Mario R Guell

US Patent:

39630137, Jun 15, 1976

Filed:

Jul 23, 1974

Appl. No.:

5/490924

Inventors:

Elmo C. Authement - Thibodaux LA
Gasper G. Varvaro - Thibodaux LA
Frank S. Stupka - Bogalusa LA
Obierge J. Waguespack - Thibodaux LA
Sidney J. Tabor - Thibodaux LA
Mario R. Guell - Bogalusa LA

International Classification:

F02M 1718

US Classification:

123133

Abstract:

A fuel and air induction system is provided for an internal combustion engine and includes a conventional air and fuel mixing carburetor for starting the engine when cold. However, when operating temperatures of the engine are obtained the air and fuel induction system is operative to substantially fully vaporize liquid fuel by heating the induction air and spraying fuel into the heated induction air in a manner that completely vaporizes the fuel and this vaporized fuel is then mixed with supplemental induction air which has also been heated and passed through the conventional carburetor into the intake passages of the engine, the supply of liquid fuel to the carburetor being terminated after operating temperatures of the engine are achieved.

US Patent:

45399662, Sep 10, 1985

Filed:

Jun 6, 1984

Appl. No.:

6/618365

Inventors:

Mario R. Guell - Bogalusa LA

Assignee:

Tri-Saver Corporation - Thibodaux LA

International Classification:

F02M 3100

US Classification:

123557

Abstract:

A fuel and air mixture induction system is provided for an internal combustion engine and includes a conventional air and fuel mixing carburetor for starting the engine when the latter is cold. However, when operating temperatures of the engine are reached the air and fuel induction system is operative to more thoroughly vaporize liquid fuel by pressurizing and heating not only the induction air but also the fuel and spraying the heated fuel into the heated induction air in a manner such that substantially complete fuel atomization and vaporization occurs. This pressurized fully vaporized fuel and air charge is thereafter discharged in a downstream direction into the air and fuel passage of the carburetor closely upstream from the venturi area thereof. The supply of liquid fuel to the carburetor is maintained, but the fuel flow from the carburetor float chamber is automatically reduced when the supply of vaporized fuel and air is furnished because the air and vaporized fuel is supplied to the carburetor under a low pressure thus effectively reducing the reduced venturi area pressure normally associated with a carburetor and the flow of fuel from the carburetor float chamber to the venturi area. In addition, normal opening of the throttle valves is decreased when the supply of heated air and fully vaporized fuel is supplied to the carburetor.
