In an improved swimming pool water heating system, water in the pool circulates through a first loop from the pool to a surge pit and through a filter before returning to the pool. The heating system includes a second loop with a heat exchanger in the surge pit and a remote water heater. The pool water in the pit is heated by the heat exchanger. The first and second circulation loops are separate from one another. The heater may include multiple heating units which can be staged for sequential actuation, depending upon need. The second circulation loop is closed, such that the pool water does not flow through the heater, but rather is indirectly heated via the heat exchanger. The heater is isolated from the pool water.
Non-Pressurized Indirect Swimming Pool Water Heating System
In an improved swimming pool water heating system, water in the pool circulates through a first loop from the pool to a surge pit and through a filter before returning to the pool. The heating system includes a second loop with a heat exchanger and a remote water heater. The pool water is heated by the heat exchanger. The first and second circulation loops are separate from one another. The heater may include multiple heating units which can be staged for sequential actuation. The second circulation loop is closed, such that the pool water does not flow through the heater, but rather is indirectly heated via the heat exchanger. The heater is isolated from the pool water. The heating units are vented to atmosphere so as to be non-pressurized.
An improved filtering device for a swimming pool surge pit is provided. The filtering device includes a frame with first and second filter elements removably mounted in the frame such that water flows through both elements to remove debris before the water enters a water supply line leading to the main filtration system of the pool. The filter elements slide along guide tracks in the frame and are independently removable such that one filter element is always in place. Thus, the water in the surge pit is filtered 100% of the time before passage into the water supply line. The filter elements extend above the water level in the surge pit such that both floating and submerged debris are captured by the filter elements.
Valve For Regulating Water Level In A Swimming Pool
John Pleva - Woodward IA Mark G. Pleva - Woodward IA
Assignee:
Pleva Plumbing & Heating, Inc. - Woodward IA
International Classification:
E04H 412
US Classification:
4508
Abstract:
A valve apparatus is provided for regulating the water level in a swimming pool. The apparatus is mounted in a surge pit remote from the pool. The apparatus includes first and second valves movable between open and closed positions for controlling the introduction of water into the surge pit from the main drain line and from a fresh water supply line, respectively. The first and second valves are operatively interconnected and are moved between their open and closed positions by a float member in the surge pit. As the water level in the pool drops below an ideal level wherein a thin layer of water skims over the lip of the gutter system, less water is provided to the surge pit from the gutter drain line, such that the water level in the pit drops, and causing the float member to drop so as to open the first and second valves to allow more water into the surge pit from the main drain line of the pool and from the fresh water supply line. Conversely, as the water level in the pool rises above an ideal level, excess water from the gutter drain line is supplied to the pit, thereby raising the water level therein, and raising the float member so as to close the first and second valves, thereby decreasing the flow of water from the main drain line and from the fresh water supply line.
Modulating Butterfly Valve For Controlling Water Level In A Swimming Pool
A valve assembly for regulating water level in a swimming pool includes a first butterfly valve in a pool drain line of the pool and a second butterfly valve in a fresh water line. The drain line and the fresh water line supply water to a pit remote from the pool. A return water line directs water from the pit to the pool. A float in the pit is operatively connected to both butterfly valves via first and second pivotal arms which are rotated by a sliding frame when the buoyant float rises and falls, so as to close and open the butterfly valves, and thereby maintain a desired water depth or level in the pit, and thereby a more consistent water level in the pool.
