GM Global Technology Operations, Inc. - Detroit MI
International Classification:
F02D 41/02 G06F 17/00
US Classification:
701102, 731173
Abstract:
A method of dynamically determining a mass airflow per cylinder in order to control operation of an internal combustion engine includes first initializing a mass airflow per cylinder (MAC) value. A manifold pressure (MAP) signal, a mass airflow (MAF) signal, and an induction air temperature (IAT) signal is then received. An estimated manifold pressure is calculated from the MAF, the IAT, and the initialized MAC. A filter is applied to the MAP. A manifold pressure error is determined from the estimated manifold pressure and the filtered manifold pressure. A product is computed of the manifold pressure error and the initialized MAC. The product is adapted. A mass airflow per cylinder is computed, as a second product, based on the adapted product and the initialized MAC. Engine operation is controlled based on the mass airflow per cylinder.
Ljubisa M. Mladenovic - Ann Arbor MI, US Kenneth J. Cinpinski - Ray MI, US
International Classification:
F02D 13/02
US Classification:
701102, 123 9017
Abstract:
A camshaft phasor control system for an engine includes a position control module. The position control module generates a position control signal based on a camshaft position command signal and a gain signal. A gain circuit generates the gain signal based on the position control signal and feeds the gain signal back to the position control module. The position control module positions a camshaft of the engine based on the gain signal.
Adapter Phasor Control Hold Duty Cycle System For An Engine
Kenneth J. Cinpinski - Ray MI, US Ljubisa M. Mladenovic - Ann Arbor MI, US Jerry W. Kortge - Clarkston MI, US Gregory J. York - Fenton MI, US
International Classification:
F01L 1/34 F02D 41/34
US Classification:
701103, 123 9017
Abstract:
A camshaft phasor control system for an engine includes a camshaft position sensor that generates a current camshaft position signal based on position of a camshaft. A first comparator generates a camshaft position signal based on the current camshaft position signal and a crankshaft position. The second comparator generates an error signal based on the relative camshaft position signal and a commanded camshaft position signal. A control module determines a current control hold duty cycle (CHDC) for a camshaft phasor based on an engine state parameter. The control module also generates a correction signal based on the error signal, adjusts the current CHDC based on the correction signal to generate a commanded CHDC signal, and generates another CHDC based on the commanded CHDC signal.
Mass Air Flow Estimation Based On Manifold Absolute Pressure
Ljubisa Mladenovic - Ann Arbor MI, US Kenneth Buslepp - Brighton MI, US Douglas Trombley - Hartland MI, US
International Classification:
F02D 45/00 G06F 19/00 G01M 19/00
US Classification:
701102000, 073118200
Abstract:
A control system that determines a mass air flow through a throttle of an internal combustion engine (ICE) having an intake manifold includes a calculator that calculates an estimated mass air flow based on a throttle position and an adjustment module that determines an adjustment value. The adjustment value is based on the estimated mass air flow, an estimated manifold absolute pressure and a measured manifold absolute pressure. A multiplier multiplies the estimated mass air flow by the adjustment value to determine the mass air flow.
