermined air pressure, air passes into the third air chamber at another higher rate to reach the predetermined air pressure. The different internal diameters of the integrated fill tube outlets for each air chamber provide different air flow rates, resulting in staged inflation of air chambers. A membrane panel allows air to escape the sequentially filled air chambers.
