Kevin Bischel - Rockton IL, US Kenneth Moshier - Roscoe IL, US Martin Singletary - Beloit WI, US Timothy Whitney - Beloit WI, US
Assignee:
Carrier Commercial Refrigeration, Inc. - Charlotte NC
International Classification:
F25B041/00
US Classification:
621964, 622386
Abstract:
A refrigeration system both cools and heats frozen dessert mix in at least two hoppers and at least two freezing cylinders. A liquid line solenoid valve at the inlet of each of the hoppers and the freezing cylinders controls the flow of refrigerant from the condenser. A hot gas solenoid valve at the inlet of each of the hoppers and the freezing cylinders controls the flow of hot refrigerant from the compressor. The system further includes a hot gas bypass valve that is opened when only the hoppers are being cooled to provide additional compressor load. An EPR valve proximate to the hopper discharges varies the temperature of the refrigerant exchanging heat with the mix in the hoppers. A CPR valve controls the inlet pressure of the compressor by reducing the amount of hot refrigerant flowing into the compressor suction. A TREV valve injects liquid refrigerant to the compressor suction to control excessive compressor discharge during the cool cycle.
Kevin Bischel - Rockton IL, US Kenneth Moshier - Roscoe IL, US Martin Singletary - Beloit WI, US Robert Newton - Beloit WI, US Peter McNamee - Beloit WI, US
International Classification:
F25B041/00 F25B049/00 F25B027/00
US Classification:
062/196400, 062/238600
Abstract:
A hot gas heat treat system is employed to cool mix in a hopper and a freezing cylinder and to heat the mix for pasteurization. A hopper liquid line solenoid valve at the inlet of the hopper and a cylinder liquid line solenoid valve at the inlet of the freezing cylinder each control the flow of refrigerant to the expansion valves which further control the flow of refrigerant that flows around the hopper and the freezing cylinder, respectively. A hopper hot gas solenoid valve at the inlet of the hopper and a cylinder hot gas solenoid valve at the inlet of the freezing cylinder control the flow of refrigerant from the compressor that flows around the hopper and the freezing cylinder. The system further includes a hot gas bypass valve that is opened when only the hopper is being cooled to provide additional load to the compressor. An EPR valve is positioned proximate to the hopper discharge to vary the temperature of the refrigerant exchanging heat with the hopper. A CPR valve is employed to control the inlet pressure of the compressor by reducing the amount of hot refrigerant flowing into the compressor suction. The system further includes a TREV valve to allow for liquid refrigerant injection to the compressor suction to control excessive compressor discharge during the cool cycle.
