Robert A. Livernash - Naperville IL Robert J. Cooper - West Dundee IL Manuel Gamez - Chicago IL
International Classification:
E03B 3100
US Classification:
13762511
Abstract:
A diverter valve for diverting fluid flow between an inlet and an outlet selected from among several outlets is disclosed. The diverter valve disclosed is useful for distributing fluids in laundry applications, especially automatic clothes washers and the like. It includes a body, a valve member, a motor to operate the valve, an actuable switch, a cam mechanism to de-energize the motor upon movement to a position, and a housing for the device.
